A
ALLEN BOLT
M6 X 30 (8 PCS.)
STEP 1.
PLACE ROUND DINING TABLE BODY
IN A SOFT, AND FLAT SURFACE.
ASSEMBLE THE METAL LEG Y (5) TO
THE HOLE IN THE RING METAL LEG X
(4) USING THE PROVIDED
ALLEN BOLT (A), SPRING WASHER (E),
FLAT WASHER (D) AND ALLEN KEY (F).
HARDWARE LIST
B
C
ALLEN BOLT
ALLEN BOLT
M6 X 40 (4 PCS.)
M6 X 70 (4 PCS.)
1
2
TOP PANEL (1 Pc) WOOD LEG (1 Pc)
Assembly Instruction
D
E
ALLEN KEY L4
FLAT W. M6
SPRING W. M6
(FOR ALLEN BOLT)
16 PCS.
16 PCS.
PART INSIDE
3
4
METAL STREACHER
METAL LEG X (1 Pc)
(1 Pc)
STEP 2.
INSTALL METAL STREACHER (3) TO THE PLATE ON
THE METAL LEG X (4) AND METAL LEG Y (5) USING
THE PROVIDED ALLEN BOLT (A), SPRING WASHER (E),
FLAT WASHER (D) AND ALLEN KEY (F).
Page 1 of 2
F
1 PC.
5
METAL LEG Y (2 Pcs)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Howard Miller HEKMAN 24819
Summary of Contents for Howard Miller HEKMAN 24819
- Page 1 HARDWARE LIST ALLEN KEY L4 ALLEN BOLT ALLEN BOLT ALLEN BOLT FLAT W. M6 SPRING W. M6 (FOR ALLEN BOLT) M6 X 30 (8 PCS.) M6 X 40 (4 PCS.) M6 X 70 (4 PCS.) 16 PCS. 16 PCS. 1 PC. PART INSIDE METAL STREACHER TOP PANEL (1 Pc) WOOD LEG (1 Pc)
- Page 2 STEP 3. INSTALL METAL LEG X (4) AND METAL LEG Y (5) TO THE HOLE WHICH UNDER THE TOP PANEL (1) USING THE PROVIDED ALLEN BOLT (B), SPRING WASHER (E), FLAT WASHER (D) AND ALLEN KEY (F). STEP 4. INSTALL WOOD LEG (2) TO THE HOLE IN THE METAL LEG X (4) AND METAL LEG Y (5) USING THE PROVIDED ALLEN BOLT (C), SPRING...
