SpeedAlert 18 Hardware Quick Start Guide
Thank you for purchasing an All Traffic Solutions SpeedAlert 18 Radar Speed Sign. This
hardware quick start guide will show you how to set up, power, and configure your new sign.
For details about using the sign, go to www.alltrafficsolutions.com/support, where there are
complete user manuals that you can use online or download and print.
[Figure 1] SpeedAlert 18 Radar Speed
Sign
4. Disconnect the power connectors if connected, as shown in [Figure 3] above.

Charge the batteries

The SpeedAlert 18 arrives with the batteries partially charged and needs to be fully charged before deployment.
The charger is not intended for outdoor use. The batteries should only be charged and stored in a
C :
AUTION
controlled environment.
1. Plug the battery into the supplied charger cable.
2. Plug the charger cable into a power outlet. The light on the charger displays red while charging and changes to
green when charging is nearly complete. A charge can take up to 11 hours for the 12V 16Ah LFP batteries
supplied with the sign.
ATS | Chantilly, VA | United States | Tel: 1-866-366-6602 | Email:

Unpack the equipment

Remove the sign, batteries, charger, and other optional equipment from the
boxes.
Batteries should be fully charged before deployment. SpeedAlert Radar
Message Signs can accommodate up to two 16Ah lithium batteries
internally. Although only one battery is required, two batteries are
recommended to extend the run time of the sign, on average from 7 to 10
days.
For all steps involving batteries, repeat for the second battery as necessary.

Remove the batteries

1. Place the SpeedAlert 18 face down on a flat surface and remove the
mounting bracket by unlocking the lock with the supplied key and
lifting up on the bottom of the mounting bracket.
2. Next, remove the battery compartment cover by removing the thumb
screws. Set the key, bracket, and thumb screws aside.
3. Slide the battery out of the battery compartment, as shown in [Figure
2] below.
[Figure 2] Slide the battery
Copyright © 2022 | All Traffic Solutions, Inc.® | Document ver. 1.0 | All rights reserved.
[Figure 3] Disconnect the battery
