Scope of delivery

4 Scope of delivery
A shipping company will deliver the individual parts to the kerbside on a double pallet.
Before you assemble the portable vocal and singing booth, make sure the contents of package is complete according to the fol‐
lowing list.
1 × floor panel, 2 × 25-mm MDF, melamine-coated
n
1 × right side panel with window module (noise-insulating double-layer insulation glass), 25-mm MDF, melamine-coated
n
1 × left side panel, 25-mm MDF, melamine-coated
n
n 1 × rear panel with 3 holes for cable feedthrough and a thread for attaching a microphone arm, 25-mm MDF, melamine-
coated
1 × lockable door with handle, 25-mm MDF, melamine-coated
n
2 × panels for door front, 25-mm MDF, melamine-coated
n
2 × shelves, one with a hole for cable feedthrough
n
n 1 × ceiling element with air vent, 18-mm MDF, melamine-coated
15 × screws
n
58 × connecting bolts
n
37 × connector housings
n
59 × wooden dowels
n
1 × foam filter
n
1 × carpet
n
PET polyester panels for exterior insulation, 12 mm, magnetic assembly
n
n PET polyester panels for interior insulation, 12.25 mm and 40 mm, magnetic assembly
1 × rechargeable USB LED lamp
n
Optional ventilation system
n 1 × ventilation element with connecting cable and plug
4 × wooden dowels
n
