■ ENTERING THE ADJUSTMENT MODE
1. Right click the CS-A16's icon on the desktop and
select the "Properties".
• The CS-A16 properties window appears.
2. Append " /Expert" to the end of the contents of the
Target field, and then click [OK].
• A space is necessary before slash.
Append " /Expert,"
then click [OK].
3. Boot up the programming software, CS-A16.
4. Connect the transceiver and the PC using with the
OPC-478UC, and then rotate [VOL] turn the power
ON.
5. Read the transceiver data into the PC.
6. Set "Adjust Mode" in the "EXPERT" to "Enable".
Click
7. Write the data to the transceiver.
8. Turn the power OFF, and then disconnect the
OPC-478UC from the transceiver.
9. While holding down [CLR] and [MR], rotate [VOL]
turn the power ON.
• Enter to the adjustment mode.
■ ADJUSTMENT MODE SCREEN
Select "Enable"
4-2
Rotate [VOL] turn the power ON
Adjustment item name
Adjustment frequency
While holding down
