MULTISPAN DT 10S Manual

Delay Timer
DT 10S , DT 30S, DT 60S, DT 15M, DT 30M, DT 60M
Power Supply :
Output:
Time Range :
230 V AC ±20% ,50 Hz
: 415 V AC ±20% ,50 Hz
1 Relay O/P (1 C/O, 5A 230 VAC
0 to 10 SEC (For DT 10S)
0 to 30 SEC (For DT 30S)
0 to 60 SEC (For DT 60S)
0 to 15 MIN (For DT 15M)
0 to 30 MIN (For DT 30M)
0 to 60 MIN (For DT 60M)
RELAY LED
for visualisation of output
status
KNOB
for on/off delay time setting
MAIN LED
for visualisation of power
supply status
Resistive Load
)
