A
B
HALFMOON
BOLT M8 x 100
WASHER M8
8 PCS.
8 PCS.
1
HEADBOARD (1 Pc)
FOOTBOARD (1 Pc)
STEP 1:
INSERT CONNECTING BOLT (A) & DOWEL (H) TO INSERT THAT ARE FIXED IN
HEADBOARD (1) AND FOOTBOARD (2). PLACE SIDE RAILS (3) IN POSITION USING
THE HALFMOON WASHER (B), SPRING WASHER (C), HEX BOLT (D) USING
WRENCH KEY (G) PROVIDED.
HARDWARE LIST
C
D
SPRING W. M8
HEXAGONAL BOLT
8 PCS
.
M8 (8 PCS.)
PART INSIDE
2
3
SIDE RAILS (2 Pcs)
Assembly Instruction
Page 1 of 2
E
F
ALLEN KEY L4
ALLEN BOLT
(FOR ALLEN BOLT)
(FOR HEXA BOLT)
M6 X 40 (4 PCS.)
1 PC.
4
5
SUPPORT SLATS
SLATS (4 Pcs)
(Short) (4 Pcs)
G
H
WRENCH KEY
DOWEL
Ø10 X 40 mm
Ø8 X 1
1 PC.
4 PCS.
SUPPORT SLATS
(Long) (4 Pcs)
A
H
B
C
D
G
I
SCREW
1
" (8 PCS.)
2
Advertisement
Table of Contents
Related Manuals for Howard Miller HEKMAN 24865
Summary of Contents for Howard Miller HEKMAN 24865
- Page 1 HARDWARE LIST ALLEN KEY L4 WRENCH KEY DOWEL SCREW HALFMOON BOLT M8 x 100 SPRING W. M8 HEXAGONAL BOLT ALLEN BOLT (FOR ALLEN BOLT) (FOR HEXA BOLT) WASHER M8 Ø10 X 40 mm Ø8 X 1 " (8 PCS.) 8 PCS. 8 PCS M8 (8 PCS.) M6 X 40 (4 PCS.)
- Page 2 STEP 2: PLACE SLATS IN THE WOOD RAIL BRACKET FOUND INSIDE THE SIDE RAILS USING SCREW (I) AND TIGHTEN WITH SCREW DRIVER (NOT INCLUDED) . ATTACH SUPPORT LEGS TO SLATS, FIX WITH ALLEN BOLT (D) AND TIGHTEN USING ALLEN KEY L4 (F). IF THE BED SUPPORTS ARE NOT LEVEL WITH THE FLOOR, ADJUST THE ADJUSTABLE LEVELERS IN THE BOTTOM OF THE LEG SUPPORTS.
