Operator's manual
®
HUSQVARNA AUTOMOWER
435X AWD
EN, English
Read the operator's manual carefully and make sure that you
understand the instructions before you use the product.

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna AUTOMOWER 435X AWD

Summary of Contents for Husqvarna AUTOMOWER 435X AWD

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Husqvarna AUTOMOWER 435X AWD o cerca il tuo prodotto tra le migliori offerte di Macchine Giardinaggio Operator's manual ® HUSQVARNA AUTOMOWER 435X AWD EN, English Read the operator's manual carefully and make sure that you...

  • Page 2: Table Of Contents

    Contents 1 Introduction 6 Troubleshooting 1.1 Support............3 6.1 Introduction - troubleshooting....38 ® 1.2 Product description........3 6.2 Error icons in the Automower 1.3 Product overview ........4 Access display..........38 1.4 Symbols on the product......5 6.3 Fault messages........40 1.5 Symbols on the battery.......6 6.4 Information messages......

  • Page 3: Introduction

    PIN code: The serial number is on the product rating plate and on the product carton. • Use the serial number to register your product on www.husqvarna.com. 1.1 Support The boundary wire and the guide wire controls the movement of the product within the work For support about the Husqvarna product, speak area.

  • Page 4: Product Overview

    1.3 Product overview Front top cover START button Lifting handle 10. Battery cover Rear top cover 11. Skid plate Headlights 12. Blades Display 13. Blade disc LED status indicator 14. LED for operation check of the charging station and boundary wire Jog wheel 15.

  • Page 5: Symbols On The Product

    16. Charging station WARNING: Read the 17. Power supply (the appearance of the power user instructions before supply may differ depending on market) operating the product. 18. Low voltage cable 19. Alarm decal WARNING: Operate the 20. Extra blades disabling device before 21.

  • Page 6: Symbols On The Battery

    ® 1.6 Automower Access It is not permitted to dispose this product as normal household waste. Ensure that the product is recycled in accordance with local legal requirements. The chassis contains components which are sensitive to electrostatic discharge (ESD). The chassis must also be resealed in a professional manner.
  • Page 7 Error icons in the The display shows the status bar and the main error icons. Refer to ® menu icons. If an error occurs, the display shows Automower Access display on page 38 . A. Status bar The current product activity status is shown as ei- ther mowing or parked.
  • Page 8 ® 1.6.2 To operate Automower Access Turn the jog wheel clockwise to move to the right or down in the menus. Turn the jog For information on what is what, refer to wheel counterclockwise to move to the left ® Automower Access on page 6 .
  • Page 9 Icon description ® Use the current timer settings in Activate the Bluetooth pairing ® the Automower Connect app. mode. Operate in the selected mode Pairing between the product and until a new option is chosen. mobile device is not successful. Operate in the selected mode Pairing between the product and until the battery is empty.

  • Page 10: Safety

    2 Safety 2.1 Safety definitions 2.2 General safety instructions Warnings, cautions and notes are used to point The following system is used in the Operator’s out specially important parts of the manual. Manual to make it easier to use: italics is a text that is shown •...
  • Page 11 2.2.1 IMPORTANT. READ CAREFULLY BEFORE USE. KEEP FOR FUTURE REFERENCE The operator is responsible for accidents or hazards occurring to other people or property. This appliance is not intended for use by persons (including chil- dren) with reduced physical, sensory or mental capabilities (that could affect a safe handling of the product), or lack of experience and knowledge, unless they have been given supervision or in- struction concerning use of the appliance by a person responsible...

  • Page 12: Safety Instructions For Operation

    WARNING: The product can be dangerous if used incorrectly. WARNING: Do not use I am a robotic lawnmower and I work here quietly to keep the lawn in perfect condition. I work 24/7 independently of weather conditions and do it the product when without releasing any exhaust emissions.
  • Page 13 26 . Make sure that the LED status indicator is • Husqvarna does not guarantee full not lit. compatibility between the product and other Carry the product by the lifting handle as the types of wireless systems such as remote illustration shows.
  • Page 14 2.3.5 In the event of a thunderstorm To reduce the risk of damage to electrical components in the product and the charging station, we recommend that all connections to the charging station are disconnected (power supply, boundary wire and guide wire) if there is a risk of CAUTION: Do not lift the product when a thunderstorm.

  • Page 15: Installation

    • Put the charging station in an area without an irrigation system. Note: Refer to www.husqvarna.com for more • Put the charging station in an area with information about installation. protection from the sun.
  • Page 16 CAUTION: Make sure that the blades on the product do not cut the low- voltage cable. 10 cm / 4" CAUTION: Do not put the low-voltage cable in a coil or below the charging 0 cm / 0" station plate. The coil causes interference with the signal from the charging station.
  • Page 17 passage must be a minimum of 60 cm / 24 in. CAUTION: Do not let the product wide. operate on gravel. Note: If a passage is less than 2 m / 6.5 ft. wide, • If you make an island, put the boundary wire install a guide wire through the passage.
  • Page 18 • Put the 2 sections of boundary wire in the same stake. • Make sure that there is a minimum of 1.5 m / 5 ft of empty space before an obstacle. 1.5 m/5 ft 1.5 m/5 ft 0 cm/0" Note: When the product cuts grass in the Secondary area mode secondary area, the...

  • Page 19: Before The Installation Of The Wires

    3.2.5 Work area examples CAUTION: Do not put the guide wire in parallel with the slope, as the illustration shows. This can increase the wear on the grass. • If the charging station is put in a small area (A), make sure that the distance to the boundary wire is at a minimum 3 m / 10 ft.

  • Page 20: Installation Of The Product

    • Bury the boundary wire or the guide wire if and increase the risk of electrical you are going to use a dethatcher on the shock. work area. If not, attach the boundary wire or guide wire with stakes. Connect the power supply cable to a 100-240V outdoor power outlet.

  • Page 21: To Put The Wire Into Position With Stakes

    Close the connector with a pair of pliers. Cut the boundary wire 1-2 cm / 0.4-0.8 in. above each connector. Put the 2 ends of the boundary wire Put the right end of boundary wire into the and the end of the guide wires into the channel with the mark "AR".

  • Page 22: To Bury The Boundary Wire Or The Guide Wire

    ® Automower 435X AWD. Contact you local into position with stakes, remove the stakes Husqvarna representative. from the ground. Remove the front top cover. Refer to Carefully remove the boundary wire or the remove the front top cover on page 34 .

  • Page 23: After The Installation Of The Product

    ® have the Automower Connect app installed. ® Automower Connect is a free app for your ® mobile device. The Automower Connect app gives extended functions to your Husqvarna product. You can: 1035 - 001 - 04.02.2019 Installation - 23...

  • Page 24: Overview Of Settings In Automower

    ® • See the status of your product. Register in the Automower Connect app. • Change settings to your product. Log in to your Husqvarna account in the ® • Get extended product information. Automower Connect app. • Get an alarm if the product moves out of the ®...

  • Page 25: To Start The Product For The First Time

    When the product is switched on for the first time, there are some basic settings to do before the Log in to your Husqvarna account in the product can start to operate. ®...

  • Page 26: Settings In Automower ® Access

    ® 3.14 Settings in Automower Access work area is less than the maximum capacity the timer should be used to minimize wear on the 3.14.1 To adjust the cutting height with grass and to the product. ® Automower Access To calculate the timer setting, refer to Push the STOP button to stop the product.
  • Page 27 ® • With the Automower Connect app. Open • Guide wire - The product moves in the work ® the Automower Connectapp on your area until it finds the guide wire. The product Settings > Cutting mobile device. Go to moves along the guide wire to the charging height and obey the instructions in the app.
  • Page 28 • Always ON Time lock A time lock can be set to decide how many days • Evening only will pass before the PIN code must be entered. • Evening and night This means that the product cannot be operated/ •...
  • Page 29 ® through Bluetooth if you are in short-range of ® the product. You can use Automower Direct without a Husqvarna account as long as you have the product PIN code. ® 3.15.11.1 To start to use Automower Direct ® Download the Automower Connect app on your mobile device.

  • Page 30: Operation

    4 Operation 4.1 To switch on the product WARNING: Read and understand the safety chapter before you switch on the product. Push the jog wheel for 3 seconds to switch on the product. 3 sec If the product is parked in the charging station, it will only leave the charging station when the battery is fully charged and if the timer is set to allow the product to operate.

  • Page 31: To Stop The Product

    4.2.3.1 Park until further notice Make sure that the LED status indicator goes out. The product stays in the charging station until another operating mode is selected. Note: If the LED status indicator is lit or is flashing in any color the product is not 4.2.3.2 Park for a specific number of hours LED status indicator switched off.

  • Page 32: Maintenance

    It is recommended to clean using a brush. Husqvarna offers a special cleaning and maintenance kit as an accessory. Contact your Husqvarna central service.

  • Page 33: Replace The Blades

    Rotate the skid plate so that its holes align WARNING: Use blades and screws of with the screws for the blade. the right type. Husqvarna can only guarantee safety when using original blades. Only replacing the blades and reusing the screw can result in a screw wearing during mowing.

  • Page 34: To Replace The Top Covers

    Remove each blade and screw. Lift the front top cover. Fasten new blades and screws. Check that the blades can pivot freely. 5.4 To replace the top covers If the top covers are damaged, you must replace them. CAUTION: Clean grass and dirt from the product before you remove the covers.
  • Page 35 Put a protection between the rear top cover and the link arm. This is to prevent damage to the rear top cover. Push the front top cover into position. Pull the rear top cover. 5.4.3 To remove the rear top cover Push the STOP button to stop the product.

  • Page 36: Battery

    5.4.4 To install the rear top cover Put the top cover on the rear body. 5.5 Battery WARNING: Only charge the product using a charging station and power supply which is intended for it. Incorrect use may result in electric shock, overheating or leakage of corrosive liquid from the battery.

  • Page 37: Winter Service

    Contact your local Husqvarna representative to replace the battery. 5.6 Winter service Take your product to your local Husqvarna representative for service prior to winter storage. Regular winter service will maintain the product in good condition and create the best conditions for a new season without any disruptions.

  • Page 38: Troubleshooting

    Restart the op- motors. eration of the product. Contact your lo- cal Husqvarna representative if the problem is frequent. The product has stopped because the Refer to the error message "No loop Fault messages on page 40 .
  • Page 39 ® Automower Connect app. The product has stopped because of Enter the correct PIN code. Contact the wrong PIN code. your local Husqvarna representative if you have forgotten the PIN code. 1035 - 001 - 04.02.2019 Troubleshooting - 39...

  • Page 40: Fault Messages

    6.3 Fault messages ® The table below shows a number of fault messages that may be shown in Automower Connect. Contact your local Husqvarna representative if the same message appears often. For more Messages on page 29 . information, refer to Message...
  • Page 41 Wrong PIN code Wrong PIN code has been entered. Enter the correct PIN code. Contact Five attempts are permitted, and the your local Husqvarna representative if keypad is then blocked for five minutes. you forget the PIN code. No drive The product is caught in something.
  • Page 42 Message Cause Action Wheel motor over- The product is caught in something. Free the product and rectify the reason loaded for the lack of drive. If it is due to wet grass, wait until the lawn has dried be- fore using the product. Charging station The contact between the charging Put the product in the charging station...
  • Page 43 Message Cause Action Electronic problem Temporary electronic or software rela- Switch off/on the product. ted issue. Loop sensor prob- If the problem remains, the message requires action by authorized service technician. Charging system problem Tilt sensor prob- Temporary prob- Temporary battery Temporary battery or software related Switch off/on the product.

  • Page 44: Information Messages

    6.4 Information messages ® The table below shows a number of information messages that may be shown in Automower Connect. Contact your local Husqvarna representative if the same message appears often. For more Messages on page 29 . information, refer to...

  • Page 45: Indicator Lamp In The Charging Station

    For a fully functional installation, the indicator lamp in the charging station must emit a solid or flashing green light. If something else appears, follow the troubleshooting guide below. There is more help on www.husqvarna.com. If you still need help, please contact your local Husqvarna representative.

  • Page 46: Symptoms

    If your product does not work as expected, follow the symptoms guide below. There is a FAQ (Frequently Asked Questions) on www.husqvarna.com which provides more detailed answers to a number of standard questions. Contact your local Husqvarna representative if you still cannot find the reason for the fault.

  • Page 47: Find Breaks In The Loop Wire

    Symptoms Cause Action Uneven mowing The product works too few hours per Increase the mowing time. Refer to Timer on page 26 . results. day. How often? setting is incorrect in Check that the correct How often? val- relation to the layout of the work area. ue is selected.
  • Page 48 b) If the suspected boundary wire is long (thick black line) then do as follows: Put AL and G1 back to their original positions. Then POWER disconnect AR. Connect a new loop wire to AR. Connect the other end of this new loop wire at the middle of the suspected wire section.
  • Page 49 Continue until only a very short section of the wire remains which is the difference between a solid green light and a flashing blue light. Then follow instruction in step 5 below. If indicator lamp still flashes blue in step 3 above: Put AL and G1 back in their original positions.

  • Page 50: Transportation, Storage And Disposal

    • Keep the product in a dry, frost free space. • Keep the product with all wheels on level ground during storage, or use a Husqvarna wall hanger if available. • If you keep the charging station indoors, disconnect and remove the power supply and all the connectors from the charging station.
  • Page 51 Disconnect the two cables from the battery and remove the battery. 1035 - 001 - 04.02.2019 Transportation, storage and disposal - 51...

  • Page 52: Technical Data

    8 Technical data 8.1 Technical data ® Dimensions Automower 435X AWD Length, cm / in. 93 / 36.6 Width, cm / in. 55 / 21.6 Height, cm / in. 29 / 11.4 Weight, kg / lbs 17.3 / 38.1 ® Electrical system Automower 435X AWD...
  • Page 53 ® Mowing Automower 435X AWD Cutting system 3 pivoted cutting blades Maximum blade motor speed, rpm 2475 Power consumption during cutting, W +/- 20 % Cutting height, cm / in. 3-7 / 1.2-2.8 Cutting width, cm / in. 22 / 8.7 Narrowest possible passage, cm / in.
  • Page 54 Power Class 1 (for 30 dBm DCS/PCS) Husqvarna AB does not guarantee full compatibility between the product and other types of wireless systems such as remote controls, radio transmitters, hearing loops, underground electric animal fencing or similar. The products are made in England or the Czech Republic. See information on the rating plate. Refer to Introduction on page 3 .

  • Page 55: Warranty

    The blades and wheels are seen as disposable and are not covered by the guarantee. If an error occurs with your Husqvarna product, please contact Husqvarna customer service for further instructions. Please have the receipt and the products’s serial number at hand when contacting Husqvarna customer service.

  • Page 56: Ec Declaration Of Conformity

    10.1 EC Declaration of Conformity ® For Husqvarna Automower 435X AWD equip- ® ped with Bluetooth also: Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares that the Husqvarna • ETSI EN 300 328 V2.1.1 ® Automower 435X AWD with serial numbers •...
  • Page 57 1035 - 001 - 04.02.2019 EC Declaration of Conformity - 57...
  • Page 58 58 - EC Declaration of Conformity 1035 - 001 - 04.02.2019...
  • Page 59 1035 - 001 - 04.02.2019 EC Declaration of Conformity - 59...
  • Page 60 ® AUTOMOWER is a trademark owned by Husqvarna AB. © Copyright 2019 HUSQVARNA. All rights reserved. www.husqvarna.com Original instructions 1140539-26 2019-02-22...
