Operating Instructions
III
RS800 Series
Remote Engine Starting System
INSTALLATION INSTRUCTIONS
To ease and reduce installation time, we suggest you READ THIS MANUAL and consider the following points before
beginning your installation:
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS,
ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY).
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These
components include: The module itself, valet/program button, possible extra relays, and antenna/receiver.
DAMAGE resulting from incorrect installation or failure to follow guidelines stated in this book will not be covered under
warranty and subject to repair or replacement charges.
USE A VOLT/OHM METER to test and locate all connections. Test Lights can damage a vehicle's computer systems.
Record all color codes of vehicle wiring to be used for reference. This will save time by not having to re-test the same
wires over again.
ADDITIONAL PARTS, which are not included with this unit, may be needed for your particular vehicle. . These items
may include extra relays (Part#CS-402A), and/or Anti-Theft System Bypass modules.
TECHNICAL SUPPORT: 1-800-998-6880
Monday - Friday 8:00am - 4:30pm Pacific Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 9/2002
PRE-INSTALLATION CONSIDERATIONS
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper RS-800.III
Summary of Contents for CrimeStopper RS-800.III
-
Page 1: Installation Instructions
Monday - Friday 8:00am - 4:30pm Pacific Time Web Site: www.crimestopper.com E-mail: tech-support@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV A 9/2002 This device complies with FCC Rules part 15. Operation is subject to... -
Page 2: Installation Cautions & Warnings
INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL THE RS800 in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property. WARNING: This system does NOT have engine over-rev protection. Make certain vehicle throttle linkage operates properly and does not stick. - Page 3 YELLOW / YELLOW/WHITE (-) IGN. & (-) ACC. OUTPUTS (GROUND WHEN RUNNING): YELLOW PIN 4: YELLOW/BLACK: (-) ANTI-GRIND/STARTER KILL OUTPUT (OPTIONAL) Use this wire for the negative side of the Anti-Grind/Starter Disable relay. It can also be used as a sensor disable circuit for a host alarm.
- Page 4 WIRING INSTRUCTIONS PIN 5: EMPTY (NOT USED) PIN 6: GREEN: INSTANT START ACTIVATION BY NEGATIVE (-) TRIGGER INPUT (OPTIONAL ACCESSORY) This wire allows the Auxiliary Channel Output of a separate (host) Alarm or Keyless Entry System to activate a Remote Start.
-
Page 5: Ignition Switch Wiring
6 PIN HIGH-CURRENT CONNECTORS: PIN 1: BROWN 14 GA.: STARTER OUTPUT (30A) PIN 2: GRAY 14 GA.: ACCESSORY / IGNITION 2 (30A) PIN 3: RED 14 GA.: BATTERY CONSTANT FUSED (30A) PIN 4: RED 14 GA.: BATTERY CONSTANT FUSED (30A) PIN 5: PINK 14 GA.: IGNITION 1 (30A) PIN 6: WHITE 18 GA.:... -
Page 6: Power Door Lock Wiring
3 PIN DOOR LOCK PLUG: PIN 1: GREEN: (-) Negative pulse for LOCK PIN 2: RED: +12V Coil Power for external relays TERM 86. PIN 3: BLUE: (-) Negative pulse for UNLOCK DETERMINING DOOR LOCK TYPE: We recommend determining the type of locking system the vehicle has before connecting any wires. -
Page 7: "Smart" Tachless Mode
REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH This RS800 system includes a unique voltage monitor system called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. This module actively monitor the voltage reference on the vehicle every time remote start is requested. - Page 8 TACH (RPM) REFERENCE MODE / TACH FINDER MODE / TACH PROGRAMMING Tach Reference Mode provides reliable remote starting performance though engine speed sensing. When using Tach Reference Mode, the Red/White wire is used for Tach signal [Engine RPM] input. Most modern engines include various points where the Engine Speed [Tach] or A/C signal may be obtained.
-
Page 9: Transmitter Programming
NOT be a good location for Tach source due to RF noise or Computer Data. The RS-800 may not detect a clean signal. Of you are unable to locate a Tach Source, call Crimestopper for Tech Support: (800) 998-6880. -
Page 10: Option Programming
This system has several installer programmable features as listed in the chart below. Option Programming: 1. Open hood (Ground the Gray wire if no hood pin is installed). 2. Turn Key to the ON position 3. Press program button 5 times, after a few seconds the unit will flash the lights 5 times. 4. -
Page 11: Remote Start Troubleshooting
REMOTE START TROUBLESHOOTING UNIT FLASHES LIGHTS ONCE AND WILL NOT ATTEMPT A START: The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for about 4 seconds until LED goes out. The unit is now out of valet mode and should perform a remote start. UNIT FLASHES LIGHTS TWICE AND WILL NOT ATTEMPT A START: The unit reads a fault at the Brake (Purple wire is active) or the Hood is OPEN (Gray wire grounded). - Page 12 ENGINE TRANSMISSION COIL PARKING LIGHTS 12A MAX. SMART TACH JUMPERS RS-800 Series III ANTENNA/ RECEIVER PLUG ANTENNA (-) UNLOCK OUTPUT PROGRAM/ OVERRIDE +12 V FOR RELAYS SWITCH (-) LOCK OUTPUT NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL IGN 1 BROWN GRAY...
