Specifications - Altronix CommBatt1 Installation Manual

Altronix CommBatt1 is an in-building power and battery backup solution for emergency response radio coverage
system. Designed and engineered to meet NFPA 1225 codes providing integrators and consultants with a BDA
power and backup option.
Agency Listings:
• UL2524 Standard for In-building 2-Way
Emergency Radio Communication
Enhancement Systems
• UL864
Standard for Control Units and
Accessories for Fire Alarm Systems.
• CAN/ULC-S527 Fourth Edition, 2019
Control Units for Fire Alarm Systems.
Input:
• 115VAC-220VAC 50/60Hz, 2A.
• Input Fuse Rating: 5A/250V.
Output:
• 12VDC or 24VDC regulated output.
• UL2524 Specifications:
24V @ 5.5A total or 12V @ 9A total current.
• UL864/ULCS527 Specifications:
24V: 3.5A standby, 6A Alarm
12V: 3.5A standby, 12A alarm.
Supervision (Form "C" contacts relays):
• AC: Failure/Brownout.
• Battery:
Low Battery/Battery Presence/Battery fail.
• Component Trouble:
Critical Component Failure.
• Ground Fault
• Charger Circuit Failure
• FACP Reporting
- 2 -
Overview:

Specifications:

Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Up to four (4) 55AH batteries in series/parallel for 24V,
One (1) to three (3) in parallel for 12V.
• 12AH option for UL864.
• Automatic switch over to stand-by battery when
AC fails.
• Battery Fuse Rating: 20A/32V.
• Maximum charge current 3A for 12V and 2A for 24V.
Visual Indicators (
• AC High Side LED
• AC Low Side LED
• Heartbeat LED
• Battery LED
• Charger LED
• Ground Fault LED
• Component Fail LED
Enclosure Dimensions:
26" x 19.7" x 8" (660.5mm x 500mm x 203mm).
See LED Diagnostics Table)
CommBatt1 Installation Guide
:
