NRS Healthcare M11090 User Instructions

M11090
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1.

INTENDED USE

The Toilet Frame with Seat is designed to assist users when lowering onto and rising from the toilet.
Primarily for use over the toilet using the splash guard provided but also for use as a commode with the
addition of a potty. The seat lid adds discreet style and helps to improve cleanliness and hygiene.
2.

SAFETY

WARNING: The maximum user weight must not be
more than 190Kg (30st).
DO NOT attempt to stand or climb on the product.
MAKE SURE all legs are set at equal height to avoid
rocking.
3.

UNPACKING

Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
4.

INSTALLATION INSTRUCTIONS

Product arrives fully assembled.
To adjust the height:
• Remove the 'e-clip' and slide the legs to the
desired position.
• Align the holes and re-insert the 'e-clip'.
• Repeat for all four legs.
Ensure that all four legs are positioned at the same
height to prevent rocking and instability.
HEIGHT ADJUSTABLE TOILET FRAME
Height Adjustable Toilet Frame with Seat
Figure 1:
USER INSTRUCTIONS
WITH SEAT
Place the frame over the toilet ensuring that the
internal splash guard is positioned centrally over the
toilet bowl.
To fi t M20303 - Commode Pan
Figure 2: M20303 Commode Pan
Lift the seat and lid to slot the commode pan into
position on the frame, see fi gure 3.
Figure 3: M11090 with Commode Pan (M20303)
5.

OPTIONAL FLOOR FIXING KIT

The fl oor fi xing kit provides a permanent fi xing
solution for the Toilet Frame. It helps to prevent
the frame from moving out of position or becoming
unstable during use.
1
Maximum User Weight
30st
190kg
fi tted
