3.2 Electrical connection
• The voltage, electrical power, pressure range and nominal width can be
found on the name plate.
• Voltage tolerance: ± 10%
• Electrical connection: Instrument socket Type 2508 to the connection plug pin
of the coil; Fixing torque: 0.5 Nm
ATTENTION!
3.3 Measures to be taken before installation
Before the installation, check:
- fluid and electrical connections
- Operational pressure
- Voltages
- Type of current.
Ensure that the maximum operating conditions (see
name plate) are not exceeded!
Always connect the protective conductor!
Always follow the warning instructions on the coil,
particularly for coils which require rectifiers!
When screwing the coil and the instrument socket
together, ensure that the seal is properly seated!
