Technical specifications

6 Technical specifications
Voice and singing booth
Volume reduction
Material
Dimensions (W × H × D)
Weight
Dimensions of window module (L × W)
Optional ventilation module (item no. 564133)
Air exchange
Supply voltage
Dimensions (W × H × D)
Weight
Ambient conditions Temperature range
Relative humidity
Isolation Booth
24
Portable Vocal and Singing Booth
approx. 27 dB
Panels MDF, melamine-coated
Window module Double-layer insulating glass
Insulating panels PET polyester
Outside: 1,090 mm × 2,193 mm × 1,090 mm
Height with optional ventilation module: 2,289 mm
Inside: 975 mm × 2,075 mm × 963 mm
244 kg
770 mm × 530 mm
40 m³ / 20 air exchanges per hour
100 - 240 V
400 mm × 106 mm × 230 mm
3.6 kg
0 °C...40 °C
20%...80% (non-condensing)
50/60 Hz
