Altronix LPS3WP outdoor linear power supply/chargers are specifically designed to provide the power needed
by the most demanding security and access control applications . Unit's unique NEMA 4/IP65 rated enclosure
allows installation right at the outdoor equipment it is designed to power .

LPS3WP Series Power Supply Configuration Reference Chart:

Altronix
Model Number
LPS3WP12
LPS3WP24
Input:
• 115VAC 50/60Hz .
Output:
LPS3WP12: 12VDC
LPS3WP24: 24VDC
• 2 .5A continuous supply current .
• Filtered and electronically regulated output .
• Short circuit and thermal overload protection .
The LPS3WP should be installed in accordance with The National Electrical Code and all applicable Local
Regulations .
1 . Remove back plate inside enclosure by removing the four (4) mounting screws (Fig. 2, pg. 5) .
2 . Mark and drill desired knockouts on the enclosure to facilitate wiring (Fig. 1, pg. 4).
3 . Secure back plate inside enclosure with the four (4) mounting screws (Fig. 2, pg. 5) .
4 . Unit can be wall or pole mounted .
Wall Mount:
- Mark and drill holes to line up with the top and bottom holes of the enclosure flange .
- Secure enclosure with appropriate fasteners (Fig. 3, pg. 7) .
Pole Mount:
- Refer to the detailed pole mount instructions (pg. 7).
Secure enclosure to earth ground .
5 . Connect AC power to the black and white flying leads of the transformer (Fig. 2, pg. 5) . Use 18 AWG or
larger for all power connections (Battery, DC output) .
6 . Measure output voltage at the terminals marked [
This helps avoiding potential damage .
7 . Connect devices to be powered to the terminals marked [
Note: Power supplies mounted in weatherproof enclosures should be derated by approximately 50% to
account for the extreme environmental conditions .
8 . Connect optional stand-by battery to the terminals marked [
(A separate enclosure is needed for batteries). (Fig. 2, pg. 5) .
Note: When batteries are not used, a loss of AC will result in a loss of output voltage .
LPS3WP Series
Output Current
12VDC
24VDC

Specifications:

Installation Instructions:

Overview:

Output Rating
2 .5A
2 .5A
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries .
• Maximum charge current 500mA .
• Automatic switch over to stand-by battery when
AC fails (zero voltage drop) .
• Fused battery protection .
Visual Indicators:
• AC/DC power LED indicator .
Enclosure Dimensions (H x W x D):
12" x 8" x 6" (304 .8mm x 203 .2mm x 152 .4mm) .
DC +] before connecting devices .
–
DC +], carefully observing polarity (Fig. 2, pg. 5).
–
BAT +] . Battery leads included .
–
Maximum
Charge Current
0 .5A
0 .5A
115VAC, 50/60Hz
Input Current
0 .5A
0 .95A
