- Page 1 User Manual 7 Bank 4 Channel Multiplexer Module (Model No. 40-655A) Issue 1.0 March 2019 pickeringtest.com pickering 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page (1)
- Page 2 © COPYRIGHT (2019) PICKERING INTERFACES. ALL RIGHTS RESERVED. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
- Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.
-
Page 4: Product Safety
If this product is heavy reference should be made to the safety instructions for provisions of lifting and moving. STATIC SENSITIVE To indicate that static sensitive devices are present and handling precautions should be followed. REED RELAY MODULE 40-110/115/120/125 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page (IV) Page (IV) -
Page 5: Table Of Contents
Programming Options For Pickering PXI Modules ....4.1 Module Architecture ..............4.2 Programming The Module ............4.3 Section 5 Connector Information ..............5.1 Section 6 Trouble Shooting .................6.1 Section 7 Maintenance Information ............7.1 Relay Lookup Tables .............7.1 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page (V) - Page 6 THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page (VI)
-
Page 7: Warnings And Cautions
Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale. This module must not be used for the switching of Mains Circuits. For the switching of voltages up to the module’s full specification, Secondary Circuit power supplies and the Device Under Test must... - Page 8 • For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on the front of the unit. 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579...
- Page 9 It can be configured in many multiplexer switching formats (see schematic overleaf), for example 56-channel 1-pole, 28-channel 2-pole, etc. The 40-655A can be either factory configured or later re-configured by the user to form a different multiplexer function. The 40-655A can be operated as a conventional multiplexer with break-before-make action when a new channel is selected.
-
Page 10: Technical Specification
Specifications 7 Bank, 4 Channel MUX – 40-655A Relay Type The 40-655A is fitted with electro-mechanical signal relays, gold clad silver alloy contacts. A spare relay is built onto the circuit board to allow easy maintenance with minimum downtime. BANK 1... - Page 11 For further assistance, please contact your local Pickering sales office. Product Customization Pickering PXI modules are designed and manufactured on our own Mating Connectors & Cabling flexible manufacturing lines, giving complete product control and For connection accessories for the 40-655A module please enabling simple customization to meet very specific requirements.
- Page 12 We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families with 1200+ products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules. Connectors & Backshells...
- Page 13 7 Bank, 4 Channel MUX – 40-655A Programming Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of Windows and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os...
- Page 14 SECTION 1 - TECHNICAL SPECIFICATION pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 1.6...
-
Page 15: Functional Description
COMPACT PCI CONNECTOR CONTROL RELAY LOGIC DRIVER U3, U4, U5, U6 BRIDGE TERMINATING RESISTORS R4 TO R15 MODULE CONFIGURATION PCI BRIDGE CONFIGURATION Figure 2.1 - Multiplexer Module 40-655A: Functional Block Diagram 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 2.1... -
Page 16: Guidance On Using The Module
GUIDANCE ON USING THE MODULE The 40-655A multiplexer module is configured to a particular configuration with hard wired links LK1 to LK14 which connect the common signals from each bank to the “Com H”, “Com L” and “1W Loref” terminals. All the links are factory fitted but can be removed if a particular bank is not required. -
Page 17: Installation
Modular products require installation in a suitable PXI/LXI chassis. The module is designed for indoor use only. PREOPERATION CHECKS (UNPACKING) 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident. -
Page 18: Hardware Installation
For a system comprising more than one chassis, turn ON the last chassis in the system followed by the penultimate, etc, and finally turn ON the external controller or chassis containing the system controller. 9. For Pickering Interfaces modular LXI installation there is no requirement to use any particular power up sequence. -
Page 19: Testing Operation
Figure 3.2 - General Soft Front Panel Icon A selector panel will appear, listing all installed Pickering PCI, PXI or LXI switch cards and resistor cards. Click on the card you wish to control, and a graphical control panel is presented allowing operation of the card. - Page 20 SECTION 3 - INSTALLATION pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 3.4...
-
Page 21: Programming Guide
SECTION 4 - PROGRAMMING GUIDE PROGRAMMING OPTIONS FOR PICKERING INTERFACES PXI MODULES For information on the installation and use of drivers and the programming of Pickering’s products in various software environments, please refer to the Software User Manual. This is available as a download from: https://www.pickeringtest.com/support/software-drivers-and-downloads... -
Page 22: Module Architecture
MODULE ARCHITECTURE In its default configuration, the 40-655A has all seven banks connected together to form a single bank multiplexer with 28-channels of 2-pole switching. Connections are made by operating a channel relay to make a connection between the common terminal and the corresponding channel terminal. When a relay is operated, both poles of the corresponding channel are activated simultaneously. -
Page 23: Programming The Module
Once the drivers are installed the manual “Sys40Prg.pdf” and driver help files which fully describes these functions can be found in the Pickering folder(s) or the Pickering entries on your Start Menu. The card must be opened before use and closed after using the following function calls: Direct I/O Driver - Open with PIL_OpenCards or PIL_OpenSpecifiedCard and close with PIL_CloseCards or PIL_CloseSpecifiedCards respectively. - Page 24 SECTION 4 - PROGRAMMING GUIDE pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 4.4...
- Page 25 103.2 701.2 502.1 303.2 103.1 701.1 501.2 303.1 102.2 C7.2 501.1 302.2 102.1 C7.1 C5.2 302.1 101.2 604.2 C5.1 301.2 101.1 604.1 404.2 301.1 C1.2 603.2 404.1 C3.2 C1.1 603.1 C3.1 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 5.1...
- Page 26 SECTION 5 - CONNECTOR INFORMATION pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 5.2...
-
Page 27: Trouble Shooting
PCI configuration, highlighting any potential configuration problems. Specific details of all installed Pickering switch cards are included. All the installed Pickering switch cards should be listed in the “Pilpxi information” section - if one or more cards is missing it may be possible to determine the reason by referring to the PCI configuration dump contained in the report, but interpretation of this information is far from straightforward, and the best course is to contact Pickering support: support@pickeringtest.com, if possible... - Page 28 SECTION 6 - TROUBLE SHOOTING pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 6.2...
-
Page 29: Maintenance Information
For PXI modules which are supported in one of Pickering Interfaces’ Modular LXI Chassis (such as the 60-102B and 60-103B) no module software update is required. If the module was introduced after the LXI chassis was manufactured the module may not be recognized, in this case the chassis firmware may need upgrading. - Page 30 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.1 - Relay Look-Up Table: 40-655A-002 40-655A-002 - 7-Bank, 4-Channel, 2-Pole Multiplexer Switch Function Relay No. Switch Function Relay No. Channel 101.1 Channel 501.1 RL17 Channel 101.2 Channel 501.2 Channel 102.1 Channel 502.1 RL18 Channel 102.2...
- Page 31 SECTION 7 - MAINTENANCE INFORMATION pickering RL29 RL30 Figure 7.1 - 40-655A Multiplexer Module - Component Layout 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 7.3...
- Page 32 SECTION 7 - MAINTENANCE INFORMATION pickering THIS PAGE INTENTIONALLY BLANK 7 BANK 4 CHANNEL MULTIPLEXER MODULE 40-655A Page 7.4...
