MULTISPAN DIN-63 Operating Manual

OPERATING MANUAL
MULTIRANGE TIMER
DIN-63

LED

All Led are in Red color.
S
M
H
RLY

Connection Diagram

DIN-63
Size (mm)
Display
Power Supply
Operating
Temperature
: Shows that the set time is in seconds.
: Shows that the set time is in minutes.
: Shows that the set time is in hours.
: Shows the relay status.
ON OFF
SWITCH 1,SWITCH 2 & SWITCH 3
for DP & UNIT Selection.
SWITCH SWITCH SWITCH
1
OFF
OFF
ON
ON
OFF
OFF
ON
ON

Technical Specification

Model
3 Digit Seven Segment LED Display
Dirction
0 to 999 Second/Minute/Hours and
Range
Decimal Point Selectable
Output 1 Relay with 2C/O (5 Amps/230V AC)o/p
Relative
Up to 95% RH Non Condensing
Humidity
www.multispanindia.com
1 2 3 4
SWITCH 4 For
Mode selection
ON Delayed OFF
OFF Delayed ON
RANGE
2 3
.999 Sec.
OFF ON
ON
ON 9.99 Sec.
OFF ON
99.9 Sec.
ON ON 999 Sec.
OFF OFF .999 Min.
ON
OFF 99.9 Hr.
OFF OFF
99.9 Min.
OFF 999 Min.
ON
Made in India
Page
-2
DIN-63
76 (H) x 27 (W) x 85 (D) mm
Up & Down Selectable
100 to 270V AC, 50/60Hz
C


C

0° To 55°
L
No1
C1 Nc1
C2 Nc2
No2
N
www.multispanindia.com
Display
