We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
These instructions apply only to the destination countries listed on the appliance's data plate.
This is a class 3 built-in hob.

PRECAUTIONS

General safety instructions

Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
22 - PRECAUTIONS
22
22
25
26
26
26
Cleaning the hob
27
27
27
27
27
28
28
28
29
29
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
29
29
29
31
31
31
32
32
32
35
35
36
37
38
39
91477A696/B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS9062 and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg PS9062

Summary of Contents for Smeg PS9062

  • Page 1: Table Of Contents

    We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com These instructions apply only to the destination countries listed on the appliance's data plate.
  • Page 2 unsupervised children. objects (cutlery or utensils) into • Make sure that the flame- the slots in the appliance. spreader crowns are correctly • Do not use or store flammable positioned in their housings with materials near the appliance or their respective burner caps. directly underneath the hob.
  • Page 3 installed. Make sure there is SPACE HEATER. good ventilation, especially • Cooking vessels or griddle when the appliance is in use: plates should be placed inside keep the natural ventilation the perimeter of the hob. openings open or install a •...

  • Page 4: Installation

    • This appliance is not designed • Installation using a hose must to operate with external timers be carried out so that the length or with remote-control systems. of the hose does not exceed 2 • This appliance can be used up metres when fully extended for to a maximum altitude of 2,000 steel hoses and 1.5 metres for...

  • Page 5: Appliance Purpose

    • Run the power cable in the rear sufficient to provide complete part of the unit. Make sure that disconnection in category III it does not come into contact overvoltage conditions, with the lower part of the hob pursuant to installation or a built-in oven below it.

  • Page 6: Identification Plate

    Identification plate top of the pan, as the top is almost always larger than the base. The identification plate bears the technical data, • When preparing dishes with long cooking serial number and brand name of the times, you can save time and energy by appliance.

  • Page 7: Description

    DESCRIPTION General description models. 1: Left pan support grid • The accessories intended to come into 2: Right pan support grid contact with food are made of materials that 3: Central pan support grid comply with the provisions of current 4: Control panel legislation.

  • Page 8: Use

    Precautions Using the accessories Raised pan support See General safety instructions. The raised pan supports should be placed on the hob pan supports. Make sure they are A gas leak can cause an explosion. placed properly. If you smell gas or there are faults in the gas system: •...
  • Page 9 Pan diameters that can be used with the or steatite griddles. raised pan support • Never use the griddle for more than 40 minutes. Burner Pan diameter (cm) Correct positioning of the flame-spreader 28 - 32 crowns and burner caps 26 - 28 Using cookware Before lighting the hob burners, make sure that...

  • Page 10: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cleaning the hob should be cleaned regularly after use. Let them cool first. Cooking hob pan support grids Ordinary daily cleaning Remove the pan support grids and clean them in Always and only use specific products that do lukewarm water and non-abrasive detergent.

  • Page 11: What To Do If

    What to do if... • Make sure that the hob is properly ventilated and that the air inlets are The hob does not work: unobstructed. • Make sure that the hob is connected and The hob smokes: that the main switch is turned on. •...
  • Page 12 B.S. 669. Connection to LPG Use a pressure regulator and make the connection on the gas cylinder following the guidelines set out in the standards in force. The supply pressure must comply with the values indicated in the “Burner and nozzle characteristics table”.
  • Page 13 issue a certificate of conformity. Replacing nozzles Extraction using a hood Extraction without a hood Extraction with a single natural draught chimney A = External nozzle, B = Internal nozzle. Extraction with a single chimney with 1. Remove the pan supports, burner caps and extractor fan flame-spreader crowns to access the burner Extraction directly outdoors with wall- or...

  • Page 14: Gas Types And Countries

    spindle (depending on the model) until the 5. Repeat the operation on all the gas taps. correct minimum flame is achieved. Adjusting the minimum setting for LPG Tighten the screw located at the side of the cock spindle clockwise all the way. Following adjustment to a gas other than the one originally set in the factory, replace the gas setting label on the...

  • Page 15: Electrical Connection

    2 Natural Gas G20 - 25 mbar UR2 ext. UR2 int. Rated heating capacity (kW) 1.05 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (H3) (H1) Reduced flow rate (W) 1200 3 Natural Gas G25.1 - 25 mbar UR2 ext. UR2 int.

  • Page 16: Section Cut From The Countertop

    with a contact separation distance sufficient to Built-in cabinet dimensions (mm) provide complete disconnection in category III overvoltage conditions, pursuant to installation regulations. For the Australian/New Zealand market: The circuit breaker incorporated in the fixed connection must comply with AS/NZS 3000. Connection with plug and socket Make sure that the plug and socket are of the same type.

  • Page 17: Mounting

    front and rear sides of the seal must be flush Connection positions (mm) with the hole. Electrical connection Gas connection 3. Place the hob on the insulating seal and fix it to the supporting structure using the screws Mounting and fastening brackets supplied (A) so that Over built-in oven unit the hob is perfectly level.

  • Page 18: Instructions For The Installer

    base using suitable equipment. contact your local Authorised Service Centre. • Once the appliance has been installed, please explain to the user how to use it correctly. 1 Opens on bottom 2 Opens on back A min. 20 mm - max. 50 mm B max.
