x-IMU3 User Manual v1.7
January 5, 2024

2.2 Housing

The housing interfaces are annotated in Figure 3. A detailed mechanical drawing describing the housing
dimensions is available on the product
1
1. Power button
2. USB-C connector
3. LED

2.2.1 IP67 rating

The Ingress Protection 67 (IP67) rating is an international standard that describes the ability of the housing to
protect against the ingress of solid particles and water. The first digit, 6 indicates complete protection against
dust and solid particles. The second digit, 7 indicates protection from water for a maximum depth of 1 meter
for up to 30 minutes.
In practical terms, this means that the housing can be used outdoors in all weather conditions and that it
will survive accidental or temporary submersion in water. The housing should not be used in underwater
applications.
web page.
2
3
Figure 3: Housing
