- Page 1 V1.0 | MW63 www.tcl.move.com CJB70M002AAA...
- Page 2 Overview Buttons • Press and hold for 3 seconds to power on or off your Power button device. • Press and hold for 10 seconds to reboot your device. Connect to a power supply (5 V/1 A) using the provided Micro USB port USB cable.
-
Page 3: Status Led
Status LED Wi-Fi • Solid blue: Wi-Fi is enabled. Indicator • Off: Wi-Fi is off. • Solid blue: new SMS Indicator message(s). • Flashing blue: SMS inbox is full. • Off: No new message. • Solid blue: battery Battery Signal •... - Page 4 Insert the SIM Card & Battery Note: Heed the orientation of your SIM card. Make sure you align the SIM card with the slot and slide it into the slot until it sits properly.
- Page 5 Power On Press and hold the power button for 3 seconds to turn on your LinkZone.
-
Page 6: Connect To The Network
Connect to the Network MW63-xxxx Connection ********* Security Key: *********** Cancel Select network MW63-xxxx MW63-XXXX Input password xxxxxxxxx *********** xxxxxxxxx xxxxxxxxx xxxxxxxxx Note: The default Wi-Fi name and password can be found on the label inside your LINKZONE. -
Page 7: Configure The Network
Configure the Network Note: For the default login information, refer to the label inside your LinkZone. To configure the LINKZONE Wi-Fi network: 1. Open a web browser on the device connected to the LINKZONE network. 2. Go to the login website and follow the on-screen instructions. The login website can be found on the label beneath the battery. -
Page 8: Important Safety Information
Important Safety Information Read all the safety information before using your device. Failure to follow these safety instructions could result in injury, or damage to your device or other property. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. -
Page 9: Power Adapter
Power adapter Charge your device with the supplied USB cable. Only charge with an adapter that is compliant with the applicable international and regional safety standards. The adapter shall be CE-approved. Using other adapters could cause damage to the device or pose a risk of injury or death. Keep the adapter in a well-ventilated area when it is plugged into an electrical outlet. -
Page 10: Operating Environment
• Do not puncture, disassemble, or short circuit the battery. • The battery must be recycled or disposed of separately from household waste. Dispose of batteries according to your local environmental laws and guidelines. • Replace the battery only with another qualified battery. Use of an unqualified battery may present a risk of fire, explosion, leakage, or other hazard. -
Page 11: Compliance Information
UMTS 1800MHz + Wi-Fi 2.4GHz 1.56 W/kg Limb SAR (0 mm) LTE Band 7 + Wi-Fi 2.4GHz 3.47 W/kg For more information, go to: www.tcl.com Frequency band This product operates with the following frequency bands and maximum radio- frequency power:... - Page 12 Frequency band Maximum radio-frequency power UMTS Band 1 (2100MHz) 24.5 dBm UMTS Band 3 (1800MHz) 24.5 dBm UMTS Band 8 (900MHz) 24.0 dBm LTE FDD B1/3/7/8/20 23.5 dBm (2100/1800/2600/900/800 MHz) LTE TDD B38 (2600 MHz) 23.5 dBm 802.11 b/g/n 2.4GHz 19.43 dBm 802.11 a/n/ac 5150 –...
- Page 13 5350 MHz of Wi-Fi 5GHz can be used inside buildings only. The 5470-5725 band of Wi-Fi 5GHz can’t be used in road vehicles, trains, aircraft or UAS (Unmanned Aircraft System) scenarios for the following countries: (NI) Third countries...
-
Page 14: Regulatory Compliance
Regulatory compliance Hereby, TCL Communication Ltd. declares that the radio equipment type TCL MW63 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at: https:/ /www.tcl.com/global/en/service-support-mobile/... - Page 15 Waste disposal and recycling The device, accessory and battery must be disposed of in accordance with locally applicable environmental regulations. This symbol on your device, the battery, and the accessories means that these products must be taken to: • Municipal waste disposal centres with specific bins. •...
-
Page 16: Support Information
Website www.tcl.com/global https:/ /www.tcl.com/global/en/mobile-support/ Hotline hotline&service-center.html Manufacturer TCL Communication Ltd. 5/F, Building 22E, 22 Science Park East Avenue, Hong Address Kong Science Park, Shatin, NT, Hong Kong Limited warranty Additional rights under consumer laws As the consumer You may have legal (statutory) rights that are in addition to those set out in this limited warrant offered by Manufacturer voluntarily, such as the consumer laws of the country in which you live (“Consumer Rights”). - Page 17 Manufacturer will, or will not, provide a remedy for the TCL device. This limited warranty does not limit or exclude any of your Consumer Rights relating to the TCL device. Manufacturer warranty coverage This Manufacturer’s Limited Warranty sets forth the warranty responsibilities...
- Page 18 TCL device 24 months TCL accessories : USB cable, 12 months battery In case of any defect of your device which prevents you from normal use thereof, you must immediately inform your vendor and present your device with your proof of purchase.
- Page 19 You. If your TCL device is returned during the warranty period, but your TCL device is not covered under this limited warranty, terms and charges may apply for any...
-
Page 20: Back Up Your Data
If you do not live in the country where the TCL device was originally sold to you, then: (a) Warranty repair or service may not be possible. (b) You may be required to agree to terms and/or to pay certain costs (including but not limited to, shipping and handling costs). - Page 21 During the servicing (repair or replacement), content on your TCL device may be deleted, reformatted or configured as originally purchased (subject to then current updates and upgrades of software), and peripherals removed may not be returned to you. This limited warranty does not cover the backup, recovery or reinstallation of your data, files and applications to the TCL device.
