Vulcan-Hart VEL100 Specifications

SPECIFICATIONS:
Electric, self-contained, stainless steel,
mounted steam kettle, Vulcan-Hart Model No. ___________.
Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and lining (316 stainless steel liner, 20, 30 & 40
gallon). Jacket tested to 50 psi (3.4 kg/cm
water, rust inhibitor and antifreeze mixed to protect to 30°
below zero. Counterbalanced hinged stainless steel cover
with drop down lift handle (60 - 100 gallon spring assist). 2"
compression tangent draw-off valve with perforated strainer.
Tubular stainless steel legs with flanged feet. Controls enclosed
in stainless steel housing include a power switch, thermostat,
power "on" light, vacuum/pressure gauge, pressure relief valve
and low water signal light. Elements are field replaceable.
Requires 208 or 240 volts, 60 Hz, 3 phase.
U L listed. NSF listed. Meets ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-31648 (10-03)
2 / jacketed floor
3
2
). Jacket contains
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
VEL SERIES
ELECTRIC FLOOR MOUNTED
STATIONARY 2 / JACKETED KETTLE
3
VEL20 12 KW, 20 gallon capacity
VEL30 15 KW, 30 gallon capacity
VEL40 18 KW, 40 gallon capacity
VEL60 18 KW, 60 gallon capacity
VEL80 18 KW, 80 gallon capacity
VEL100 24 KW, 100 gallon capacity
STANDARD FEATURES
Electric, self-contained stainless steel,
mounted steam kettle.
Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and lining. (316 stainless steel liner for 20, 30 & 40
gallon models.)
Jacket tested to 50 psi (3.4 kg/cm
Jacket contains water, rust inhibitor and antifreeze mixed to
protect to 30° below zero.
One piece counterbalanced hinged stainless steel cover with
drop down lift handle (60 - 100 gallon spring assist).
2" compression tangent draw-off valve with perforated strainer.
Faucet bracket.
Tubular stainless steel legs with flanged feet.
Controls enclosed in stainless steel housing include a power
switch, thermostat, power "on" light, vacuum/pressure gauge,
pressure relief valve and low water signal light.
Elements are field replaceable.
Requires 208 or 240 volts, 60 Hz, 3 phase.
One year limited parts and labor warranty.
OPTIONS
Spring assist cover (20 - 40 gallon).
Two-piece hinged cover.
3" compression draw-off valve with perforated strainer.
Correction facility package:
a. Security type tamper resistant fasteners with tack welds.
b. Stainless steel step cover over draw-off valve with chain.
c. Type 316 liner (60 - 100 gallon).
Pedestal base.
Single phase, 12 or 15 KW.
24 KW elements (40, 60 & 80 gallon models only).
33 KW (60, 80 & 100 gallon models only).
480 volts, 60 Hz, 3 phase.
Second year extended limited parts and labor warranty.
ACCESSORIES
Contour measuring strip.
Perforated stainless steel basket assembly (single - 20 gal.)
(triple - 20 through 100 gallon).
Clean-up kit, includes draw-off brush, clean -up brush and
paddle scraper with 40" handle.
Stainless steel 48" whip.
Solid disk.
(12") (18" double jointed) single pantry faucet.
(12") (18" double jointed) double pantry faucet.
Double pantry washdown hose with 16" add-on faucet with
backflow preventer.
Double pantry washdown hose with backflow preventer.
Double pantry pot filler and backflow preventer.
C.S.I. Section 11420
2 / jacketed floor
3
2
).
