IV
RS-800 Series
Remote Engine Starting System

INSTALLATION INSTRUCTIONS

To ease and reduce installation time, we suggest you READ THIS MANUAL and consider the following points before
beginning your installation:
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS,
ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY).
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These
components include: The module itself, valet/program button, possible extra relays, and antenna/receiver.
DAMAGE resulting from incorrect installation or failure to follow guidelines stated in this book will not be covered under
warranty and subject to repair or replacement charges.
USE A VOLT/OHM METER to test and locate all connections. Test Lights can damage a vehicle's computer systems.
Record all color codes of vehicle wiring to be used for reference. This will save time by not having to re-test the same
wires over again.
ADDITIONAL PARTS, which are not included with this unit, may be needed for your particular vehicle. . These items
may include extra relays (Part#CS-402A), and/or Anti-Theft System Bypass modules.
TECHNICAL SUPPORT: 1-800-998-6880
Monday - Friday 8:00am - 4:30pm Pacific Time
Web Site: www.crimestopper.com
E-mail: email@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 08/2003
PRE-INSTALLATION CONSIDERATIONS
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-800.IV and is the answer not in the manual?

Questions and answers

Related Manuals for CrimeStopper RS-800.IV

Summary of Contents for CrimeStopper RS-800.IV

  • Page 1: Installation Instructions

    Monday - Friday 8:00am - 4:30pm Pacific Time Web Site: www.crimestopper.com E-mail: email@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV A 08/2003 This device complies with FCC Rules part 15. Operation is subject to...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Pre-Installation Considerations…………...……...………………………………………………………………Front Cover Cautions & Warnings…….…………..….……..…..……………………………………………………………….…..……2 Wiring……..…………………………...……………………………………………………………………………….…….3-5 Wiring High-Current Connector…….………………...…………………………………………………………………...5-6 Smart Tachless, Tach Reference & Tach Finder Modes…………………..…..………...…...…………………….……6-8 Transmitter Programming……………………….…………………….……………..………...………………………...….8 2 Vehicle Operation.……………………………….……………………………………...…………………….……………9 Option Programming………..……………………….…………………………………...……………..………..…………9-10 Troubleshooting “Before You Call” Section……………..…………………………..………………….……..….……….11 System Diagram…………………………………………………….……………………………………………….….……12 INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL THE RS800 in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property.

  • Page 3: Wiring

    2 PIN PLUG-PROGRAM/OVERRIDE SWITCH: This switch is used for programming features, remote transmitters & valet mode. 2 PIN PLUG-(OPTIONAL) LED: The LED is used as an indicator for Valet mode. PIN 1 & 2: YELLOW / YELLOW/WHITE: (-) IGN / (-) ACC OUTPUTS (FOR ADDING RELAYS) Use these wires when the vehicle requires a second IGNITION or ACCESSORY circuit to be activated.
  • Page 4 PIN 4: YELLOW/BLACK: (-) ANTI-GRIND/STARTER KILL OUTPUT (OPTIONAL) Use this wire for the negative side of the Anti-Grind/Starter Disable relay. It can also be used as a sensor disable circuit for a host alarm. This output activates whenever a remote start is requested. MOTOR PIN 5: EMPTY (NOT USED) PIN 6: GREEN: INSTANT START ACTIVATION BY NEGATIVE (-) TRIGGER INPUT (OPTIONAL ACCESSORY)

  • Page 5: Wiring High-Current Connector

    PIN 9: PURPLE: (+12V) BRAKE RESET Connect the Purple wire to the side of brake pedal switch that shows +12 volts ONLY when pedal is depressed. This will turn off the remote start if someone attempts to drive the car without the keys or if the Ignition key is not turned on all the way.

  • Page 6: Smart Tachless, Tach Reference & Tach Finder Modes

    WIRING: HIGH CURRENT CONNECTOR PARKING LIGHTS +10A MAX. FUEL PUMP COIL 2nd IGN 1 2nd IGN 2 TRANSMISSION This CoolStart system includes a unique voltage monitor called “Smart Tachless” mode that allows this unit to efficiently start an engine without the use of a Tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested.
  • Page 7 “SMART TACHLESS” ADJUSTMENT: In the event “Smart Tachless” over-cranks or under-cranks your starter, the settings can be changed. The purpose of adjusting the “Smart Tachless” Mode is to raise or lower the voltage reference threshold from the 90% default point. Raising or lowering this 90% point should increase or decrease your cranking time respectively.

  • Page 8: Transmitter Programming

    TACH FINDER MODE & TACH PROGRAMMING TACH FINDER (OPTIONAL): 1. Open hood (or ground Gray hood pin wire if no hood pin is installed) 2. Start Engine with the key. 3. Press the Program button for 2 seconds 4. Lights will flash if the Tach wire is connected to a valid tach source. If lights do not flash, then try a different wire. 5.

  • Page 9: Vehicle Operation

    The RS-800 IV system can be used for 2-car operation. A single RS800 IV remote control can operate two independent vehicles with RS800 IV systems installed. SETUP: 1. Using the switch on the side of the remote set your controller to Car II. 2.

  • Page 10: Option Programming

    Option Option Description NOT USED NOT USED NOT USED Engine Monitoring Remote Start Engine Run Time Smart Tachless Voltage Adjust 80-100% (Only when option #4 is set to Tachless) Option reset OPTIONS DESCRIPTIONS: OPTIONS #1-3 ARE NOT USED. 4. Engine Monitoring: This option sets how the system monitors your engine.

  • Page 11: Remote Start Troubleshooting

    REMOTE START TROUBLESHOOTING UNIT FLASHES LIGHTS ONCE AND WILL NOT ATTEMPT A START: The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for about 5 seconds until LED goes out. The unit is now out of valet mode and should perform a remote start. UNIT FLASHES LIGHTS TWICE AND WILL NOT ATTEMPT A START: The unit reads a fault at the Brake (Purple wire is active) or the Hood is OPEN (Gray wire grounded).

  • Page 12: System Diagram

    ENGINE TRANSMISSION COIL PARKING LIGHTS 10A MAX. RS-800 Series IV ANTENNA/ RECEIVER PLUG ANTENNA OPTIONAL PROGRAM/ OVERRIDE SWITCH NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL IGN 1 BROWN GRAY PINK WHITE NOT USED YELLOW (-)IGN OUT BLACK GROUND GRAY (-) HOOD SWITCH...
