InstAlert 18 Quick Start Guide
Thank you for purchasing an All Traffic Solutions InstAlert 18 variable message sign. This
Quick Start Guide will show you how to install, power, and configure your new sign.
If your purchase includes the Integrated Solar option, please refer to either the
N :
OTE
ATS 3 Trailer with Integrated Solar Setup Guide or Pole Mounting Signs with Integrated Solar
Option that came with your sign and available on www.alltrafficsolutions.com/support.
Step 1: Unpacking the equipment
Upon receiving your new InstAlert, check to ensure that you have all of the items ordered. If you notice any damage or
missing items, contact ATS
Remove the InstAlert, batteries, charger, and other optional equipment from the boxes.
ATS | Chantilly, VA | United States | Tel: 1-866-366-6602 | Email:
Copyright © 2024 | All Traffic Solutions, Inc.® | InstAlert 18 Quick Start Guide, ver. 1.03 | PN 4800244 | All rights reserved.
Technical Customer Support
If your InstAlert includes batteries, they should be fully charged before
deployment, as explained in
InstAlert signs can accommodate up to two lithium batteries internally.
Although only one battery is required, two batteries are recommended to
increase average sign runtime. Without a solar panel, continuous runtime
with two batteries is typically between 2 and 4 days.
For all steps involving batteries, repeat for the second battery as necessary.
To remove the batteries:
A. Place the InstAlert face down on a flat surface and remove the
mounting bracket by unlocking the lock with the supplied key and
lifting up on the bottom of the bracket. Then pull to remove.
B. Next, remove the battery compartment cover by removing the
thumb screws. Set the key, bracket, and thumb screws aside.
C. Slide the battery or batteries out of the battery compartment, as
shown in
D.
Disconnect the connectors, as shown in
[Figure 1] Slide the battery
immediately.
Step 2: Charging the batteries on the next
[Figure 1] below.
[Figure 2] Disconnect/connect
support@alltrafficsolutions.com
[Figure 2] below.
