Vulcan-Hart VEC20 Specifications

Electric tilting kettle

Advertisement

Quick Links

SPECIFICATIONS:
2
20 gallon capacity,
/
jacketed self-contained electric tilting
3
kettle, Vulcan-Hart Model No. VEC20. Hemispheric bottom kettle
liner formed of type 316 stainless steel. Balance of construction
is type 304 fully welded stainless steel designed to operate at a
maximum of 50 PSI (3.4 kg/cm
inhibitor and antifreeze mixed to protect to 30° below zero.
Removable electric elements are field serviceable. Stainless
steel tilt handle with insulated pull knob located on the right.
Stainless steel "water proof" control housing located on the right.
Controls include a power switch, power "on" light, solid state
temperature control, vacuum/pressure gauge, pressure relief
valve, low water light and low water shut-off. Stainless steel
adjustable legs extend 4
1
/
" below base. Requires 208 or 240
2
volt, 60 Hz, 1 or 3 phase power supply.
Exterior dimensions: 30
3
/
"w x 24"d x 43
4
U L listed. NSF listed. Meets ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32299 (12-01)
2
). Jacket contains water, rust
1
/
"h.
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL VEC20
ELECTRIC TILTING KETTLE
STANDARD FEATURES
2
20 gallon capacity,
/
jacketed self-contained electric tilting
3
steam kettle.
Hemispheric bottom kettle liner formed of type 316 stainless
steel.
Balance of construction is type 304 fully welded stainless
steel designed to operate at a maximum 50 PSI (3.4 kg/cm
Jacket contains water, rust inhibitor and antifreeze mixed to
protect to 30° below zero.
Removable electric elements are field serviceable.
Stainless steel tilt handle with insulated pull knob located on
the right.
Stainless steel "water proof" control housing located on the
right. Controls include a power switch, power "on" light, solid
state temperature control, vacuum/pressure gauge, pressure
relief valve, low water light and low water shut-off.
Faucet bracket.
Stainless steel adjustable legs extend 4
Requires 208 or 240 volt, 60 Hz, 1 or 3 phase power supply.
One year limited parts and labor warranty.
OPTIONS
Tilting kettle strainer.
480 volt, 60 Hz, 3 phase power supply.
Second year extended limited parts and labor warranty.
ACCESSORIES
One piece lift-off stainless steel cover.
Stainless steel basket assembly.
Contour measuring strips.
(12") (18" double jointed) single pantry faucet.
(12") (18" double jointed) double pantry faucet.
Double pantry washdown hose with 16" add-on faucet with
backflow preventer.
Double pantry washdown hose with backflow preventer.
Double pantry pot filler and backflow preventer.
C.S.I. Section 11420
2
).
1
/
" below base.
2
