11

Accessories and Spare Parts

11 Accessories and Spare Parts

11.1 Order Address

11.2 Accessories

Pos. Order Designation
number
1 133 459 Installation kit
2 148 887 Magnet installation set
3 131 993 Cable extension 2 m
4 131 994 Cable extension 5 m
5 131 995 Cable extension 10 m
6 168 176 Spiral cable 0.5 m / 2 m
7 118 447 Connection cable 3 m
8 118 448 Connecting cable 5 m
9 118 449 Connecting cable 10 m
10 154 374 Adapter cable
11 167 205 CAN bus distributor
12 220 395 CAN-Bus adapter M12 / M8 Connection CCD camera CCDPro*
CAN-Bus power adapter
13 220 406
M8 4-pin / M8 3-pin
14 229 894 Calibration template
154/162 ekr 500 digital Unit Touch – Installation and Commissioning Manual
BST GmbH
Remusweg 1
D-33729 Bielefeld
Germany
Tel.: +49 (0) 521 400 70 767
E-Mail: service@bst.group
http: www.bst.group
Utilisation
Installation of the control panel in an existing on-site
operator panel or a control station
Installation of the control panel on a ferromagnetic
surface.
Connection control panel,
Connection of sensors (CAN-Bus)
Connection of sensors (CAN-Bus)
Connection actuator EMS 17/18/21/22
For connecting the actuators EMS 17/21/22, you
require an additional adapter cable (see pos. 10)
Connection actuator EMS 17/21/22
Connection of several bus participants,
Connection CCD camera CCDPro*
Connection CCD camera CCDPro*
CCD camera calibration
* The following accessory parts are required for connecting one
CCD camera:
1x CAN bus distributor (pos. 11)
■
1x CAN-Bus adapter (pos. 12)
■
1x CAN-Bus power adapter (pos. 13)
■
