USER MANUAL
USER MANUAL
V1.0 | MW63
V1.0 | MW63

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LINKZONE and is the answer not in the manual?

Questions and answers

Related Manuals for TCL LINKZONE

Summary of Contents for TCL LINKZONE

  • Page 1 USER MANUAL USER MANUAL V1.0 | MW63 V1.0 | MW63...

  • Page 2: Table Of Contents

    Contents Read this first ........................iii Chapter 1. Meet Your LINKZONE ..................1 1.1 System requirements ..................... 1 1.2 Overview ........................1 Chapter 2. Getting Started ....................3 2.1 Install a SIM card and the battery .................. 3 2.2 Power on your LINKZONE ..................... 3 2.3 Access LINKZONE network ...................

  • Page 3: Read This First

    • TCL Communication Ltd. does not assume any liability that may occur due to the use or application of the product described herein. Every effort has been made in the preparation...

  • Page 4: Chapter 1. Meet Your Linkzone

    300 Mbps. Your LINKZONE lets you create fast and secure Wi‑Fi in any location with cellular network coverage. 1.1 System requirements Your LINKZONE supports up to 32 connected devices with up to 5 GHz Wi‑Fi network. It also works with these browsers, for example Firefox, Safari, Internet Explorer, Opera, and Google Chrome.
  • Page 5 Press any button to turn all the indicators on. • If the Wi‑Fi network hasn't been used for over 10 minutes, your LinkZone will be disconnected from the network. Press any button to resume network connection.

  • Page 6: Chapter 2. Getting Started

    Remove the battery if your LinkZone will not be used for more than one week. 2.2 Power on your LINKZONE To power on your LINKZONE, press and hold the power button for 3 seconds. The indicators will flash solid blue.

  • Page 7: Access Linkzone Network

    2.3 Access LINKZONE network You can connect your devices to the LINKZONE network wirelessly. To establish a wireless network connection, select the Wi‑Fi name (or the SSID) of the LINKZONE on your wireless devices, and enter the Wi‑Fi password. NOTE The default Wi‑Fi name and password can be found on the label beneath the...

  • Page 8: Chapter 3. Access The Web Ui

    Chapter 3. Access the Web UI This chapter introduces how to access the web UI of your LINKZONE, and gives you a glimpse of the web UI. 3.1 Log in to the web UI To log in to the web UI, follow these steps: 1.
  • Page 9 Status icon What it means The LinkZone connects to the network. The LinkZone disconnects from the network. New messages or unread messages The SMS inbox is full. Wi‑Fi is enabled. Wi‑Fi is disabled. It indicates the battery level of your router.

  • Page 10: Chapter 4. Configure Your Linkzone

    Chapter 4. Configure Your LINKZONE In this chapter, we will show you how to get the most out of your LINKZONE using the web UI. With the web UI, you can configure Wi‑Fi settings, view connected devices, manage SMS settings, and more.

  • Page 11: Status

    4.2 Status This section allows you to view your network information, connection status, device information and more. Status You can have a quick check on your device information, such as cellular network and Wi‑Fi. Connected devices This tab allows you to edit the connected device name, and manage internet access for connected devices.

  • Page 12: Settings

    1. Locate the message you want to delete in the Inbox Outbox folder. Delete a message 2. Tick the checkbox beside the message you want to delete. 3. Click Delete. 1. Click at the top of the checkbox column to select all messages.
  • Page 13 5 GHz (Auto, 802.11a, 802.11an, and 802.11ac). The AP isolation function enables you to create a separate virtual network for each wireless client that is connected to your LinkZone AP isolation network. When this function is enabled, all wireless devices in the network will not be able to communicate with each other.
  • Page 14 LinkZone web UI or the master network. Security SIM PIN management 1. When the SIM PIN feature is disabled, click Enable SIM PIN 2. Set a SIM PIN code. 3. Click Apply.

  • Page 15: System

    This function enables you to restart or factory rest the LinkZone. If the LinkZone does not work properly, you can try restarting the device to solve the problem. If you can't access the internet for unknown reasons, or forget the login password, you can restore the LinkZone to factory settings.

  • Page 16: Important Safety Information

    Important safety information Read all the safety information before using your product. Failure to follow these safety instructions could result in injury, or damage to your product or other property. Important safety instructions • Do not use the device in areas where wireless devices are prohibited. •...

  • Page 17: Operating Temperature

    Disposal and recycling information At TCL, we continually strive to improve our operations and products, and minimize our impact on the environment. This symbol on your device and/or its accessories indicates that this device should not be disposed of with household waste.

  • Page 18: Troubleshooting

    • If you are using an Ethernet connection, check if the network is working properly. • Make sure the Wi‑Fi indicator of your LinkZone is solid blue. I can't find the Wi‑Fi name of the LinkZone on my wireless device.
  • Page 19 PUK code. If the PUK code is entered incorrectly 10 times, the SIM card will be locked permanently. TCL and the TCL logo are trademarks of TCL Communication Ltd. All other trademarks and trade names are the property of their respective owners.
