Important safety instructions:
Please carefully read all instructions before assembling.
For your safety and ease, assembly by two or more adults is recommended.
Keep instructions for future use.
Pre-assembly:
Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or
hardware.
Remove all parts and hardware from box along with any plastic protective packaging.
P1
Table Top
Short Frame Leg
P2
Long Frame Leg
P3
P4
Short Stretcher
Long Stretcher
P5
H1
Bolts Ø5/16"*1-1/2"
H2
Lock Washer Ø5/16"
H3
Flat Washer Ø5/16"*3/4"
H4
Allen Wrench 4mm
H5
Plastic Cap
DISCLAIMER:
WHEN PROPERLY ASSEMBLED, THIS ITEM IS SAFE FOR INTENDED USE. SELLER IS NOT LIABLE FOR ANY DAMAGES
RESULTING FROM ITEM BEING IMPROPERLY ASSEMBLED AFTER PURCHASE
Assembly Procedures:
Step 1. Assemble the Desk on a flat, soft surface such as a carpet or cloth to prevent scratching the finish.
Attach Short Stretcher (P4) & Long Stretcher (P5) to the Short Frame Leg (P2) & Long Frame Leg (P3)
as shown below.
(H1)x4
Bolts
(H2)x4
Lock Washer
(H3)x4
Flat Washer
R
10
10
10
1
4
P5
P3
Kirtley Writing Desk
.
P2
P4
H4
H3
H2
H1
Advertisement
Table of Contents
Related Manuals for Madison Park Kirtley Writing Desk
Summary of Contents for Madison Park Kirtley Writing Desk
- Page 1 Kirtley Writing Desk Important safety instructions: Please carefully read all instructions before assembling. For your safety and ease, assembly by two or more adults is recommended. Keep instructions for future use. Pre-assembly: Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or hardware.
- Page 2 Step 2. Turn over the Table Top (P1) on a flat, soft surface such as a carpet or cloth to prevent scratching the finish. Attach the Base to the Table Top (P1) as shown below. (H1)x6 Bolts (H2)x6 Lock Washer (H3)x6 Flat Washer Step 3: Turn the Desk over and place it upright on a level surface.
