Summary of Contents for Schiller FRED easyport plus Trainer
- Page 1 ® ® FRED easyport plus Trainer Automated external defibrillator (AED) Depth 5.0cm CPR OK 00:59 Rate 101/min User Guide...
- Page 2 Sales and service information The SCHILLER sales and service centre network is world-wide. For the address of your local distributor, contact your nearest SCHILLER subsidiary. In case of difficulty, a complete list of all distributors and subsidiaries is provided on our internet site: http://www.schiller.ch...
-
Page 3: Table Of Contents
Configurations on the FEP+ TRAINER ..........12 Operating and Display Elements ........15 2.2.1 Overview FEP+ TRAINER ............... 15 2.2.2 FRED easyport plus TRAINER with bag (optional)......16 Inserting the batteries ............17 2.3.1 Switching device On and Off............17 2.3.2 Device-smartphone pairing .............. - Page 4 ® ® FRED easyport plus Trainer Page 4...
-
Page 5: Safety Notes
Immediately report any changes that impair safety (including operating behav- iour) to the responsible person. Only use original SCHILLER training electrodes. Immediately replace a damaged unit, or damaged cables and connections. Only operate the device in accordance with the specified technical data. -
Page 6: Maintenance And Cleaning
There are no express or implied warranties which extend beyond the warranties here- inabove set forth. SCHILLER makes no warranty of merchantability or fitness for a particular purpose with respect to the product or parts thereof. -
Page 7: Symbols/Indicators
Safety Notes FRED® easyport® plus Trainer User Guide Symbols/Indicators Symbols/Indicators 1.7.1 Symbols used in this user guide The safety levels are classified according to ANSI Z535.6. The following overview shows the safety symbols and pictograms used in this user guide. The terms Danger, Warning, and Caution are used in this User Guide to point out poten- tial dangers and to indicate risk levels. -
Page 8: Symbols Used On The Device
Safety Notes Symbols/Indicators FRED® easyport® plus Trainer 1.7.2 Symbols used on the device General used symbols see 5 Appendix - Symbols. Reading the instruction for use is mandatory before using the device! Dangerous voltage! Used for electrical dangers during defibrillation. The enclosure is protected against foreign solid objects of ... -
Page 9: Symbols Used On The Training Electrode Packaging
Safety Notes FRED® easyport® plus Trainer User Guide Symbols/Indicators 1.7.3 Symbols used on the training electrode packaging These electrodes are only intended for training, not for clinical use. Do not store these electrodes with your normal defibrillator. General used symbols see 5 Appendix - Symbols. -
Page 10: Components And Operation
Components and Operation General Information FRED® easyport® plus Trainer 2 Components and Opera- tion General Information The following instruction uses the Name FEP+ TRAINER instead of the full name ® FRED easyport plus TRAINER The FEP+ TRAINER is a simple and cost-effective simulator of the FRED easyport ®... -
Page 11: Configurations Via Simulation App
Components and Operation FRED® easyport® plus Trainer User Guide General Information 2.1.1 Configurations via Simulation App Configuration Values Device Normal Simulation of the following device types: Semi-automatic Manual FEP+ Manual Automatic FEP+ Auto Audio language List of available language Page 11... -
Page 12: Configurations On The Fep+ Trainer
Components and Operation General Information FRED® easyport® plus Trainer 2.1.2 Configurations on the FEP+ TRAINER The following programming should be adapted for the organisation to be trained. Note: This bold settings have been entered during the initial setting. The initial setting screen appears only after the device is set to factory default. - Page 13 Components and Operation FRED® easyport® plus Trainer User Guide General Information Device Setting >>> CPR setting Default settings are bold Parameter Values Description If Yes is set, the device starts with the analysis as soon as defibrillation • No electrodes are applied. Start with Analysis If No is set, the device prompts the user to perform CPR before the •...
- Page 14 Components and Operation General Information FRED® easyport® plus Trainer System Setting >>> Local setting Note: This settings have been entered during the initial setting. The initial setting screen appears only after the device is set to factory default. Parameter Values Description •...
-
Page 15: Operating And Display Elements
Components and Operation FRED® easyport® plus Trainer User Guide Operating and Display Elements Operating and Display Elements The status LEDs are not active! 2.2.1 Overview FEP+ TRAINER The picture below shows the user interface for an AED with ECG and CPR feedback display. -
Page 16: Fred Easyport Plus Trainer With Bag (Optional)
Components and Operation Operating and Display Elements FRED® easyport® plus Trainer 2.2.2 FRED easyport plus TRAINER with bag (optional) (1) RTU LED (Ready -to-use LED) transparent window (2) Defibrillation electrode compartment (3) Scissor and razor compartment (4) Connection ARGUS LifePoint CPR feedback sensor (USB Port) -
Page 17: Inserting The Batteries
Components and Operation FRED® easyport® plus Trainer User Guide Inserting the batteries Inserting the batteries Danger of explosion! The battery must not be exposed to high temperatures or disposed of with household waste. Do not short-circuit, cut, destroy, burn or charge a battery. ... -
Page 18: Device-Smartphone Pairing
Log Files >>> Next device 7. Open the Schiller Defi training App on your smart-phone or tablet PC. 8. Select the icon the Device list of Defi training application. Select the de- vice you want to use in the list. -
Page 19: Training
Training FRED® easyport® plus Trainer User Guide Training procedure semi automated AED 3 Training • As soon the FEP+ TRAINER is switched on, the voice prompt starts. • Advise the trainee to follow the instruction from the device. • The running AED algorithm can by paused during CPR by the Green ON/OFF but- ton (press 1 second) and continued by pressing again the ON/OFF button •... -
Page 20: Training Procedure Fully Automated Aed
Training Training procedure fully automated AED FRED® easyport® plus Trainer Training procedure fully automated AED • The following instructions comply with the scenario “shock recommended” and then shock not recommended. • Depending on the configuration the FEP+ TRAINER may start with Step 1 or 11 (see chapter 2.1.2 Start with analysis Yes/No). -
Page 21: Training Procedure Manual Aed Mode
Training FRED® easyport® plus Trainer User Guide Training procedure manual AED mode Training procedure manual AED mode • The FRED easyport plus version including the manual option is clearly labelled with a red foil. If the user does not activate the manual mode, the unit will run in the semi-automatic mode. - Page 22 Training Training procedure manual AED mode FRED® easyport® plus Trainer repeat until next instruction (the next instruction starts with step 2) – After the instruction “no shock advised” (step 4), it jumps to step 8. Finishing resuscitation process To finish the resuscitation process and switch the device to standby mode, press the Green ON/OFF button (press 3 second) Page 22...
-
Page 23: Training On Thorax Compressions (Optional)
Training FRED® easyport® plus Trainer User Guide Training on thorax compressions (optional) Training on thorax compressions (optional) This training is only avalibel with the ARGUS LifePoint CPR feedback sensor. The training with the Argus LifePoint sensor is only allowed on a chest manikin. Text and voice advice Measured value from ARGUS Depth... -
Page 24: Setup Of The Sensor
Training Training on thorax compressions (optional) FRED® easyport® plus Trainer 3.4.1 Setup of the sensor The recommended securing pads during real CPR keeps the LifePoint sensor in po- sition. It is not always needed for training purpose. 1. Connect the LifePoint USB cable to the USB connector. 2. - Page 25 Training FRED® easyport® plus Trainer User Guide Training on thorax compressions (optional) 7. The displayed measurements in the middle of the screen informs you about your CPR quality. Depth CPR OK 00:59 Rate /min The following limits are set for speed and depth: Metronome speed [/min] Press faster...
-
Page 26: Accessories And Disposables
. A full list of all SCHILLER representatives can be TRAINER found on the SCHILLER website (www.schiller.ch). In case of difficulty, contact SCHILLER. Our staff will be pleased to help process your order or to provide details for all SCHILLER products. 3.5.1... -
Page 27: Disposal Information
In accordance with national law, the battery must be dis- posed of at an appropriate waste disposal station or returned to SCHILLER. According to European legislation, this device is considered as electronic waste equipment. -
Page 28: Troubleshooting
Training Troubleshooting FRED® easyport® plus Trainer Troubleshooting 3.7.1 Troubleshooting Problem Possible causes Remedy The ON/OFF LED is off and Replace the battery. • Battery depleted or inserted with the device cannot be turned the wrong polarity. Insert the battery correctly. •... -
Page 29: Preventing Electromagnetic Interferences
Training FRED® easyport® plus Trainer User Guide Preventing electromagnetic interferences Preventing electromagnetic interferences The user can help avoid electromagnetic disturbances by keeping the minimum distance between portable and mobile HF telecommunication devices (transmitters) and the FEP+ TRAINER. The minimum distance of 0.3 m has been tested according to IEC 60601-1-2 for a wide range of telecommunication equipment, as shown in the following table: “Non ionising electromagnetic radiation"... -
Page 30: Technical Data
Max. power output +4 dBm Conformity Hereby, SCHILLER AG declares that the radio equipment type FRED easyport plus TRAINER is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.schiller.ch/en/conformity... -
Page 31: Appendix - Symbols
Appendix - Symbols 5 Appendix - Symbols This appendix lists all general symbols that may be present on the device, label and accessories. Not all of those symbols are necessarily present on your device. This appendix has its own article number, which is independent of the user guide's article number. - Page 32 Appendix - Symbols CE marking, affirms its conformity with European standards Regulatory Compliance Mark for the Australian standards The device is recyclable Symbol for the recognition of electrical and electronic equipment. Device must not be disposed of in the household waste. Symbol for the recognition of a battery.
- Page 33 Appendix - Symbols Keep dry (store in a dry location) Keep away from sunlight (protect from direct sunlight) Fragile, handle with care Transport upwards (this way up) Do not use hooks EIP = electronic information product (does not contain any toxic and hazardous substances or elements above the maximum concentra- tion values (product can be recycled and re-used)).
- Page 34 Appendix - Symbols Blank page...
