II
RS800 Series
Remote Engine Starting System
INSTALLATION INSTRUCTIONS
To ease and reduce installation time, we suggest you READ THIS MANUAL and consider the following points before
beginning your installation:
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS,
ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY).
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These
components include: The module itself, valet/program button, possible extra relays, and antenna/receiver.
DAMAGE resulting from incorrect installation or failure to follow guidelines stated in this book will not be covered under
warranty and subject to repair or replacement charges.
USE A VOLT/OHM METER to test and locate all connections. Test Lights can damage a vehicle's computer systems.
Record all color codes of vehicle wiring to be used for reference. This will save time by not having to re-test the same
wires over again.
ADDITIONAL PARTS, which are not included with this unit, may be needed for your particular vehicle. . These items may
include extra relays (Part#CS-402A), General Motors Anti-Theft System Bypass modules for Vats / Passkey® / Passlock®
Systems, (Part# CS-GMATA II) or Transponder Anti-Theft Adapter modules (Part # CS-TATA).
TECHNICAL SUPPORT: 1-800-998-6880
Monday - Friday 8:00am - 4:30pm Pacific Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 09.10.01
PRE-INSTALLATION CONSIDERATIONS
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CrimeStopper RS800

Summary of Contents for CrimeStopper RS800

  • Page 1 Monday - Friday 8:00am - 4:30pm Pacific Time Web Site: www.crimestopper.com E-mail: tech-support@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV A 09.10.01 This device complies with FCC Rules part 15. Operation is subject to...

  • Page 2: Installation Cautions & Warnings

    A stuck throttle will cause severe engine damage DO NOT extend the RS800 Series II Ignition harness length. Mount the module so that main harness reaches all ignition switch wiring. Extending these wires could result in poor performance.
  • Page 3 YELLOW / YELLOW/WHITE (-) IGN. & (-) ACC. OUTPUTS (GROUND WHEN RUNNING): YELLOW PIN 4: YELLOW/BLACK: (-) ANTI-GRIND/STARTER KILL OUTPUT (OPTIONAL) Use this wire for the negative side of the Anti-Grind/Starter Disable relay. It can also be used as a sensor disable circuit for a host alarm.
  • Page 4 Connect Pink wire to indicator circuit that shows +12 volts while the “WAIT TO START LAMP” is on. When this wire is used, the RS800 Series II will wait until light turns off before attempting a remote start. Note: For vehicles that have a Negative Wait to Start lamp An extra relay may be required.

  • Page 5: Ignition Switch Wiring

    NOTE: Heavy duty/High Current Ignition circuits greater than 30 AMPS, such as those found on Work or Industrial vehicles, require high-current relays. DO NOT use the outputs of the RS800 Series II for High-Current systems or you will risk damaging the unit and creating a hazardous condition! Use Part #CS-403 relays for circuits up to 70 amps.

  • Page 6: Power Door Lock Wiring

    3 PIN DOOR LOCK PLUG: PIN 1: GREEN: (-) Negative pulse for LOCK PIN 2: RED: +12V Coil Power for external relays TERM 86. PIN 3: BLUE: (-) Negative pulse for UNLOCK DETERMINING DOOR LOCK TYPE: We recommend determining the type of locking system the vehicle has before connecting any wires.
  • Page 7 IMPROVED “SMART” TACHLESS MODE This RS800 Series II system includes a unique voltage monitor system called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage reference on the vehicle every time remote start is requested.
  • Page 8 TACH (RPM) REFERENCE MODE / TACH FINDER MODE / TACH PROGRAMMING Tach Reference Mode provides reliable remote starting performance though engine speed sensing. When using Tach Reference Mode, the Red/White wire is used for Tach signal [Engine RPM] input. Most modern engines include various points where the Engine Speed [Tach] or A/C signal may be obtained.

  • Page 9: Transmitter Programming

    This unit automatically switch out of “Smart Tachless” Mode when Tach is programmed. Transmitter Code Learning: Note: All transmitter codes must be learned at time of programming!! The RS800 allows storage of up to 4 different transmitter codes. 1. Open Hood. (Ground Gray wire.) 2.

  • Page 10: Option Programming

    This system has several installer programmable features as listed in the chart below. Option Programming: 1. Open hood (Ground the Gray wire if no hood pin is installed). 2. Turn Key to the ON position 3. Press program button 5 times, after a few seconds the unit will flash the lights 5 times. 4.

  • Page 11: Remote Start Troubleshooting

    REMOTE START TROUBLESHOOTING UNIT FLASHES LIGHTS ONCE AND WILL NOT ATTEMPT A START: The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for about 4 seconds until LED goes out. The unit is now out of valet mode and should perform a remote start. UNIT FLASHES LIGHTS TWICE AND WILL NOT ATTEMPT A START: The unit reads a fault at the Brake (Purple wire is active) or the Hood is OPEN (Gray wire grounded).
  • Page 12 ENGINE TRANSMISSION COIL PARKING LIGHTS 12A MAX. SMART TACH JUMPERS RS-800ER Series II ANTENNA/ RECEIVER PLUG ANTENNA (-) UNLOCK OUTPUT PROGRAM/ OVERRIDE +12 V FOR RELAYS SWITCH (-) LOCK OUTPUT NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL IGN 1 BROWN GRAY...
