10.3 Display of CAN Bus Status

LED Name Condition
OFF
H17 RUN
FLASHING
ON
OFF
H18 ERR
FLASHES x3
ON

10.4 Display of Device Status

10.5 Status Display of Message Output "System OK"

10.6 Status Display of Power Supply

10.7 Status Display of Controller Interlock

Bus designation Meaning
STOPPED
PREOPERATIONAL
OPERATIONAL
NO ERROR
SYNC ERROR
BUS OFF
LED Name Condition Meaning
H19 PROG
LED Name Condition Meaning
OK
H21
relay
LED Name Condition Meaning
H28 12 V
H29 3.3 V
LED Name Condition Meaning
(red)
H53 LOCK
ekr 500 digital Unit Touch – Installation and Commissioning Manual
The unit is in the initialization phase.
No data transfer takes place.
The device is in PREOPERATIONAL mode.
The initialization is completed.
The device can be started.
The unit is in OPERATIONAL mode.
The module is working correctly.
No problems exist.
No SYNC message is received.
The interface controller is located in Bus-Off mode.
OFF The unit is in an undefined state.
FLASHING The unit program is running correctly.
ON The unit is in an undefined state.
OFF Error
ON No error
OFF Operating voltage 12 V⎓ not available
ON Operating voltage 12 V⎓ available
OFF Operating voltage 3.3 V⎓ not available
ON Operating voltage 3.3 V⎓ available
OFF Controller is enabled
Controller is blocked
ON
(motor output stage is switched off)
