Landoll Brillion LSP5 Operator's Manual

Landscape grass seeder
Hide thumbs Also See for Brillion LSP5:

Advertisement

Quick Links

Download this manual
'
Landscape Grass Seeder
Models LSP5, LSP6 and LSS6
Operator's Manual
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
(785) 562-5381
800-428-5655 ~ WWW.LANDOLL.COM
7K458-2311

Advertisement

loading
Need help?

Need help?

Do you have a question about the Brillion LSP5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Landoll Brillion LSP5

Summary of Contents for Landoll Brillion LSP5

  • Page 1 ‘ Landscape Grass Seeder Models LSP5, LSP6 and LSS6 Operator’s Manual LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM 7K458-2311...
  • Page 2 Manuals for Landscape Grass Seeder - LSP5, LSP6 and LSS6 Manual Number Manual Type 7K458 Operator’s Manual 7K457 Parts Manual...
  • Page 3 DANGER DO NOT operate or perform any maintenance tasks on this equipment until you have completed the following: 1. Receive proper training to operate this equipment safely. 2. Read and understand the operator’s manual. 3. Be thoroughly trained on inspection and repair procedures. Failure to comply with this warning may result in serious injury or possibly death.
  • Page 5 Table of Contents Safety Information Introduction ........... . 1-1 Description of Unit .
  • Page 6 TABLE OF CONTENTS Maintenance General Torque Specifications ........4-1 Fasteners .
  • Page 7 Seeder. within 10 days of retail purchase, using the Landoll Company, LLC Ag Products on-line registration process. • 5FT Seed Box capacity is 3.75-bushel Please refer to the Ag Products Policy and Procedures •...
  • Page 8 TABLE OF CONTENTS SAFETY INFORMATION Safety • When applying decals to the implement, be sure to clean the surface to remove any dirt or residue. Where possible, sign placement should protect the sign from NOTE abrasion, damage, or obstruction from mud, dirt, oil etc.
  • Page 9 TABLE OF CONTENTS SAFETY INFORMATION Safety Instructions for Towing Protective Equipment Vehicles • Wear protective clothing and equipment appropriate for the job. Avoid loose fitting clothing. The maximum travel speed is the lesser of • Because prolonged exposure to loud noise can cause •...
  • Page 10 13 TOOTH 26 TOOTH ITEM 11 DRIVER ITEM 4 2P151 7K343 FOR LSP5 AND LSP6 SEEDERS 528934 ITEM 8 - 7K343 A LANDOLL PRODUCT ITEM 5 LANDSCAPE 528933 SEEDER ITEM 9 - 193500 P/N: 235624 ITEM 12 ITEM 6 ITEM 9 - 4K036...
  • Page 11 TABLE OF CONTENTS SAFETY INFORMATION Figure 1-3: LSP Decal Locations (After 12/2023) 7K458-2311...
  • Page 12 TABLE OF CONTENTS SAFETY INFORMATION Figure 1-4: LSS6 Decal Locations (After 12/2023) 7K458-2311...
  • Page 13 TABLE OF CONTENTS SAFETY INFORMATION Figure 1-5: LSP Decal Locations (Before 12/2023) 7K458-2311...
  • Page 14 TABLE OF CONTENTS SAFETY INFORMATION Table provided for general use. NOTES: 7K458-2311...
  • Page 15 Chapter 2 TABLE OF CONTENTS Assembly The Seeder is shipped completely assembled. See To ensure alignment of assemblies, leave the nuts loose Figure 2-1. until completion of final assembly. Use lockwashers or flat washers as specified. Spread all cotter pins. CAUTION After completion of final assembly, tighten all nuts evenly to prevent misalignment, distortion or binding.
  • Page 16 TABLE OF CONTENTS ASSEMBLY Skid Steer Seeder Quick The Quick Attach Plate can be mounted on the front (Skid Steer pulls the Seeder) or rear (Skid Steer pushes the Attach Plate Seeder) of the Seeder. See Figure 2-3. Quick Attach Plate when mounted on the rear can be offset.
  • Page 17 TABLE OF CONTENTS ASSEMBLY Seeder Quick Attach Plate Seeder Frame Rear Tube REAR Frame Lug Frame Lug FRONT Seeder Seeder REAR Frame Lug Frame Lug FRONT Stop Channel Stop Channel Quick Attach Plate Figure 2-3: Quick Attach Plate Mounted - Centered 7K458-2311...
  • Page 18 TABLE OF CONTENTS ASSEMBLY Quick Attach Plate 5" Offset Seeder Frame Rear Tube REAR Frame Lug Frame Lug FRONT Seeder Figure 2-4: Quick Attach Plate Mounted - Offset Agitator Installation 5-Strip Brush Agitators must be installed with the brushes facing backward, away from rotation to wipe over the seed openings.
  • Page 19 TABLE OF CONTENTS ASSEMBLY Inner Drive Shaft Rotation Flange Hub Outer Drive Flange Hub Seed Box Shifter 5-Strip Plate Roll Pin Brush Seed Shaft REAR Figure 2-7: Agitator Installation - LH Figure 2-6: Brush Agitator Orientation Lock Washer,5/16 Agitator Installation Steps Bolt,5/16-18 1.
  • Page 20 TABLE OF CONTENTS ASSEMBLY Acre Meter Installation - 6. Attach the Pick-Up Switch short ground wire to the small hole in the Pick-Up Switch Bracket with #6-32 x Optional 1/2 Screw and Nut. Remove paint under the wire connector to assure a good electrical ground The Acre Meter Kit consists of three main parts, the Acre connection.
  • Page 21 TABLE OF CONTENTS ASSEMBLY 8. Connect the Acre Meter and Pick-Up Switch Connectors. 9. Securely fasten the cords with tie wraps to the Seeder Frame End Plate to prevent cords from becoming entangled or rubbing on moving parts. See Figure 2-13. 10.
  • Page 22 TABLE OF CONTENTS ASSEMBLY CAT2 Quick Hitch Adapter Kit 3. Insert a Clamp Plate into each Hitch Lug Slot and over the top of the Seeder Frame Tube. Secure with 1/2-13 - Optional x 4-1/2 Bolts and Locknuts. See Figure 2-15. 4.
  • Page 23 TABLE OF CONTENTS ASSEMBLY Hair Pin Cotter Clevis Pin Bushing,1" x 2" Lower 3-PT Hitch Pin Bushing,1-1/8 18" Klik Pin Klik Pin x 3-3/16 Lower 3-PT Bushing,1-1/8 Hitch Pin x 3-3/16 Category 2 Free Link Bushing,1-1/4 x 1-15/16 Clevis Pin Hair Pin Cotter Pin Ø1-7/16"...
  • Page 24 TABLE OF CONTENTS ASSEMBLY Lift Sling Kit - Optional 1. Attach a Mounting Bracket onto each side of the Seeder Frame with 1/2-13 x 1-3/4 Bolts, Lock Washers and Nuts. See Figure 2-17. WARNING 2. Attach Lift Sling to Mounting Brackets with 5/8-11 x 1-1/2 Bolts and Locknuts.
  • Page 25 Chapter 3 TABLE OF CONTENTS Operation DANGER DANGER DANGER DANGER Never allow anyone to ride on the seeder at any Always lock the tractor drawbar in the center time. Allowing a person to ride on the machine can position when transporting the unit. Failure to do inflict serious personal injury or death to that so can result in serious injury or death and cause person.
  • Page 26 TABLE OF CONTENTS OPERATION Tractor Preparation - 4. Disengage both Parking Pins from the back LH and RH sides of the Seeder. This will allow the Rear Roller Attaching/Detaching to float during operation. See Figure 3-1. • Remove each Parking Pin Klik Pin. The Landscape Seeder is available as a 3-PT Hitch or •...
  • Page 27 TABLE OF CONTENTS OPERATION Clevis Pin Hair Pin Cotter Pin Ø3/4" 18" Pin Ø7/8" Pin Ø7/8" Klik Pin Klik Pin Lower Hitch Pin Lower Hitch Pin Category 1 Free Link Clevis Pin Hair Pin Cotter Bushing Ø1" Bushing Ø1-1/8" Bushing Ø1-1/8" 18"...
  • Page 28 TABLE OF CONTENTS OPERATION SMV Position in Transport Skid Steer Preparation - Attaching/Detaching The SMV should be clearly viewable from the rear of the Seeder and as vertical as possible when in transport. Skid Steer Preparation 1. Loosen the 1/2-13 Hardware attaching the SMV Mount to the Seeder.
  • Page 29 TABLE OF CONTENTS OPERATION 4. Raise Seeder so Rollers are barely off the ground. 5. Disengage both Parking Pins from the back LH and Klik Pin RH sides of the Seeder. This will allow the Rear Roller to float during operation. See Figure 3-5. Parking Pin •...
  • Page 30 TABLE OF CONTENTS OPERATION Seed Rate Adjustment Cage and 8-Row Brush Agitators can be used to plant cereal grains such as Wheat, Oats, Rye, and Barley. However, Brillion does not recommend this for a WARNING harvestable grain crop because the seed will be placed in the top 1/4"...
  • Page 31 TABLE OF CONTENTS OPERATION Seed Calibration Procedure Idler NOTE 13 Tooth The information listed in the Seed Charts is subject to Driven change without notice. 26 Tooth IMPORTANT Driven Planting rates are in pounds per acre. Rates are for 13 Rotation Tooth Driver.
  • Page 32 TABLE OF CONTENTS OPERATION Doubling the Seed Rate Sprocket, Connector Link Seed rates can be doubled by using the 26 Tooth 13 Tooth Sprocket and extra Chain Links located on the Seeder Extra Frame Left End Plate. See Figure 3-12. Nut,3/4-10 Chain 1.
  • Page 33 TABLE OF CONTENTS OPERATION Track Remover Adjustment The pitch of the Tire Track Remover/s can be adjusted. The depth of the Tire Track Remover/s can be 1. Loosen the Clamp Bolts that secure the Coil Tine adjusted. Harrow Tube to the Coil Tine Supports. See 1.
  • Page 34 TABLE OF CONTENTS OPERATION Loup Acre Meter Kit - Total Acres Optional (After 05/15/2012) Press the /FUNC button until the “TOTAL” LED is lit. The digits indicate the acres covered since the total acre counter was cleared. IMPORTANT To clear the total acre count, press and hold the UP and Acre Meter is dust and splash resistant, under no DOWN buttons for two seconds.
  • Page 35 TABLE OF CONTENTS OPERATION Loup Acre Meter Kit - If the display shows “Ent”: You must enter your password using the UP and DOWN buttons. When your Optional (Before 05/15/2012) password is displayed, press the /FUNC button to test the password. If the password is correct, you will be able Settings to change the acre counter settings.
  • Page 36 TABLE OF CONTENTS OPERATION Acre Meter Settings Charts MODEL Pulses per 400 FT Width (Feet) SSPT604 SSBP4 SSB4 SSBP5 SSBP6 SSBS6 SSP8 SSBP8 SSB8 SSP10 SSBP10 SS10 SSB10 10.0 SSP12 SSBP12 SS12 SSB12 12.0 SSP16 SSBP16 SS16 SSB16 16.0 SSP108 SS108 SSP110 SS110...
  • Page 37 TABLE OF CONTENTS OPERATION Width MODEL Pulses (Feet) SSPT604 SSP4 SSP5 SSP6 SSP8 SSP10 SS10 SSP12 SS12 SSP108 SS108 SSP110 SS110 SSP112 SS112 SSP208 SSP2081 SS208 SS2081 SSP210 SSP2101 SS210 SS2101 SSP212 SSP2121 SS212 SS2121 SSP308 SS308 SSP310 SS310 SSP312 SS312 SLP8 4147...
  • Page 38 TABLE OF CONTENTS OPERATION Transporting the Seeder 9. Verify that SMV sign, reflectors, and Safety Decals are clearly visible and tractor or Skid Steer lamps are 1. Check and follow all federal, state, and local functioning properly. requirements before transporting the Seeder. 10.
  • Page 39 Chapter 4 TABLE OF CONTENTS Maintenance General Torque Specifications (rev. 4/97) This chart provides tightening torques for general purpose applications when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received condition). They do not apply if special graphite moly-disulfide or other extreme pressure lubricants are used.
  • Page 40 TABLE OF CONTENTS MAINTENANCE Fasteners Lubrication Before operating your Brillion machine, check all WARNING hardware for tightness. Use the Tightening Torque Table as a guide. See Page 4-1. Do Not lubricate Seeder while in motion. If Guard After a few hours of use, check entire machine and tighten is opened for lubricating, it must be closed before any loose nuts or bolts.
  • Page 41 TABLE OF CONTENTS MAINTENANCE Front and Rear Roller 3. Slide the Clamp Band against the Half End Wheel on each end of the Front Roller and tighten the Clamp Adjustment Band Socket Head Bolt to 75 Ft-Lbs. 4. Adjust the Rear Roller Wheels. Loosen the Axle Clamps.
  • Page 42 TABLE OF CONTENTS MAINTENANCE Seed Box Slide Adjustment Shifter Set to "0" When the Seed Box Slide is properly adjusted, the Handle following should occur. Shifter • When the Shifter Handle is set to “0” (closed), the Plate Seed Box bottom opening end edge is aligned with the Slide opening end edge.
  • Page 43 TABLE OF CONTENTS MAINTENANCE Acre Meter Troubleshooting 2. Verify that the magnet in the Magnet Wheel Assembly has not come out. 3. Place the Acre Meter display in “Calibrate” mode by IMPORTANT pressing the *(FUNC) key until the “P-WORD” Acre Meter is dust and splash resistant, under no indicator is lit and then press the up/down arrow keys circumstances should this unit be submerged in any until the display shows 0 and the LED is blinking.
  • Page 44 TABLE OF CONTENTS MAINTENANCE Table provided for general use. NOTES: 7K458-2311...
  • Page 45 Chapter 5 TABLE OF CONTENTS Specifications Product Attributes LSP 5 LSP 6 Approximate Weight 966 lbs. (438 kg) 1,103 lbs. (500 kg) Working Width 5 ft. 0 in. (1.25 m) 6 ft. 0 in. (1.8 m) Transport Width 6 ft. 0 in. (1.8 m) 7 ft.
  • Page 46 TABLE OF CONTENTS SPECIFICATIONS Product Attributes LSS 6 Approximate Weight 1,300 lbs. (590 kg) Working Width 6 ft. 0 in. (1.8 m) Transport Width 7 ft. 0 in. (2.1 m) Transport Height Dependent Upon Tractor Overall Height 4 ft. 5 in. (1.4 m) Overall Length 3 ft.
  • Page 47 Document Control Revision Log: Date Form # Improvement(s): Description and Comments 05/2008 102rev0508 Initial Release 10/2011 102rev1011 Updated, Incorporated Landoll Format 03/13/2013 102rev0313 Added New Acre Meter Data 02/2021 7K458-0221 Added CAT2 Quick Coupler Hitch Adaptor Kit 02/2022 7K458-0222 Updated: Assembly Chapter “Changing Agitator Kits”...
  • Page 48 Equipment from Landoll Company, LLC is built to exacting standards ensured by ISO 9001 registration at all Landoll manufacturing facilities. Landscape Grass Seeder Models LSP5, LSP6 and LSS6 Operator’s Manual Re-Order Part Number 7K458 LANDOLL COMPANY, LLC 1900 North Street...
