• FRONT UNIT (BOTTOM VIEW)
FRONT PANEL
FRONT UNIT
BUFFER
(IC507)
Bluetooth MODULE
(IC506)
+3.3 V REGULATOR
(IC508)
RESET IC
(IC509)
2-2
SPEAKER
(SP1: CHASSIS UNIT)
J1
