NRS Healthcare WHEELED COMMODE Series User Instructions

L22056 Wheeled Commode Fixed Height
N54411 Economy Wheeled Commode Fixed Height S30063 Wheeled Commode Powder Coated
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1. INTENDED USE
The Wheeled Commode range has been designed for use as a traditional commode or for use over a
standard toilet. Subject to completion of a suitable risk assessment, the wheeled commode can be used for
short transfers to move the user over the toilet. It features removable arms to enable side transfers.
2. SAFETY
Warning: Do not exceed the maximum user weight
specified for each product.
Always perform a risk assessment prior to use,
including safe moving distance.
Do not use as an alternative to a wheelchair.
Do not use in a shower or as a shower chair.
Do not use the product outdoors.
Only use indoors on level surfaces and take care
over door thresholds.
Always engage the brakes and swing away or lift off
the footrests when the user is transferring onto or off
the commode.
Take care to ensure all body parts are inside the
perimeter of the commode when passing through
doorways.
USER INSTRUCTIONS
NRS WHEELED COMMODE
M66119 Wheeled Commode Height Adjustable
3.
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
3.1
Main Chassis & Castors
Main Chassis
Seat Cover
Detachable Arms
Detachable Back
Potty
Footrest
Adjustable-Height Castors
Hand Wheel
E-Clip
4.
4.1
Slide the castors into the main chassis, set to the
desired height, then secure with the e-clips.
Note: Make sure that all castor legs have been set
to the same height.
1
Maximum User Weight
30st
190kg
UNPACKING
Contents:
L22056
Part
N54411
ASSEMBLY
Fitting the Castors (M66119 and S30063):
M66119
Qty
S30063
1
P
1
P
1
P P
2
P P
1
P P
1
P P
2
P P
4
P
2
P P
4
P
