SpeedAlert 18 Quick Start Guide
Thank you for purchasing an All Traffic Solutions SpeedAlert 18 data-enabled radar sign.
This Quick Start Guide will show you how to install, power, and configure your new sign.
Upon receiving your new SpeedAlert, check to ensure that you have all of the items ordered. If you notice any damage
or missing items, contact ATS
Remove the SpeedAlert, batteries, charger, and other optional equipment from the boxes.
If your SpeedAlert includes batteries, they should be fully charged before deployment, as explained in
the batteries on the next
one battery is required, two batteries are recommended to increase average sign runtime. Without a solar panel,
continuous runtime with two batteries is typically between 5 and 8 days.
For all steps involving batteries, repeat for the second battery as necessary.
To remove the batteries:
A. Place the SpeedAlert face down on a flat surface and remove the mounting bracket by unlocking the lock with
the supplied key and lifting up on the bottom of the bracket. Then pull to remove.
B. Next, remove the battery compartment cover by removing the thumb screws. Set the key, bracket, and thumb
screws aside.
C.
Slide the battery or batteries out of the battery compartment, as shown in
D.
Disconnect the connectors, as shown in
ATS | Chantilly, VA | United States | Tel: 1-866-366-6602 | Email:
Copyright © 2024 | All Traffic Solutions, Inc.® | SpeedAlert 18 Quick Start Guide, ver. 1.05 | PN 4800245 | All rights reserved.
If your purchase includes the Integrated Solar option,
N :
OTE
please refer to either the ATS 3 Trailer with Integrated Solar
Setup Guide or Pole Mounting Signs with Integrated Solar
Option that came with your sign and available on
www.alltrafficsolutions.com/support.
Before you begin
If you have a TraffiCloud subscription, the first thing you'll need to get started using your
SpeedAlert is to create a data collection Site in TraffiCloud. Each Site is configured with a
speed limit and the direction of moving traffic. They provide a way to keep traffic data
organized for reporting purposes. If necessary, you can also perform Site setup after you
install your SpeedAlert at a physical location. See "Creating a Site" in Getting Started with
TraffiCloud and SpeedAlert.
If you don't have a TraffiCloud subscription, you have several other options for Site and
sign setup, as described in
Step 1: Unpacking the equipment
Technical Customer Support
page. SpeedAlert signs can accommodate up to two lithium batteries internally. Although only
[Figure 2]
[Figure 1] Slide the battery
Step 4: Configuring the SpeedAlert locally on the next
immediately.
below.
[Figure 2] Disconnect/connect
support@alltrafficsolutions.com
Step 2: Charging
[Figure 1] below.
| Web: www.alltrafficsolutions.com
page.
