NRS Healthcare M11077 User Instructions

M11077
General Safety Warning
Please make sure that you read and follow these
instructions carefully. Keep these instructions in
a safe place for future reference.
1. INTENDED USE
To assist users transferring into and out of the bath by reducing the step-over height. It can also provide
assistance when using the toilet or sink in a bathroom environment.
2. SAFETY
WARNING: The maximum user weight must not be
more than 317 kg (50 st).
WARNING: The maximum step height is 175 mm
(7") using 6 step sections (2 packs).
DO NOT: Stack more than 6 step sections together.
ALWAYS: Make sure the bottom section of the step
has 4 support pillars inserted into the base.
3. UNPACKING
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
3.1 Contents:
1. Step 50 mm (2") x 3
2. Support Pillar x 4
4. ASSEMBLY/INSTALLATION
4.1 Single Step - 50 mm (2") Step Height:
1. Turn one step section upside down and lay flat.
2. Push the four support pillars into position (see
Figure 1).
USER INSTRUCTIONS
ADJUSTABLE BATH-STEP RANGE
Adjustable Bath Step & Support Pillars
Maximum User Weight
Figure 1: Insert Support Pillars
3. Turn the step over to stand on the pillars and
place in the desired location.
4.2 Two Steps - 75 mm (3") Step Height:
1. Turn one step section upside down and lay flat.
2. Push the four support pillars into position (see
Figure 1).
3. Place an additional step section on top of the
first.
4. Push down firmly to secure.
4.3 Three Steps - 100 mm (4") Step Height:
1. Place an additional step section on top of the
top step section.
2. Push down firmly to secure.
1
50st
317kg
