InstAlert 18 Quick Start Guide
Thank you for purchasing an All Traffic Solutions InstAlert 18 Variable Message Sign. This
Quick Start Guide will show you how to set up, power, and configure your new sign. If you
have a TraffiCloud subscription, you can log on to TraffiCloud to set up your signs remotely.
Non-subscribers can complete sign setup locally.
If your purchase includes the Integrated Solar option, this guide
N :
OTE
DOES NOT apply to your product. Please refer to either the ATS 3 Trailer with Integrated Solar Setup Guide or
Pole Mounting Signs with Integrated Solar Option that came with your sign and available on
www.alltrafficsolutions.com.
[Figure 1] InstAlert 18 Variable Message
Sign
B. Next, remove the battery compartment cover by removing the thumb screws. Set the key, bracket, and thumb
screws aside.
C. Slide the battery out of the battery compartment, as shown in
D. Disconnect the connectors, as shown in
ATS | Chantilly, VA | United States | Tel: 1-866-366-6602 | Email:
Copyright © 2023 | All Traffic Solutions, Inc.® | InstAlert 18 Quick Start Guide, ver. 1.02 | PN 4800244 | All rights reserved.
Step 1: Unpack the equipment
Remove the sign, batteries, charger, and other optional equipment from
the boxes.
Batteries should be fully charged before deployment. InstAlert Variable
Message Signs can accommodate up to two 16Ah lithium batteries
internally. Although only one battery is required, two batteries are
recommended to extend the run time of the sign, on average from 7 to 10
days.
For all steps involving batteries, repeat for the second battery as
necessary.
To remove the batteries:
A. Place the InstAlert 18 face down on a flat surface and remove the
[Figure 2] Slide the battery [Figure 3] Disconnect/connect the battery
[Figure 3]
mounting bracket by unlocking the lock with the supplied key and
lifting up on the bottom of the mounting bracket.
[Figure 2]
above.
sales@alltrafficsolutions.com
above.
