GENUINE GRACO PARTS AND ACCESSORIES
Graco Control
Architecture
Programming
For updating or programming the software version of Graco Control Architecture Modules.
For professional use only.
See your system manual when replacing parts in hazardous locations.
Important Safety Instructions
Read all warnings and instructions in this
manual and your system manuals. Save
these instructions.
NOTE: An upgrade token is needed to program
modules. See system manual for token part num-
ber.
™
Module
USB Module
Display Module
Not all modules shown.
3A1244F
Advanced Fluid Control Module
EN
ti16440a
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graco Control Architecture Module
Summary of Contents for Graco Control Architecture Module
- Page 1 Architecture Module 3A1244F Programming For updating or programming the software version of Graco Control Architecture Modules. For professional use only. See your system manual when replacing parts in hazardous locations. Important Safety Instructions Read all warnings and instructions in this manual and your system manuals.
-
Page 2: Software Upgrade Instructions
NOTE: Token has no preferred orientation. • Use the token to load software to the Graco Control 4. Supply electrical power to the Graco Control Archi- Architecture Module before use. Follow all direc- tecture Module using either system power or Power tions and warnings in this manual and your system Supply Kit 24F672 (available separately). - Page 3 Remote Loading 9. Upgrade all other modules in the system to the soft- 3. Wait for update to complete. ware revision on the token, if not already completed. NOTE: The approximate time until completion is shown Different software versions may not be compatible. along bottom of progress bar.
- Page 4 Remote Loading Systems With A Display Module, 4. Updates are complete. Icon indicates update 262384, 24F493 success or failure. See Icon Table. Press 1. The following screen will be shown when the display continue. turns on. Communications with other modules established. Icon Description Update successful...
- Page 5 Remote Loading Systems With A Display Module or 4. Updates are complete. Icon indicates update Advanced Display Module, 24L096, 24L097 success or failure. See Icon Table. Press 1. The following screen will be shown when the display continue. turns on. Communications with other modules established.
- Page 6 Available Graco Control Architecture Modules Available Graco Control Architecture Modules Display Module (262384, USB Module (289900) 24F493) ti17215a Advanced Display Module (24E451) red light Advanced Fluid Control Module (255920) ti17216a ti16439a 3A1244F...
- Page 7 Available Graco Control Architecture Modules Communications Gateway Fluid Control Module (289696) Module (15V759, 15V760, 15V761, 15V762, 289835, 289836, 289837, 289838) ti17219a Local Control Module (262416) ti17217a Discrete Gateway Module (24B681) ti17220a ti17218a 3A1244F...
- Page 8 Available Graco Control Architecture Modules High Power Temperature Motor Control Module (257396) Control Module (255774) ti17221a ti17223a Low Power Temperature Control Display Control Module (24L096) Module (256270) and Advanced Display Control Module (24L097) ti17222a ti19597a 3A1244F...
-
Page 9: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
