CommBatt1
BDA Power and Battery Charger System
UL2524
CommBatt1F
BDA Power and Battery Charger System
UL2524, UL864, CAN/ULC-S527
Installation Guide
More than just power.
Rev. 031424
TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CommBatt1F and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix CommBatt1F

Summary of Contents for Altronix CommBatt1F

  • Page 1 CommBatt1 BDA Power and Battery Charger System UL2524 CommBatt1F BDA Power and Battery Charger System UL2524, UL864, CAN/ULC-S527 Installation Guide More than just power. Rev. 031424 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...

  • Page 2: Specifications

    Overview: Altronix CommBatt1(F) is an in-building power and battery backup solution for emergency response radio coverage system. Designed and engineered to meet NFPA 1225 codes providing integrators and consultants with a BDA power and backup option. Specifications: Agency Listings: Battery Backup: CommBatt1F: •...
  • Page 3 Stand-by Specifications: UL864, CAN/ULC-S527 Compliance (CommBatt1F only): Output Stand-by/Alarm Current Time 24V: 12VDC/55AH Battery 3.5A/6A @24V 24 hours + 30 minutes of alarm (4 in series/parallel). Total capacity 110AH. 12V: 12VDC/55AH Battery (2 in parallel). 3.5A/12A@12V 24 hours + 30 minutes of alarm Total capacity 110AH.

  • Page 4: Power Supply Output Specifications

    7. Connect Altronix Annunciator to AC FAIL, Low Bat ,Charger Fail, Component Fail and, optionally, Ground Fault (CommBatt1F only, Fig. 2a, pg. 6) supervisory relay outputs. If end of line resistor is used it has to be connected between EOL and corresponding [Com] terminals with field wiring connected between NC and NO teminals.

  • Page 5: Led Diagnostics

    LED Diagnostics: Ground Fault* (CommBatt1F only) (Fig. 2d, pg. 6) Power Supply Status Solid No ground fault detected 0.5 sec. Blink Ground fault Component Failure (Fig. 2d, pg. 6) Power Supply Status Solid No component failure detected 0.5 sec. Blink Critical Component Failure Battery (Fig.
  • Page 6 0.6A maximum. Voltage corresponds to the output voltage selected. G Fault NO NC C EOL* Indicates Ground Fault (CommBatt1F only) on DC output or AUX output. 330 Ohm maximum (Fig. 2f, pg. 6) impedance. Relay Contacts are Form ”C”. Contact rating 0.4A/28VDC. 0.6 power factor.

  • Page 7: Maintenance

    Terminal Identification (Battery Interface Module): Terminal Legend Function/Description + – Factory connected to power supply board. 12V Section Parallel Connection Connect 1-4 12V batteries for 12V output. Battery1 through Battery4 Up to 4 batteries can be connected to achieve more capacity. [Positive] [Negative] 24V Section Facilitates series/parallel connection of 12V batteries for 24V backup.
  • Page 8 Fig. 4 - CommBatt1(F) Wiring Diagram Supervisory Circuit 115/230VAC Input (power-limited) (non power-limited) 5A/250V Heartbeat Power Down Before Switching Brooklyn, NY Altronix Corp. + BAT - + OUT - www.altronix.com Output (non power-limited) Battery 1 Battery 2 Battery 3 Battery 4...
  • Page 9 Two (2) 12V/55AH batteries can fit in the CommBatt1(F) enclosure. If additinal batteries are needed, separate enclosure is to be employed. Altronix part Number: CommBattEXP Fig. 5 - CommBatt1(F) with Optional UL Listed CommBattEXP Expansion Battery Enclosure 5A/250V Heartbeat Power Down...

  • Page 10: Termination Resistor

    - [Low Bat] connects to [Low Battery] input - [CHRG Fail] connects to [Charger Fail] input - [COMP Fail] connects to [Component Fail] input - [G Fault] connects to [Ground Fault (CommBatt1F only)] input. See ANC1BBU Installation Guide Doc No. IIANC1BBU for more information. RS485 Connection: For distances up to 1,500 ft.
  • Page 11 Notes: CommBatt1(F) Installation Guide - 11 -...
  • Page 12 5.825” (148mm) 8” (203mm) 1/4 Turn Lock 17.85” (454mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
