INSTRUCTIONS FOR SAFETY AND USE __________________________ 28

SAFETY PRECAUTIONS _______________________________________ 30

ENVIRONMENTAL RESPONSIBILITY _____________________________ 32

POSITIONING OF THE HOB ____________________________________ 33

ELECTRICAL CONNECTION ____________________________________ 35

GAS CONNECTION ___________________________________________ 36

ADAPTATION TO DIFFERENT TYPES OF GAS _____________________ 38

FINAL OPERATIONS __________________________________________ 42

USING THE HOB______________________________________________ 45

CLEANING AND MAINTENANCE_________________________________ 48

THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES

WHOSE IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS

MANUAL.

INSTRUCTIONS FOR THE INSTALLER: these are for the qualified

technician who must carry out a suitable check of the gas system, install

the appliance, set it functioning and carry out an inspection test.

INSTRUCTIONS FOR THE USER: these contain user advice,

description of the commands and the correct procedures for cleaning

and maintenance of the appliance.

Contents

Table of Contents

Summary of Contents for Smeg AP64S3

Page 1: Table Of Contents
INSTRUCTIONS FOR SAFETY AND USE __________________________ 28 SAFETY PRECAUTIONS _______________________________________ 30 ENVIRONMENTAL RESPONSIBILITY _____________________________ 32 POSITIONING OF THE HOB ____________________________________ 33 ELECTRICAL CONNECTION ____________________________________ 35 GAS CONNECTION ___________________________________________ 36 ADAPTATION TO DIFFERENT TYPES OF GAS _____________________ 38 FINAL OPERATIONS __________________________________________ 42 USING THE HOB______________________________________________ 45 CLEANING AND MAINTENANCE_________________________________ 48 THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES...
Page 2: Instructions For Safety And Use
INSTRUCTIONS FOR SAFETY AND USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE YOU TO READ THIS MANUAL CAREFULLY BEFORE USING THE HOB.
Page 3: General Instructions
General instructions SUITABLE HEAT-PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS. DO NOT USE STEEL SPONGES OR SHARP SCRAPERS AS THEY WILL DAMAGE THE SURFACE. USE NORMAL NON-ABRASIVE PRODUCTS AND A WOODEN OR PLASTIC TOOL IF NECESSARY. RINSE THOROUGHLY AND DRY USING A SOFT CLOTH OR A MICROFIBRE CLOTH.
Page 4: Safety Precautions
General instructions SAFETY PRECAUTIONS REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE.
Page 5 General instructions IMMEDIATELY AFTER INSTALLATION, CARRY OUT A QUICK TEST ON THE APPLIANCE FOLLOWING THE INSTRUCTIONS PROVIDED LATER THIS MANUAL. FUNCTION, DISCONNECT IT FROM THE POWER SUPPLY AND CALL THE NEAREST TECHNICAL ASSISTANCE CENTRE. NEVER ATTEMPT TO REPAIR THE APPLIANCE. DURING USE THE APPLIANCE BECOMES VERY HOT.
Page 6: Environmental Responsibility
Instructions for disposal ENVIRONMENTAL RESPONSIBILITY Our product's packing is made of non-polluting materials, which are therefore compatible with the environment and recyclable. Please help by disposing of the packaging correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations.
Page 7: Positioning Of The Hob
Instructions for the installer POSITIONING OF THE HOB The following operation requires building and/or carpentry work so must be carried out by a competent tradesman. Installation can be carried out on various materials such as masonry, metal, solid wood or plastic laminated wood as long as they are heat resistant (T 90°C).
Page 8 Instructions for the installer Fig.1 Fig.3 Fig.4 Fig.2 Fig.5...
Page 9: Electrical Connection
Instructions for the installer ELECTRICAL CONNECTION Make sure that the voltage and capacity of the power line conform to the data shown on the plate located under the casing. Do not remove this plate for any reason. The plug on the end of the supply cable and the wall socket must be the same type and conform to the current electrical system regulations.
Page 10: Gas Connection
Instructions for the installer GAS CONNECTION Connection to the gas mains may be made with a rigid copper pipe or with a flexible pipe and conforming to the provisions defined by standard regulations in force. To facilitate connection, fitting A on the rear of the appliance may be adjusted laterally.
Page 11 Instructions for the installer Connection to LPG Use a pressure regulator and make the connection to the tank according to the provisions of standards regulations in force. Make sure that feed pressure conforms to the levels shown in the table in paragraph “...
Page 12: Adaptation To Different Types Of Gas
Instructions for the installer ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, disconnect the appliance from the electrical socket. The hob has been inspected for G20 (2H) natural gas at a pressure of 20 mbar. For functioning with other types of gas the nozzles must be replaced and the primary air adjusted.
Page 13 Instructions for the installer Regulation for LPG Check that the connection has been made as described in the “Gas connection” section. Undo the screw “D” and push the air regulator “C” fully down. Use a spanner to remove the nozzles “B” and fit those of suitable type following the instructions given in the tables for bottled gas G30/G31 –...
Page 14 Instructions for the installer Regulation for natural gas The hob has been inspected for G20 (2H) natural gas at a pressure of 20 mbar. To allow the unit to work with this type of gas, perform the same operations described in paragraph “ 0 Regulation for LPG”, but choose the nozzles and regulate the primary air for natural gas, as shown in the following table and in paragraph “...
Page 15 Instructions for the installer Regulation of primary air Referred to distance “A” in mm. 60 cm hobs with separable control panel. Burner Auxiliary (1) Semirapid r (2) Semirapid l (3) Rapid large (4) Ultrarapid (5) 90 cm hobs with separable control panel. Burner Auxiliary (1) Semirapid (2)
Page 16: Final Operations
Instructions for the installer FINAL OPERATIONS Having carried out the above adjustments, reassemble the appliance following, backwards, the instructions in paragraph “7.1 Removing the separable control panel / 7.2 Removing the hob”. Regulation of minimum for natural gas Reposition the components on the burner and slide the knobs onto the cock stems.
Page 17 Instructions for the installer Arrangement of the burners on the hob (Hob with separable control panel) 60 cm. hob BURNERS Auxiliary Semirapid r Semirapid l Rapid large Ultrarapid 90 cm. hob BURNERS Auxiliary Semirapid Rapid Fish burner Ultrarapid...
Page 18 Instructions for the installer Arrangement of the burners on the hob (Hob with built-in control panel). 60 cm. hob Lubrication of gas taps With time it may happen that the gas taps get blocked and hard to turn. Clean them inside and re-grease them. This operation must be done by an authorised person.
Page 19: Using The Hob
Instructions for the user USING THE HOB Before turning on the burners, make sure that the burner rings, caps and grids have been fitted correctly. In the ultrarapid burner, notch A must be aligned with pin B. Grid C provided is intended for use with woks (Chinese pans). Adapter D comes only with open grids models and is intended for use with small sized vessels.
Page 20 Instructions for the user while cooking, all pans or griddles must be positioned within the cooking hob perimeter and must be a minimum distance of 3-4 cm from the knobs. Diameter of the pans Burners Auxiliary Semirapid Rapid medio Rapid large Ultrarapid Fish burner Electric elements...
Page 21 Instructions for the user Strong Very strong WARNING When switching on the electric element for the first time, or if the electric element has not been used for a long time, to remove any humidity from the insulating material it should be dried out by placing the electric element on position 1 for 30 minutes.
Page 22: 10 Cleaning And Maintenance
Instructions for the user 10 CLEANING AND MAINTENANCE Never use a steam jet to clean the appliance. Before any intervention, disconnect the power supply of the device. 10.1 Cleaning Clean the cooking top regularly every time you use it, obviously after it has cooled.
Page 23 Instructions for the user 10.2 Cleaning of cooking hob components CAUTION: do not wash these components in a dishwasher. In normal use of the hob, the stainless steel burner caps and pan- stands tend to be burnished by the high temperature. Clean these parts using very fine abrasive sponges or similar commercial products.
