Cyclic Timer

CYL-22

Power Supply :

Output:

Time Range :

230 V AC ±20%,50 Hz

1 Relay O/P (2 C/O, 5A 230 VAC

0.1 sec to 10 hour

MAIN LED

for visualisation of power

supply status

KNOB

for on time setting

KNOB

for off time setting

PIANO SWITCH

for time range selection &

Cyclic on/off mode selection

RELAY OUTPUT

Resistive Load

)

Table of Contents

Do you have a question about the CYL-22 and is the answer not in the manual?

Page 1 Cyclic Timer CYL-22 MAIN LED for visualisation of power supply status KNOB for on time setting KNOB for off time setting PIANO SWITCH for time range selection & Cyclic on/off mode selection RELAY OUTPUT Power Supply : 230 V AC ±20%,50 Hz...
Page 2 Terminal Connection: A1 25 NO 1 NC 1 15 26 NO 2 C2 NC 2 16 28 18 A2 Timing Diagram: Power Cyclic ON OFF Time OFF Time ON Time ON Time OFF Time OFF Time Cyclic OFF ON Time ON Time Dip switch selection: Multiplier...
Page 3 Dimension 22.5 NOTE: All dimension are in mm. 66.35 SAFETY PRECAUTION All safety related codifications, symbols and instructions that appear in this operating manual or on the equipment must be strictly followed to ensure the safety of the operating personnel as well as the instrument. If all the equipment is not handled in a manner specified by the manufacturer, it might impair the protection provided by the equipment.
Page 4 5) Do not connect anything to unused terminals. Multispan reserves the right to change speciﬁcations without prior notice.Printing and typographical errors reserved. Product improvement and upgrade is a constant procedure.
