Sony VPLFH31/B Specification Sheet

Solid Installation Projector
VPL-FH31

Key Features

• 4,300 lumens (ISO 21118)
• Native WUXGA (1,920 x 1,200) resolution
• BrightEra
®
Technology with Long Lasting Optics™
• Flexible 1.6x manual zoom standard lens
• Vertical +60%, Horizontal +/-32% Lens Shift
• Advanced geometric correction
• Edge blending
• Portrait mode
• Picture by picture function
• Network control and monitoring
• DICOM GSDF simulation gamma mode
• Synchronized lamp and filter maintenance cycle
• Rich interface terminals including 1xDVI-D and 1xHDMI®
• Clean-looking back design (available in white or black color)
Dimensions (Front)
Dimensions (Bottom)

Optional Lenses

VPLL-Z1024
Throw Ratio 2.34 to 3.19
Aperture f/2.00 to 2.30
Lens Shift
Mass
Lens Adapter
* The value is average.
1
* The figures are expected maintenance time and not guaranteed.
2
They will depend on the environment or how the projector is used.
* Works as an audio switcher function. Output from a selected channel, not available in standby.
3
.
© 2012 Sony Corporation. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specifications are subject to change without notice. Sony, BrightEra, Bright
Era Technology with Long Lasting Optics, and the Sony make.believe logo are trademarks of Sony. The HDMI logo and HDMI High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries. All other trademarks are the trademarks of their respective.
Unit: mm (inches)
VPLL-Z1032
3.18 to 4.84
f/2.00 to 2.40
Vertical : +60%/-0%
Horizontal : +/- 32%
Approx. 1.1kg / 2 lbs. 7oz.
PK-F30LA1
WUXGA/4,300lm
Optical
Light Output /
Color Light Output
LCD Panels
Panel Display Resolution
Contrast Ratio
Light source
2
Lamp replacement time*
Filter cleaning cycle*
2
Zoom / Focus Approx. 1.6x manual zoom / Manual focus
Projection Lens Lens Shift
Throw Ratio
Screen Size
Interface
INPUT A
INPUT B
INPUT C
Computer and
INPUT D
Video
Input/Output
S VIDEO IN
VIDEO IN
Monitor OUT Mini D-sub 15-pin (from INPUT A and B)
Audio OUT
RS-232C
Control Signal
LAN
Input/Output
Control S
General
Scanning Frequency
Computer
signal input
Display
Resolution
Video signal
input
Color System
Power Requirements
Power Consumption
Standby Mode
Power Consumption
Dimensions (W x H x D)
Mass
Optional Accessories
Replacement Lamp
Projection Lens Adapter
Replacement Filter
Replacement Remote
Connector Panels
For more information, visit: www.sony.com/projectors
4300 lumens (high mode)
3400 lumens (Std lamp mode)
0.76" x 3 BrightEra LCD Panel
WUXGA (1920 x 1200 dots)
2,000:1 (Full white/full black) *
High-pressure mercury lamp 275 W type
3000H(High) / 4000H(Standard)
Max. 15000H
Same time as the lamp replacement is recommended
Manual, Vertical +60%/-0%
Horizontal +/- 32%
1.39:1 to 2.23:1
40" to 600"
5BNC (RGB / Y Pb Pr)
Audio : Stereo mini jack
Mini D-sub 15-pin (RGB)
Audio : Stereo mini jack (shared with INPUT C)
DVI-D (HDCP support)
Audio : Stereo mini jack (shared with INPUT B)
HDMI (Digital RGB/Y Pb Pr, Digital Audio)
Mini DIN-4pin
Audio : Pin jack x2 (shared with VIDEO IN)
Pin Jack
Audio : Pin jack x2 (shared with S VIDEO IN)
Stereo mini jack (variable out) *
D-sub 9 pin
RJ45, 10BASE-T/100BASE-TX
Stereo mini jack, Plug in power DC5V
H: 15 to 92kHz, V: 48 to 92Hz
Maximum display resolution :
1920x1200 dots
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p,
576/50p, 720/60p, 720/50p, 1080/60i,
1080/50i, 1080/60p, 1080/50p, 1080/24p
NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M,
PAL-N, PAL60
AC 100V to 240V, 4A to 1.6A, 50Hz/60Hz
400W (AC 100V-120V)
380W (AC 220V-240V)
9.2W (Std) / 0.15W (Low) (AC 100V-120V)
10.4W (Std) / 0.3W (Low) (AC 220V-240V)
390 x 148 x 477 mm
15 11/32 x 5 13/16 x 18 25/32"
8.2kg / 18 lb 1oz
LMP-F272
PK-F30LA1
4-172-386-01 (Top) / 4-172-387-01 (Bottom)
(filters are cleanable)
1-489-092-11 (RM-PJ19)
1
3
10/12
