DATA PROJECTOR
VPL-FH30
VPL-F400H
REMOTE COMMANDER
RM-PJ19
SERVICE MANUAL
1st Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPL-FH30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony VPL-FH30

Summary of Contents for Sony VPL-FH30

  • Page 1 DATA PROJECTOR VPL-FH30 VPL-F400H REMOTE COMMANDER RM-PJ19 SERVICE MANUAL 1st Edition...
  • Page 2 WARNUNG VPL-FH30 Beim Einbau des Geräts ist daher im Festkabel ein leicht zugänglicher Unterbrecher einzufügen, oder das Netzkabel muß mit einer in der Nähe For kundene i Norge des Geräts befi...
  • Page 3 Batterien nur durch den vom Hersteller empfohlenen Kasser batteriet i henhold til gjeldende avfallsregler. oder einen gleichwertigen Typ ersetzen. Wenn Sie die Batterie entsorgen, müssen Sie die Gesetze der jeweiligen Region und des jeweiligen Landes befolgen. 注意 注意 如果更换的电池不正确，就会有爆炸的危险。 只更换同一类型或制造商推荐的电池型号。 处理电池时，必须遵守相关地区或国家的法律。 1 (P) VPL-FH30...

  • Page 5: Table Of Contents

    2-7-5. Writing of C Board/Opt Unit/3DGamma/ 1-5. Precaution for Transporting ........1-32 (E) LookUpTable/Chiral/GCFB Data ....2-14 (E) 2-7-6. Writing of DDC Data ........2-15 (E) 2-7-7. Writing of NVM Data ........2-16 (E) 2-8. Adjustment Item Initialize Data ......2-17 (E) 1 (E) VPL-FH30...
  • Page 6 QB ................. 5-29 QC ................. 5-30 Frame Wiring..............5-31 6. Board Layouts GB ................... 6-1 H ..................6-1 NF ..................6-1 C ..................6-2 QA ................... 6-4 QB ................... 6-4 QC ................... 6-5 U ..................6-5 V ..................6-5 2 (E) VPL-FH30...

  • Page 7: Manual Structure

    Manual Structure Purpose of this manual This manual is the Service Manual of the Data Projector VPL-FH30/F400H. This manual contains the service overview, adjustments, spare parts, block diagrams, schematic diagrams and board layouts. Related manuals In addition to this Service Manual, the following manuals are provided.

  • Page 9: Service Overview

    Section 1 Service Overview 1-1. Appearance Figure 1-2. Board Locations C board Power supply unit U board (Main) GB board H board NF board QB board QC board Power supply unit (Lamp) QA board V board 1-1 (E) VPL-FH30...

  • Page 10: Disassembly

    Remove parts in the order of numbers shown in the fi gure, in this section. 1-3-1. Lens Cover Assembly 1-3-20. Lens 1-3-2. Rear Panel Assembly 1-3-3. Top Panel Assembly and H Board 1-3-4. GB board 1-3-5. C Board 1-3-18. NF Board 1-3-19. U Board 1-2 (E) VPL-FH30...
  • Page 11 1-3-6. Power Supply Unit (Main) 1-3-13. Gear Block 1-3-7. DC Fan (For Power Supply Unit (Main)) 1-3-24. PS Assembly (P/S Converter) 1-3-10. DC Fan (For lamp) and 1-3-11. DC Fan Fuse Connector Assembly (For Power Supply Unit (Lamp)) 1-3 (E) VPL-FH30...
  • Page 12 1-3-15. QB Board and QC Board 1-3-12. Power Supply Unit (Lamp) 1-3-16. DC Fan 1-3-22. Prism Assembly 1-3-21. In-polarizer (R)/(G)/(B) Assembly (Panel R/B and Panel G (For Intake)) 1-3-17. V Board 1-3-23. Out-polarizer (R)/(G)/(B) Assembly 1-3-25. Shift and Out-pre-polarizer (R)/(G)/(B) Assembly 1-4 (E) VPL-FH30...

  • Page 13: Lens Cover Assembly

    Three grooves of the top panel assembly Three convex portions of the lens cover assembly 2 Lens cover assembly 1 Loosen the two screws (M3) (with stoppers). 1-5 (E) VPL-FH30...

  • Page 14: Rear Panel Assembly

    5 Rear panel assembly 2 Four hooks Four holes of the top panel assembly 2 Four hooks 5 Rear panel assembly 1 Loosen the three screws (M3) (with stoppers). 4 Sheet (RP) 3 Nylon rivet 1-6 (E) VPL-FH30...

  • Page 15: Top Panel Assembly And H Board

    != Button (H) connector (CN11) on the H board. !/ Holder (H) !- H board 9 Nylon rivet 2 Seven screws (BVTP3 x 12) 1 Two screws (PSW M3 x 70) 1-7 (E) VPL-FH30...

  • Page 16: Board

    1-3-4. GB board 5 Four screws (BVTP3 x 12) 1 Harness CN2601 CN2603 CN2602 3 Harness 2 Harness 6 GB board CN2501 4 Harness Rear side of this unit 1-8 (E) VPL-FH30...

  • Page 17: C Board

    CN1701 Power supply unit (Lamp) CN303 CN202 H board CN201 NF board CN1601 CN1801 Prism assembly (B) Prism assembly (R) Prism assembly (G) V board CN301 QC board CN106 CN102 CN101 QA board QA board C board 1-9 (E) VPL-FH30...
  • Page 18 (IC) facing the shield (CT) side. 9 C board 3 Three harnesses 0 Screw (PSW3 x 8) 8 Two connectors (B to B) 7 Three flexible flat cables !- WU shield (CB) 1-10 (E) VPL-FH30...

  • Page 19: Power Supply Unit (Main)

    1 Open the wire saddle. 6 Seven screws (BVTP3 x 12) 7 Sleeve (GA) 8 Shield (GA) 0 Power supply unit (Main) 9 Two harnesses 5 Two harnesses !- Two mini card spacers != Sheet (GA) 1-11 (E) VPL-FH30...

  • Page 20: Dc Fan (For Power Supply Unit (Main))

    Harness 2 Nylon rivet 4 Two screws (BVTP3 x 12) 5 DC fan (for power supply unit) When attaching, place with the label side facing down. 6 Two kapton tapes Label side 3 Fan holder (GA) 1-12 (E) VPL-FH30...

  • Page 21: Dc Fan (Lamp Out (For Exhaust))

    9 DC fan (LAMP OUT (for exhaust)) When attaching, place with the label side facing left side of this unit. 7 Three hooks 8 Lamp house (Bottom) Left side of this unit Front side of this unit 1-13 (E) VPL-FH30...

  • Page 22: Optical Block Assembly

    0 Four screws View from arrow A (BVTP3 x 12) !- Optical block assembly 8 Loosen the three screws (with stoppers). When removing the optical Portions B block assembly, hold at the three portions B. !- Optical block assembly 1-14 (E) VPL-FH30...

  • Page 23: Dc Fan (For Lamp) And Fuse Connector Assembly

    8 Lamp duct (Top) 3 DC fan (for lamp) Label side !- Fuse connector When attaching, place with assembly the label side facing down. 4 Four cushions 9 Hook (Fan) 6 Damper (Fan) 0 Lamp duct (Bottom) 1-15 (E) VPL-FH30...

  • Page 24: Dc Fan (For Power Supply Unit (Lamp))

    5 DC fan (for power supply unit (Lamp)) 8 Two kapton tapes When attaching, place with the label side facing down. Label side 3 Open the wire saddle, then remove the two 9 Damper (Fan) harnesses. Harnesses 1-16 (E) VPL-FH30...

  • Page 25: Power Supply Unit (Lamp)

    1-3-12. Power Supply Unit (Lamp) 1 Two harnesses 3 Power supply unit (Lamp275) 4 Sheet (Ballast275) 5 Harness 6 Shield (Ballast) 7 Four board supports 2 Three dowels 1-17 (E) VPL-FH30...

  • Page 26: Gear Block

    1-3-13. Gear Block 2 Gear block 1 Three screws (BVTP3 x 12) 1-18 (E) VPL-FH30...

  • Page 27: Qa Board

    5 Open the wire saddle, then remove the harness. 0 Two screws Harness (PSW3 x 8) 6 Two harnesses !- QA board != Sheet (BNC) 8 Two screws (BVTP3 x 8) 9 Screw (B3 x 6) 7 Six connector screws 1-19 (E) VPL-FH30...

  • Page 28: Qb Board And Qc Board

    9 QC board !\ Sheet (QB) !- Two harnesses ![ Two screws (PSW3 x 8) !] QB board != Screw (BVTP3 x 8) 7 Two connector screws 5 Open the wire saddle, then remove the harness. Harness 1-20 (E) VPL-FH30...

  • Page 29: Dc Fan (Panel R/B And Panel G (For Intake))

    7 Four screws (BVTP3 x 12) 8 Prism duct (Bottom) 9 Two DC fans (PANEL R/B and Panel G (for intake)) When attaching, place with the label side facing down. Label sides 5 Open the wire saddle, then remove the harness. 1-21 (E) VPL-FH30...

  • Page 30: Board

    1-3-17. V Board Prism duct (Bottom) 2 V Board 3 Harness 1 Screw (BVTP3 x 12) 1-3-18. NF Board 4 Harness 1 Nylon rivet 2 Holder (LED) 3 NF Board 1-22 (E) VPL-FH30...

  • Page 31: U Board

    1-3-19. U Board 1 Screw (BVTP3 x 12) 2 Cover (U) 4 Harness 3 U Board Rear side of this unit 1-23 (E) VPL-FH30...

  • Page 32: Lens

    2 Turn the lens shift dial (vertical direction) in the direction of the arrow fully Lens (clockwise direction (2) fully). Delta mark Lens fixing screws Delta mark 3 Loosen the four lens fixing screws (with stoppers). 4 Lens 1-24 (E) VPL-FH30...

  • Page 33: In-Polarizer (R)/(G)/(B) Assembly

    When the in-polarizer (R)/(G)/(B) assembly is removed from unit assembly, perform the adjustment after installing. (Refer to Section 2-2.) 1 Screw (B2 x 5) 5 Screw (B2 x 5) 2 In-polarizer (G) assembly 6 In-polarizer (B) assembly 3 Screw (B2 x 5) 4 In-polarizer (R) assembly Unit assembly 1-25 (E) VPL-FH30...

  • Page 34: Prism Assembly

    1-3-22. Prism Assembly When the prism assembly is replaced, perform the procedure after replacement. (Refer to Section 2-1-1.) 1 Three screws (B2 x 5) 2 Prism assembly 1-26 (E) VPL-FH30...

  • Page 35: Out-Polarizer (R)/(G)/(B) Assembly And Out-Pre-Polarizer (R)/(G)/(B) Assembly

    Prism assembly top view 4 Out-pre-polarizer (G) assembly Marking 7 Out-polarizer (G) assembly 6 Out-pre-polarizer Marking (B) assembly 9 Out-polarizer 5 Out-pre-polarizer (B) assembly (R) assembly Marking 8 Out-polarizer (R) assembly Front side 1-27 (E) VPL-FH30...

  • Page 36: Ps Assembly (P/S Converter)

    1 Two screws (PWH3 x 10) 1-3-25. Shift 4 Three screws (PWH3 x 10) 5 Prism mount Remove the prism mount only when replacing the shift alone. 6 Shift 2 Two screws (PWH3 x 10) 3 Unit assembly 1-28 (E) VPL-FH30...

  • Page 37: Optional Fixtures

    D Cable 3P (C board-XC board) x1 H Cable 15P (C board-XC board) x1 E Cable 5P (C board-XC board) x2 I Cable 12P (C board-XC board) x1 (2 mm pitch) F Cable 7P (C board-XC board) x1 1-29 (E) VPL-FH30...

  • Page 38: Connection

    4. Apply the insulation tapes (commercially supplied) on the A-side of the X70 boards. 5. Connect the two X70 boards to the connectors (CN2403 and CN2404) on the QA board. B-side Insulation tape X70 board (A-side) X70 board CN2404 QA board CN2403 1-30 (E) VPL-FH30...
  • Page 39 CN104 CN103 CN103 CN105 CN105 CN5103 CN5104 CN5105 CN5302 CN104 CN5303 CN303 CN303 CN1701 CN202 CN201 CN1801 CN1601 CN5301 CN301 For * marked connectors, CN301 connect the harnesses CN106 CN5106 which were disconnected CN106 from c board. 1-31 (E) VPL-FH30...

  • Page 40: Precaution For Transporting

    4. Attach the packing cap with placing the notch at the zoom lever. To removing the packing cap, reverse the procedure. Lens shift dial Lens shift dial Lens (horizontal direction) (vertical direction) Zoom lever Delta mark Lens fixing screws Delta mark Zoom lever Notch Packing cap 1-32 (E) VPL-FH30...

  • Page 41: Service Mode (Network Volume)

    You are prompted to enter a user name and password. Enter them as follows: User name: service Password: (Lower-case model name) Example: vpl-fh30 or vpl-f400h When moving from the service mode to other pages and entering the service mode again, close a Web browser once and start the Web browser again.
  • Page 42 . Network Update Bridge: Used for serial-to-network conversion. . Null-modem emulator: Used for virtual port creation. For obtaining each application, please contact your local Sony Sales Offi ce/Service Center. (1) Install Network Update Bridge. 1) Copy Network Update Bridge.exe below C:\Projector\Network Update Bridge.
  • Page 43 When Main/Sub is updated; Pull out and insert the AC cord of a projector after Network Update Bridge is closed every time each updating is completed. Return to step 1 for updating when continuing updating. 1-35 (E) VPL-FH30...

  • Page 44: Event Trace Function

    Serial number . Location: Installation site (Blanked when Location is not set.) ROM Ver. . Main ROM Version: Version of Main ROM . Sub ROM Version: Version of Sub ROM . Ext ROM Version: Version of Ext ROM 1-36 (E) VPL-FH30...
  • Page 45 LAMP/FILTER REPLACE 50H: 50 hours before lamp/fi lter replacement LAMP REPLACE: Lamp replacement SIGNAL WARNING FREQUENCY OVER: Input signal frequency warning SIGNAL WARNING SIGNAL SETTING MISTAKE: Input signal type warning FILTER CLEANING: Filter cleaning FILTER REPLACE: Filter replacement 1-37 (E) VPL-FH30...
  • Page 46 Requested action not taken: mailbox name not The name of a mailbox is improper, so data allowed was not delivered. Transaction failed Processing failed. (Continue) 1-38 (E) VPL-FH30...

  • Page 47: Setup Function

    Reception failed. 1-6-4. Setup Function When a user forgot a Web password, click the [Setup] tab and then [Password] button from the Web page of service and set the Web password on the password setting screen again. 1-39 (E) VPL-FH30...

  • Page 48: Web Password Change

    Number of Status blinking Cover error The lamp cover or fi lter holder is removed. The connectors to temperature sensor boards (U and V boards) are not connected properly. Lamp error The lamp does not light normally. 1-40 (E) VPL-FH30...

  • Page 49: Lead-Free Solder

    . The ordinary soldering iron can be used but the iron tip has to be applied to the solder joint for a slightly longer time. The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful. 1-41 (E) VPL-FH30...

  • Page 51: Adjustments

    7. Perform the V COM adjustment. (Refer to Section 2-4.) 8. Check the white balance, then perform the white balance adjustment as needed. (Refer to Section 2-5.) 9. Perform the Ext (Network) reset. (Refer to Section 2-6-5.) 2-1 (E) VPL-FH30...

  • Page 52: Polarizer Adjustment

    H board NF board Screw (B2 x 5) Screw (B2 x 5) In-polarizer (G) assembly In-polarizer (B) assembly In-polarizer (R) assembly Screw (B2 x 5) 13. Assemble the unit in the reverse order of steps 1 to 3. 2-2 (E) VPL-FH30...

  • Page 53: Preparation For Electrical Adjustment

    6. Select the menus in the following order: Installation → Image Flip and set it to either “V” or “HV”. 7. Perform the steps 2 to 5. 8. Select the menus in the following order: Installation → Image Flip and set back to “Off”. 2-3 (E) VPL-FH30...

  • Page 54: White Balance Adjustment

    Target chromaticity (x, y): 0.292, 0.310 6. Repeat steps 2 to 5 until the chromaticity (x ?0.002, y ?0.002) with reference to the target chromaticity (x, y). 7. Select the menus: Device → Save To Memory, then select [Yes] and press [ENTER]. 2-4 (E) VPL-FH30...

  • Page 55: Input A Color Temperature: Low

    Target chromaticity (x, y): 0.292, 0.310 9. Repeat steps 5 to 8 until the chromaticity (x ?0.002, y ?0.002) with reference to the target chromaticity (x, y). 10. Select the menus: Device → Save To Memory, then select [Yes] and press [ENTER]. 2-5 (E) VPL-FH30...

  • Page 56: Video In Color Temperature: Low

    . Anem Updater: Updater for Ext (Network) . For obtaining the each application and version upgrade fi le, contact your local Sony Sales Offi ce/ Service Center. . For Ext (Network) updating PC, the installation of the softwares below is required.
  • Page 57 1. Set the Standby Mode to “Standard” in the Connection/Power menu. (Refer to Operating Instructions.) 2. Install each application to PC. 3. Disconnect the AC plug of this unit. 4. Connect this unit with PC by RS-232C or USB-RS-232C dual, referring to the connection fi gure. 2-7 (E) VPL-FH30...

  • Page 58: Main (Scan Converter)

    2-6-2. Main (Scan Converter) 1. Copy the fi les to be written into the same folder of application fi le FlashUpgrader.exe. For fi les to be written, please contact your local Sony Sales Offi ce/Service Center. 2. Double-click FlashUpgrader.exe to start the application.

  • Page 59: Sub

    1. Copy the three fi les rx3vXXXXX.dli, 5212.inf, and rx3vXXXXX.mot into the same folder of applica- tion fi le Flash.exe. XXXXX means version number. 2. Double-click Flash.exe to start the application. Application name: Sub Flash Upgrader for Sony Projector File name: Flash.exe 3. Check rx3vXXXXX.dli, 5212.inf, rx3vXXXXX.mot are selected in download information fi le, MCU Type setting, and ROM File Name respectively.

  • Page 60: Ext (Network)

    For COM*, enter the serial port number used for connecting PC. 5. Check that “Completed!!” is displayed. When “Failed” is displayed, disconnect the AC plug of this unit, then perform from step 1 again. 6. Disconnect the AC plug. Example screen of Ext reset via COM1 2-10 (E) VPL-FH30...

  • Page 61: Quick Access2

    13. Click the [OK] button. The saving starts. Completed is displayed after completed. 14. Press the I/O button and set this unit to standby state. 15. Disconnect the AC plug. 16. Click the [Complete] button. 2-11 (E) VPL-FH30...

  • Page 62: Saving Of Ddc Data

    The window displaying the model name of this unit, serial number, and the fi le path of the destination of the obtained data to save is displayed. 12. Click the [OK] button. The saving starts. Completed is displayed after completed. 13. Disconnect the AC plug. 14. Click the [Complete] button. 2-12 (E) VPL-FH30...

  • Page 63: Saving Of Nvm Data

    After completed, The massage “Verify Success! Reading Model Name, Serial Number, NVM Map Version and NVM Data Version is successful.” is displayed. 14. Click the [OK] button. Completed is displayed. 15. Disconnect the AC plug. 16. Click the [Complete] button. 2-13 (E) VPL-FH30...

  • Page 64: Writing Of C Board/Opt Unit/3Dgamma/Lookuptable/Chiral/Gcfb Data

    13. Click the [OK] button. The writing starts. Completed is displayed after completed. 14. Press the I/O button and set this unit to standby state. 15. Disconnect the AC plug. 16. Click the [Complete] button. 2-14 (E) VPL-FH30...

  • Page 65: Writing Of Ddc Data

    The window displaying the fi le path, model name written in fi le, unit serial, serial number, and DDC ID is displayed. 12. Click the [OK] button. The writing starts. Completed is displayed after completed. 13. Disconnect the AC plug. 14. Click the [Complete] button. 2-15 (E) VPL-FH30...

  • Page 66: Writing Of Nvm Data

    After completed, The massage “Turn Off and On the AC, and then Power On to enable the new settings.” is displayed. 14. Click the [OK] button. Completed is displayed. 15. Disconnect the AC plug. 16. Click the [Complete] button. 2-16 (E) VPL-FH30...

  • Page 67: Adjustment Item Initialize Data

    Screen Wide Mode(SD) Wide Mode(HD) 16_9 Wide Mode(PC) FULL_1 Over Scan Adjust Signal Dot Phase Pitch Shift Function Output Volume SmartAPA CC Display Lamp Mode Standard Lamp timer setting Background BLUE Startup Image (Continue to Next page) 2-17 (E) VPL-FH30...
  • Page 68 Bias R *1: “Phase, Pitch, Shift H/V, Over Scan” in the “Adjust Signal” menu have the initial value respectively in accordance with the input signal (PRESET MEMORY No.). There are nonadjustable items in accordance with the input signal. 2-18 (E) VPL-FH30...
  • Page 69 Black Level Adj. Gamma Mode Screen Wide Mode(SD) Wide Mode(HD) Wide Mode(PC) Over Scan Adjust Signal Dot Phase Pitch Shift Function Output Volume SmartAPA CC Display Lamp Mode Lamp timer setting Background Startup Image (Continue to Next page) 2-19 (E) VPL-FH30...
  • Page 70 Serial Number signal info signal info Main ROM Version NVM Version Sub ROM Version Network ROM Version Lamp Timer Operation Timer Prev. Lamp Timer Gain R Bias R There are nonadjustable items in accordance with the input signal. 2-20 (E) VPL-FH30...
  • Page 71 Black Level Adj. Gamma Mode Screen Wide Mode(SD) Wide Mode(HD) Wide Mode(PC) Over Scan Adjust Signal Dot Phase Pitch Shift Function Output Volume SmartAPA CC Display Lamp Mode Lamp timer setting Background Startup Image (Continue to Next page) 2-21 (E) VPL-FH30...
  • Page 72 Serial Number signal info signal info Main ROM Version NVM Version Sub ROM Version Network ROM Version Lamp Timer Operation Timer Prev. Lamp Timer Gain R Bias R There are nonadjustable items in accordance with the input signal. 2-22 (E) VPL-FH30...
  • Page 73 B Offset (Component HD) SonG Threshold SonG Hysterisis Disable SonG Filter Enable HS0 Threshold HS1 Threshold HS Filter Disable Sub ADC/ R Gain G Gain B Gain R Offset G Offset B Offset (Continue to Next page) 2-23 (E) VPL-FH30...
  • Page 74 HPC R DATA0 HPC G DATA0 HPC B DATA0 HPC R DATA1 HPC G DATA1 HPC B DATA1 Other Other/ Synchronous Sync Pattern Enb Pattern Type Pattern R Enb Pattern G Enb Pattern B Enb Pattern Section 2-24 (E) VPL-FH30...
  • Page 75 B Offset (Component HD) SonG Threshold SonG Hysterisis Disable SonG Filter Enable HS0 Threshold HS1 Threshold HS Filter Disable Sub ADC/ R Gain G Gain B Gain R Offset G Offset B Offset (Continue to Next page) 2-25 (E) VPL-FH30...
  • Page 76 HPC B RGT1 HPC R DATA0 HPC G DATA0 HPC B DATA0 HPC R DATA1 HPC G DATA1 HPC B DATA1 Other Other/ Synchronous Pattern Enb Pattern Type Pattern R Enb Pattern G Enb Pattern B Enb Pattern Section 2-26 (E) VPL-FH30...
  • Page 77 B Offset (Component HD) SonG Threshold SonG Hysterisis Disable SonG Filter Enable HS0 Threshold HS1 Threshold HS Filter Disable Sub ADC/ R Gain G Gain B Gain R Offset G Offset B Offset (Continue to Next page) 2-27 (E) VPL-FH30...
  • Page 78 HPC B RGT1 HPC R DATA0 HPC G DATA0 HPC B DATA0 HPC R DATA1 HPC G DATA1 HPC B DATA1 Other Other/ Synchronous Pattern Enb Pattern Type Pattern R Enb Pattern G Enb Pattern B Enb Pattern Section 2-28 (E) VPL-FH30...
  • Page 79 B Offset (Component HD) SonG Threshold SonG Hysterisis Disable SonG Filter Enable HS0 Threshold HS1 Threshold HS Filter Disable Sub ADC/ R Gain G Gain B Gain R Offset G Offset B Offset (Continue to Next page) 2-29 (E) VPL-FH30...
  • Page 80 HPC G DATA1 HPC B DATA1 Other Other/ Synchronous Pattern Enb enable Pattern Type Pattern R Enb enable Pattern G Enb enable Pattern B Enb enable Pattern Section There are nonadjustable items in accordance with the input signal. 2-30 (E) VPL-FH30...

  • Page 81: Spare Parts

    Therefore, specifi ed parts should be used in the case of な部品です。したがって，交換する時は必ず指定 replacement. の部品を使ってください。 2. Standardization of Parts 2.  部品の共通化 Some repair parts supplied by Sony differ from those   ソニーから供給する補修用部品は，セットに使われて used for the unit. These are because of parts common- いるものと異なることがあります。 ality and improvement.

  • Page 82: Exploded Views

    Panel Block 3-2. Exploded Views To C board BVTP 3 x 12 VPL-FH30...
  • Page 83 4-172-335-01 s BUTTON (H) 4-172-336-01 s BUTTON (ARROW) 4-172-382-02 s SHEET (TOP) 4-172-383-01 s SHEET (RP) 4-261-064-01 s EMBLEM (WU) (For VPL-FH30) 4-278-532-01 s EMBLEM (WUC) (For VPL-F400H) 4-172-391-01 s LABEL (PANTHER), CAUTION 4-172-393-01 s SCREW (M3), STOPPER 7-685-648-79 s SCREW +BVTP 3X12 TYPE2 IT-3...
  • Page 84 Board Block Part No. SP Description A-1813-092-A s MOUNTED CIRCUIT BOARD, C (For VPL-FH30) A-1823-661-A s MOUNTED CIRCUIT BOARD, C 3 x 8 (For VPL-F400H) A-1813-093-A s MOUNTED CIRCUIT BOARD, GB 4-110-685-01 s SHEET (IC) 4-261-061-01 s SHEET (PD) 7-682-948-01 s SCREW +PSW 3X8...
  • Page 85 To GB board 7-685-648-79 s SCREW +BVTP 3X12 TYPE2 IT-3 BVTP 3 x 12 BVTP 3 x 12 BVTP 3 x 12 To C board To GB board BVTP 3 x 12 BVTP 3 x 12 Optics block assembly VPL-FH30...
  • Page 86 3 x 12 BVTP 3 x 12 BVTP 3 x 12 BVTP 3 x 12 To GB board BVTP 3 x 12 To C board To C board To GB board To AC inlet To C board BVTP 3 x 12 VPL-FH30...
  • Page 87 4-172-379-01 s SHEET (BALLAST 275) 4-172-380-01 s SHEET (GA) 4-195-278-02 s DAMPER (FAN) 1-910-400-20 s CONNECTOR ASSY, VH 3P 1-910-400-24 s CONNECTOR ASSY, LAMP VH 4-264-738-01 s CUSHION (FAN) 4-264-739-01 s SCREW, STEP 7-685-648-79 s SCREW +BVTP 3X12 TYPE2 IT-3 VPL-FH30...
  • Page 88 QA, QB and QC Board Block BVTP 3 x 12 4 x 8 BLACK To power unit (main) WHITE K3 x 6 To C board 3 x 8 3 x 8 3 x 8 BVTP3 x 8 BVTP3 x 8 B3 x 6 VPL-FH30...
  • Page 89 QA, QB and QC Board Block Part No. SP Description A-1813-094-A s MOUNTED CIRCUIT BOARD, QA (For VPL-FH30) A-1823-662-A s MOUNTED CIRCUIT BOARD, QA (For VPL-F400H) A-1813-095-A s MOUNTED CIRCUIT BOARD, QB A-1813-096-A s MOUNTED CIRCUIT BOARD, QC 1-815-480-11 s INLET, AC (WITH NOISEFILTER)
  • Page 90 3 x 12 BVTP 3 x 12 BVTP 3 x 12 To C board BVTP 3 x 12 To GB board BVTP 3 x 12 C board BVTP 3 x 12 BVTP 3 x 12 BVTP 3 x 12 3-10 VPL-FH30...
  • Page 91 4-172-345-01 s COVER (BOTTOM), FILTER 4-172-351-01 s HOLDER, FILTER 4-172-372-01 s PLATE (NUT) 4-172-374-01 s PLATE (SW) 4-263-141-01 s SHEET (Q), WU 4-172-386-01 s FILTER (TOP) 4-172-387-01 s FILTER (BOTTOM) 4-184-728-01 s CUSHION (FILTER) 7-685-648-79 s SCREW +BVTP 3X12 TYPE2 IT-3 3-11 VPL-FH30...
  • Page 92 B2 x 5 Marking side Marking Marking side BVTP side 3 x 10 To C board To C board Marking B2 x 5 side To C board B2 x 5 3 x 10 3 x 10 3 x 10 3-12 VPL-FH30...
  • Page 93 A-1784-690-A s S OUT PRE-POLARIZER (G) ASSY A-1784-691-A s S OUT PRE-POLARIZER (B) ASSY 3-093-573-01 s CUSHION (W) 9-885-145-33 s S-SHIFT 9-885-155-81 s S-LENS (H) 7-621-771-06 s SCREW +B 2X5 7-685-647-79 s SCREW +BVTP 3X10 TYPE2 IT-3 7-685-903-31 s TAPPING +PWH 3X10 TYPE2 N-S 3-13 VPL-FH30...

  • Page 94: Electrical Parts List

    Ref. No. or Q'ty Part No. SP Description or Q'ty Part No. SP Description A-1813-092-A s MOUNTED CIRCUIT BOARD, C (VPL-FH30) C411 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 A-1823-661-A s MOUNTED CIRCUIT BOARD, C (VPL-F400H) C412 1-112-774-11 s CAP, CERAMIC 470PF X7R 1005...
  • Page 95 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C613 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C699 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C620 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C704 1-114-325-11 s CAP, CERAMIC 0.1MF X7R 1608 3-15 VPL-FH30...
  • Page 96 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C763 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C833 1-100-909-11 s CAP, CERAMIC 10MF X6S 2012 C764 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C834 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 3-16 VPL-FH30...
  • Page 97 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1041 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1352 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1042 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1353 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 3-17 VPL-FH30...
  • Page 98 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1473 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1543 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1474 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1544 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 3-18 VPL-FH30...
  • Page 99 1-100-911-11 s CAP, CERAMIC 4.7MF X7R (3216) C1610 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1737 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 C1611 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1738 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 3-19 VPL-FH30...
  • Page 100 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C1917 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C3619 1-114-130-11 s CAP, CERAMIC 1MF X6S 1005 C1918 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C3620 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 3-20 VPL-FH30...
  • Page 101 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C4506 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C4565 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C4507 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 C4566 1-100-916-11 s CAP, CERAMIC 0.1MF X7R 1005 3-21 VPL-FH30...
  • Page 102 1-400-180-21 s INDUCTOR, EMI FERRITE (1608) FB205 1-400-331-21 s FERRITE, EMI (SMD) (1005) FB904 1-400-331-21 s FERRITE, EMI (SMD) (1005) FB206 1-400-331-21 s FERRITE, EMI (SMD) (1005) FB1002 1-400-180-21 s INDUCTOR, EMI FERRITE (1608) FB1003 1-400-180-21 s INDUCTOR, EMI FERRITE (1608) 3-22 VPL-FH30...
  • Page 103 1-400-180-21 s INDUCTOR, EMI FERRITE (1608) FB1808 1-400-331-21 s FERRITE, EMI (SMD) (1005) IC1010 6-708-762-01 s IC PQ200WNA1ZPH FB1901 1-400-331-21 s FERRITE, EMI (SMD) (1005) IC1011 6-706-487-01 s IC TC7SH08FU FB1902 1-400-331-21 s FERRITE, EMI (SMD) (1005) IC1012 6-706-487-01 s IC TC7SH08FU 3-23 VPL-FH30...
  • Page 104 1-218-929-81 s RES, CHIP 10 Q802 6-550-180-01 s TRANSISTOR SSM6N16FE(TPLR3) R248 1-218-965-81 s RES, CHIP 10K 1005 Q1601 8-729-045-93 o TRANSISTOR IMZ4T108 R249 1-218-965-81 s RES, CHIP 10K 1005 Q1603 8-729-045-93 o TRANSISTOR IMZ4T108 R251 1-218-965-81 s RES, CHIP 10K 1005 3-24 VPL-FH30...
  • Page 105 1-218-965-81 s RES, CHIP 10K 1005 R430 1-218-933-81 s RES, CHIP 22 R354 1-218-965-81 s RES, CHIP 10K 1005 R431 1-218-933-81 s RES, CHIP 22 R358 1-218-965-81 s RES, CHIP 10K 1005 R432 1-218-933-81 s RES, CHIP 22 3-25 VPL-FH30...
  • Page 106 1-218-965-81 s RES, CHIP 10K 1005 R489 1-218-941-81 s RES, CHIP 100 R569 1-218-990-81 s CONDUCTOR, CHIP (1005) R490 1-218-941-81 s RES, CHIP 100 R570 1-218-965-81 s RES, CHIP 10K 1005 R491 1-218-941-81 s RES, CHIP 100 R571 1-218-990-81 s CONDUCTOR, CHIP (1005) 3-26 VPL-FH30...
  • Page 107 1-218-990-81 s CONDUCTOR, CHIP (1005) R917 1-218-989-81 s RES, CHIP 1M R714 1-211-985-91 s RES, CHIP 47 (1608) R918 1-218-965-81 s RES, CHIP 10K 1005 R716 1-211-985-91 s RES, CHIP 47 (1608) R919 1-218-965-81 s RES, CHIP 10K 1005 3-27 VPL-FH30...
  • Page 108 1-218-965-81 s RES, CHIP 10K 1005 R1047 1-216-864-91 s CONDUCTOR, CHIP (1608) R1238 1-218-933-81 s RES, CHIP 22 R1048 1-216-864-91 s CONDUCTOR, CHIP (1608) R1239 1-218-933-81 s RES, CHIP 22 R1049 1-216-864-91 s CONDUCTOR, CHIP (1608) R1240 1-218-933-81 s RES, CHIP 22 3-28 VPL-FH30...
  • Page 109 1-208-887-81 s RES, CHIP 1.0K (1005) R1657 1-218-965-81 s RES, CHIP 10K 1005 R1316 1-208-869-81 s RES, CHIP 180 (1005) R1658 1-218-990-81 s CONDUCTOR, CHIP (1005) R1317 1-208-869-81 s RES, CHIP 180 (1005) R1659 1-218-990-81 s CONDUCTOR, CHIP (1005) 3-29 VPL-FH30...
  • Page 110 1-218-990-81 s CONDUCTOR, CHIP (1005) R1917 1-208-863-81 s RES, CHIP 100 (1005) R1810 1-218-929-81 s RES, CHIP 10 R1918 1-208-863-81 s RES, CHIP 100 (1005) R1811 1-218-990-81 s CONDUCTOR, CHIP (1005) R1919 1-208-863-81 s RES, CHIP 100 (1005) 3-30 VPL-FH30...
  • Page 111 1-218-941-81 s RES, CHIP 100 RB1315 1-234-372-21 s RES, NETWORK 100 (1005X4) R3415 1-218-941-81 s RES, CHIP 100 RB1316 1-234-372-21 s RES, NETWORK 100 (1005X4) R3416 1-218-941-81 s RES, CHIP 100 R3417 1-218-941-81 s RES, CHIP 100 T1901 1-445-028-11 s TRANSFORMER, PULSE 3-31 VPL-FH30...
  • Page 112 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 C2657 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 C2658 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 C2660 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 C2661 1-114-334-11 s CAP, CERAMIC 10MF X7R 3225 3-32 VPL-FH30...
  • Page 113 1-469-379-21 s FERRITE, EMI (SMD) (2012) R2528 1-218-969-81 s RES, CHIP 22K FB2625 1-469-379-21 s FERRITE, EMI (SMD) (2012) R2529 1-218-961-81 s RES, CHIP 4.7K R2530 1-218-973-81 s RES, CHIP 47K IC2501 8-759-338-95 s IC NJM2903V(TE2) R2531 1-218-973-81 s RES, CHIP 47K 3-33 VPL-FH30...
  • Page 114 1-218-965-81 s RES, CHIP 10K 1005 R2656 1-218-969-81 s RES, CHIP 22K R2657 1-218-969-81 s RES, CHIP 22K R2658 1-218-953-81 s RES, CHIP 1.0K R2659 1-208-935-81 s RES, CHIP 100K (1005) R2660 1-218-965-81 s RES, CHIP 10K 1005 3-34 VPL-FH30...
  • Page 115 1-802-090-21 s VARISTOR, CHIP 1-218-960-81 s RES, CHIP 3.9K 1-218-945-81 s RES, CHIP 220 1-218-960-81 s RES, CHIP 3.9K 1-218-937-81 s RES, CHIP 47 1-218-941-81 s RES, CHIP 100 VDR31 1-802-090-21 s VARISTOR, CHIP VDR32 1-802-090-21 s VARISTOR, CHIP 3-35 VPL-FH30...
  • Page 116 Ref. No. or Q'ty Part No. SP Description or Q'ty Part No. SP Description A-1813-094-A s MOUNTED CIRCUIT BOARD, QA (VPL-FH30) C2201 1-100-055-11 s CAP, CHIP CERAMIC 22MF B 3225 A-1823-662-A s MOUNTED CIRCUIT BOARD, QA (VPL-F400H) C2202 1-100-055-11 s CAP, CHIP CERAMIC 22MF B 3225 C2203 1-112-777-11 s CAP, CERAMIC 0.01MF X7R 1005...
  • Page 117 1-457-685-11 o COMMON MODE CHOKE COIL R2018 1-208-911-81 s RES, CHIP 10K (1005) R2019 1-208-923-81 s RES, CHIP 33K (1005) L2104 1-457-685-11 o COMMON MODE CHOKE COIL R2020 1-216-811-91 s RES, CHIP 150 (1608) L2201 1-469-553-21 s INDUCTOR, CHIP 4.7UH (LB2016) 3-37 VPL-FH30...
  • Page 118 1-218-941-81 s RES, CHIP 100 R2146 1-218-957-81 s RES, CHIP 2.2K R2234 1-218-941-81 s RES, CHIP 100 R2147 1-218-957-81 s RES, CHIP 2.2K R2235 1-218-941-81 s RES, CHIP 100 R2148 1-218-937-81 s RES, CHIP 47 R2236 1-218-941-81 s RES, CHIP 100 3-38 VPL-FH30...
  • Page 119 J2704 1-566-822-21 s JACK VDR8 1-802-090-21 s VARISTOR, CHIP VDR18 6-712-886-01 s IC RCLAMP0524J.TCT L2701 1-469-553-21 s INDUCTOR, CHIP 4.7UH (LB2016) VDR19 6-712-886-01 s IC RCLAMP0524J.TCT Q2701 8-729-013-26 s TRANSISTOR HN1C03FU-TE85R R2701 1-216-840-91 s RES, CHIP 39K (1608) 3-39 VPL-FH30...
  • Page 120 6-552-444-01 s TR DRC5144E0L Q2804 6-552-407-01 s TR DSA500100L R2801 1-216-811-91 s RES, CHIP 150 (1608) R2802 1-218-990-81 s CONDUCTOR, CHIP (1005) R2803 1-218-990-81 s CONDUCTOR, CHIP (1005) R2804 1-218-990-81 s CONDUCTOR, CHIP (1005) R2805 1-218-990-81 s CONDUCTOR, CHIP (1005) 3-40 VPL-FH30...
  • Page 121 1-218-953-81 s RES, CHIP 1.0K R2838 1-218-941-81 s RES, CHIP 100 CN71 1-820-297-11 o HEADER ASSEMBLY (PRINT PWB) 3P R2839 1-218-977-81 s RES, CHIP 100K R2840 1-218-973-81 s RES, CHIP 47K 1-570-504-12 s SWITCH, MICRO TH71 1-804-949-11 s THERMISTOR, NTC (SMD) 3-41 VPL-FH30...

  • Page 122: Packing Materials & Supplied Accessories

    3-4. Packing Materials & Supplied Accessories ---------------------------------------- PACKING MATERIALS & SUPPLIED ACCESSORIES ---------------------------------------- *1:[VPL-FH30(SY)] *2:[VPL-F400H(CN)] Ref. No. or Q'ty Part No. SP Description 1-489-092-11 s REMOTE COMMANDER (RM-PJ19) 1pc *2 1-830-860-11 s AC POWER-SUPPLY CORD (250V, 10A) 1pc *1 1-831-498-11 s POWER-SUPPLY CORD SET (For J)

  • Page 123: Block Diagrams

    Section 4 Block Diagrams VPL-FH30...
  • Page 124 CN302 CN202 100BASE-TX CN2801 IC2802 CN2803 232C RS-232C TRANSCEIVER Tx/Rx CN31 CN51 CN11 IC31 IC51 J2801 Tx/Rx SIRCS SIRCS IR_OUT S11-S15 PLUG IN POWER SIRCS LAMP COVER CONTROL S IC2801 POWER 5V POWER D31, D32 TH51 LIMITER LAMP TEMP VPL-FH30...

  • Page 125: Overall

    FOR LAMP OUT FAN F FAN E CN2603 FOR POWER SUPPLY LAMP CONTROL FAN F FOR BALLAST CN301 CN303 CN103 CN104 TH FUSE CN71 CN12 CN13 CN14 FILTER BALLAST COVER CN11 TH71 TEMP AC-DC POWER SUPPLY AC INLET LAMP Overall VPL-FH30...

  • Page 127: Schematic Diagrams

    Section 5 Schematic Diagrams Index Board name Page 5-22 5-24 5-29 5-30 Frame Wiring 5-31  印の部品には，秘密情報が含まれています。 修理の際は，指示に従った対応を行ってください。 The components identifi ed by mark contain confi dential information. Strictly follow the instructions whenever the components are repaired and/or replaced. VPL-FH30...
  • Page 128 LAMP_LED JL37 FB31 600ohm 1005 BLM15AG601SN CN31 To C LAMP/COVER POWER/STANDBY JL71 SML-522MU8WT86PQ SML-D12U8WT86 POWER/STANDBY FILT_COVER LAMP/COVER EXT_TEMP JL72 1/16W 1/16W 1/16W TH71 CN71 3.9k 3.9k 3.9k DSC500100L DSC500100L DSC500100L 1/16W 1/16W 1/16W BOARD NO. 1-884-093-11 BOARD NO. 1-884-091-11 VPL-FH30...
  • Page 129 FB101 600ohm JL122 1005 BLM15AG601SN SUBD5V AU_D_L AU_D_L (006) LAMP_25 SUBD5V AU_D_L CN105 CVBS (007) AU_D_R (006) CVBS AU_D_R CVBS AU_D_R TP101 TP107 CN101 CN102 TP102 TP108 TP103 TP109 TP104 TP110 TP105 TP111 TP106 TP112 C (1/19) BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 130 IC207 R201 MODE ECO3.3V TC74LCX125FT(EKJ) RESET UART SW (A & D) C213 NW3.3V RESET R207 R219 CN203 1/16W 1/16W UART_DEBUG (002) ROUT_RS U1_TX_NW (019) NW3.3V R220 TIN_RS 1/16W R211 U1_RX_NW (019) 1/16W C (2/19) (001) 232C BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 131 R365 OUT Y IC306 R1EX24256ASAS0A R334 R339 EEP ROM MAIN R361 R370 C303 0.22 1/16W (001) POWER_ON 1608 NVM_WP (001) R362 1/16W R363 R335 R340 1/16W C316 R338 R391 EEP ROM MAIN 1/16W C (3/19) 1608 BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 132 VSSQ VDDQ C421 C423 C425 C428 C430 C432 C434 C436 VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ IC401 IC402 C (4/19) W9725G6JB-25-ER25 W9725G6JB-25-ER25 DDR2 DDR2 BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 133 R562 R565 POWER DETECTION POWER DETECTION POWER DETECTION 4.7k 4.7k 4.7k (001,008,010) POWER_DELAY Q502 R511 1/16W 1/16W 1/16W 1/16W 1/16W 1/16W DRC5144E0L 1/16W 0.5% Q501 DRC5144E0L C (5/19) C510 R512 2.2k 1/16W 0.5% (005,008,010) POWER_GOOD 2012 BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 134 Q602 R636 R618 DSA500100L 1/16W Q605 R620 R635 R643 1/16W AK30 Q601 CL612 DRC5144E0L AUDIO_CONT (001) R647 R648 FB605 R637 600ohm Q604 R644 (4/9) 1005 BLM15AG601SN IC300 FB609 PW980G BLM15AG601SN A-5V ADC&CDEC&SCAN CONV. A-5V C (6/19) BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 135 VDDCP REFBGVP3V3 C734 C747 FB708 VSSCP 6.3V REFBGVGND 6.3V 600ohm 1005 C766 2012 3216 BLM15AG601SN L708 10uH AVDDP (5/9) C735 6.3V AVSSP IC300 2012 C721 C728 PW980G ADC&CDEC&SCAN CONV. (1/9) IC300 PW980G ADC&CDEC&SCAN CONV. C (7/19) BOARD NO. 1-884-085-11 VPL-FH30...
  • Page 136 C845 C846 6.3V 6.3V R845 R841 1/16W 2012 2012 2012 IC803 R831 2012 TPS54325PWPR R836 R825 AD3.3V REG 1/16W 1/16W 0.5% R842 R843 C841 C842 0.022 1608 CL807 C (8/19) (001,005,010) POWER_DELAY POWER_GOOD (005,010) BOARD NO. 1-884-085-11 5-10 5-10 VPL-FH30...
  • Page 137 AJ10 USB0_VDDA FB902 220ohm AH12 1608 MPZ1608S221AT USB_VSS C905 C907 C909 USB_VSS AG12 USB1_VDDA AJ12 USB1_VDDA FB903 220ohm 1608 AK10 USB_VSS MPZ1608S221AT C906 C908 C910 AK12 USB_VSS (8/9) IC300 PW980G ADC&CDEC&SCAN CONV. C (9/19) BOARD NO. 1-884-085-11 5-11 5-11 VPL-FH30...
  • Page 138 R1018 C1031 C1032 DELAY 1/16W 6.3V 6.3V R1017 2012 2012 CL1004 IC1006 R1022 (003) 15V_B_CONT TPS54325PWPR R1064 1.0V_G REG R1025 C1016 1/16W C1026 C1027 C1020 C1021 0.5% 0.01 4700p 1608 C (10/19) POWER_GOOD (005,008,010) BOARD NO. 1-884-085-11 5-12 5-12 VPL-FH30...
  • Page 139 3D GAMMA & TG 1/16W (9/9) SUBD3.3V IC300 PW980G R1102 R1121 0 ADC&CDEC&SCAN CONV. 1/16W FID_IN0 R1122 0 FID_IN1 R1123 0 FID_IN2 R1124 0 FIDRST ( 2/13) IC1100 CXD3549GB 3D GAMMA & TG C (11/19) BOARD NO. 1-884-085-11 5-13 5-13 VPL-FH30...
  • Page 140 R4203 0 PDR_SCL ( 3/13) SHD_SCL R4204 0 PDR_SDA IC1100 SHD_SDA CXD3549GB 3D GAMMA & TG SLV ADD:0x74 ( 4/13) IC1100 CXD3549GB 3D GAMMA & TG TX_R1 (016) C (12/19) TX_G1 (017) TX_B1 (018) BOARD NO. 1-884-085-11 5-14 5-14 VPL-FH30...
  • Page 141 C1311 AA31 AJ35 MRDRVUP_F MDQ63_F DDR2 MEMORY DDR2 MEMORY R1317 1/16W 0.5% AM20 MDUMMY0_F AM25 MDUMMY1_F AJ32 MDUMMY2_F AD32 MDUMMY3_F C1309 C1310 C (13/19) ( 5/13) C1305 C1308 IC1100 CXD3549GB BOARD NO. 1-884-085-11 3D GAMMA & TG 5-15 5-15 VPL-FH30...
  • Page 142 GNDK ( 8/13) VCCK GNDK IC1100 CXD3549GB C1489 VCCK GNDK 3D GAMMA & TG C1490 VCCK GNDK C1491 VCCK GNDK 16V C1492 VCCK GNDK ( 7/13) C (14/19) IC1100 CXD3549GB 3D GAMMA & TG BOARD NO. 1-884-085-11 5-16 5-16 VPL-FH30...
  • Page 143 GND25AD_TX GND25A_LVDS_RX GND10A_LVDS_RX GND25AD_TX GND25AD_TX (10/13) GND25A_LVDS_RX GND25A_LVDS_RX GND25AD_TX GND25AD_TX IC1100 GND25A_LVDS_RX GND25A_LVDS_RX CXD3549GB 3D GAMMA & TG (12/13) (11/13) IC1100 CXD3549GB C (15/19) IC1100 3D GAMMA & TG CXD3549GB 3D GAMMA & TG BOARD NO. 1-884-085-11 5-17 5-17 VPL-FH30...
  • Page 144 0.1 25V GCFB 3.3V_G (010) CNMON_R R1651 FB1605 R1659 600ohm 1/16W 1005 BLM15AG601SN CN1601 IC1602 R1652 TC7SH08FU(T5RSOYJF) 2.7k GCFB BUFFER 1/16W 0.5% IN B R1653 IN A CL1602 (012) GCFB_R OUT Y C1635 C (16/19) BOARD NO. 1-884-085-11 5-18 5-18 VPL-FH30...
  • Page 145 1608 GCFB 3.3V_G (010) CNMON_G FB1705 R1751 R1759 600ohm 1005 1/16W BLM15AG601SN CN1701 IC1702 TC7SH08FU(T5RSOYJF) R1752 GCFB BUFFER 2.7k 1/16W 0.5% IN B R1753 IN A CL1702 (012) GCFB_G OUT Y C1735 C (17/19) BOARD NO. 1-884-085-11 5-19 5-19 VPL-FH30...
  • Page 146 1608 GCFB 3.3V_G (010) CNMON_B R1851 FB1805 R1859 600ohm 1/16W 1005 BLM15AG601SN CN1801 IC1802 TC7SH08FU(T5RSOYJF) R1852 GCFB BUFFER 2.7k 1/16W 0.5% IN B R1853 IN A CL1802 (012) GCFB_B OUT Y C1835 C (18/19) BOARD NO. 1-884-085-11 5-20 5-20 VPL-FH30...
  • Page 147 1005 U0_TX_NW (002) BLM15AG601SN nTRST R1985 100 1/16W U1_RX_NW (002) R1908 2.2k U1_TX_NW (002) 1/16W 0.5% JL1902 CHG_STATUS_NW (003) R1981 100 CN1901 1/16W FW_WRITE_NW (002) NETWORK_SW_NW (002) U0_Rx To T3 C (19/19) U0_Tx CN1902 BOARD NO. 1-884-085-11 5-21 5-21 VPL-FH30...
  • Page 148 C2505 C2508 +IN2 +IN2 1/16W 1/16W C2501 R2510 C2504 R2520 C2507 C2506 1/16W 1/16W 2012 2012 R2508 R2504 1/16W 1/16W POWER_ON_2 (002) Q2502 DRC5144E0L Q2501 DRC5144E0L R2522 1/16W POWER_ON_3 (002) Q2503 GB (1/2) DRC5144E0L BOARD NO. 1-884-086-11 5-22 5-22 VPL-FH30...
  • Page 149 R2628 0.01 C2635 C2621 1/16W C2640 FB2606 0.5% 0.01 60ohm 2012 2012 R2629 BLM21PG600SN1D 1608 1/16W C2622 0.5% R2623 R2635 R2649 1/16W 1.8k 2.2k GB (2/2) 3225 R2630 1/16W 1/16W 0.5% 0.5% 1/16W 0.5% BOARD NO. 1-884-086-11 5-23 5-23 VPL-FH30...
  • Page 150 C2030 0.1 C2010 0.01 1608 J2001 C2020 VDR5 PROTECT VDR6 PROTECT C2011 R2017 R2022 D2011 1/10W 1/10W DZ2S05600K8 D2012 3225 DZ2S05600K8 1608 1608 D2004 DA3J101F0L R2003 PROTECT C2002 R2001 C2003 0.01 1/16W 1/16W QA (1/5) BOARD NO. 1-884-087-11 5-24 5-24 VPL-FH30...
  • Page 151 R2184 SSM3K16FV(TL3SON) HOT PLUG DETECT 100k VDR11 VDR12 1/16W 1/16W PROTECT PROTECT D3.3V CHIP CHIP CL2103 (005) HDMI_HPD2 R2117 1/16W HDMI_HOTPLUG (002,005) CHIP Q2102 R2107 DSC500100L R2106 4.7k 1/16W QA (2/5) 1/16W CHIP CHIP BOARD NO. 1-884-087-11 5-25 5-25 VPL-FH30...
  • Page 152 R2206 Q2202 IC2204 1/16W DSC500100L SN75157PS-ELL2000 BUFF COMP C2214 JL2201 1608 R2204 (004,005) 1/16W R2235 R2220 1/16W R2212 120k 1/16W JL2202 1/16W R2224 (004,005) R2236 1/16W 1/16W Q2206 DSA500100L PEAK HOLD QA (3/5) C2212 BOARD NO. 1-884-087-11 5-26 5-26 VPL-FH30...
  • Page 153 TC74VHC153FK(EL) 600ohm C2301 PROTECT SYNC SELECT 1005 BLM15AG601SN OUT_H R2325 MON_OUT_EN (004,005) IC2303 SN75453BPSR 1/16W C2313 ACT_SEL1 (004,005) SYNC BUFF (003,005) D2305 DA3J101F0L (003,005) PROTECT OUT_V R2301 R2326 1/16W R2302 1/16W 1/16W QA (4/5) BOARD NO. 1-884-087-11 5-27 5-27 VPL-FH30...
  • Page 154 1/16W SCLIN SDAIN R2410 R2414 R2412 CHIP CHIP (005) ACT_SEL0 C2403 C2404 SDA_100K SDA_100K_QB (005) SCL_100K_QB (005) (004) MON_OUT_EN R2408 R2409 C2401 R2403 R2406 R2407 1/16W 1/16W 1/16W 1/16W 1/16W (001,002,005) I2C_100K QA (5/5) BOARD NO. 1-884-087-11 5-28 5-28 VPL-FH30...
  • Page 155 R2707 68ohm R2710 JL2702 1608 BK1608LL680-T JL2707 AU_V_L R2701 R2703 C2701 1/10W 1/10W D2701 DZ2J07500L 1608 1608 2012 PROTECT JL2708 AU_V_R J2701 R2702 R2704 C2702 JL2703 1/10W 1/10W D2702 DZ2J07500L 1608 1608 2012 PROTECT BOARD NO. 1-884-088-11 5-29 5-29 VPL-FH30...
  • Page 156 1608 220ohm 1/16W PROTECT INV SW MPZ1608S221A 1608 MPZ1608S221A C2812 2012 R2833 C2809 C2811 D2809 C2806 DA3J101F0L C2818 1/16W 470p PROTECT R2834 1608 1/16W J2801 JL2801 JL2802 CONTROLS-IN JL2803 FB2803 220ohm ECO5V_ON 1608 MPZ1608S221A BOARD NO. 1-884-089-11 5-30 5-30 VPL-FH30...

  • Page 157: Frame Wiring

    SUBD5V AU_D_L AU_D_L SUBD5V SUBD5V AU_D_L AU_D_L Note: The components identified by mark contain confidential information. AU_D_R CVBS CVBS AU_D_R Strictly follow the instructions AU_D_R CVBS CVBS AU_D_R Frame Wiring whenever the components are repaired and/or replaced. 5-31 5-31 VPL-FH30...
  • Page 159 IC2610 Q2607 D2605 D2621 IC2611 Q2608 D2606 IC2612 Q2609 D2607 IC2501 Q2610 D2608 IC2503 * B-1 Q2501 Q2611 D2609 IC2504 * B-1 Q2502 Q2612 * C-1 D2610 IC2601 Q2503 Q2613 * B-1 D2611 IC2602 * A-2 Q2504 * B-2 VPL-FH30...
  • Page 160 IC1602 * C-4 IC1701 * D-5 IC1702 * D-5 IC1801 * E-4 IC1802 * E-4 IC1901 IC1902 IC1903 IC1904 IC1905 Q201 Q301 Q302 Q303 Q304 Q305 Q306 * A-4 Q501 * B-2 Q502 * B-2 Q504 Q505 -A SIDE- SUFFIX: -11 VPL-FH30...
  • Page 161 -B SIDE- SUFFIX: -11 VPL-FH30...
  • Page 162 *:B SIDE D2701 * C-2 VDR71 * D-2 D2702 * C-2 VDR72 * D-2 D2703 VDR73 * C-2 D2704 D2705 D2706 D2707 D2708 D2709 D2710 IC2701 -A SIDE- -B SIDE- IC2702 * C-2 IC2703 SUFFIX: -11 SUFFIX: -11 Q2701 VPL-FH30...
  • Page 163 IC2803 * A-2 D2802 D2808 * A-2 D2803 D2809 * A-2 Q2801 D2804 Q2802 * A-2 D2805 IC2801 Q2803 D2806 IC2802 * B-1 Q2804 -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 VPL-FH30...
  • Page 165 20 V AC range are suitable. (See Fig. A) To Exposed Metal Parts on Set 1.5 k Z 0.15 μF voltmeter (5.25V) Earth Ground Fig A. Using an AC voltmeter to check AC leakage. VPL-FH30...
  • Page 166 VPL-FH30 (SY) Printed in Japan Sony Corporation VPL-F400H (CN) J, E 2011. 1 32 9-968-816-01 ©2011...

This manual is also suitable for:

Vpl-f400h

Table of Contents
