- Page 1 ECS2100-10T/ECS2100-10P/ ECS2100-10PE/ECS2100-28T/ ECS2100-28P/ECS2100-28PP ECS2100-52T 10/28/52-Port Web-Smart Pro Gigabit Ethernet Switch I n s t a l l a t i o n G u i d e ECS2110-26T 26-Port Web-Smart Pro 10G Ethernet Switch www.edge-core.com...
- Page 2 Web-Smart Pro Gigabit Ethernet Switch with 8 10/100/1000BASE-T (RJ-45) 802.3 af/at PoE Ports and 2 Gigabit SFP Ports (PoE Power Budget: 65 W) ECS2100-10P Gigabit Ethernet Switch Web-Smart Pro Gigabit Ethernet Switch with 8 10/100/1000BASE-T (RJ-45) 802.3 af/at PoE Ports...
-
Page 3: How To Use This Guide
How to Use This Guide This guide includes detailed information on the switch hardware, including network ports, power, cabling requirements, as well as plug-in modules and transceivers. This guide also provides general installation guidelines and recommended procedures. To deploy this switch effectively and ensure trouble- free operation it is recommended to first read the relevant sections in this guide so that you are familiar with all its hardware components. - Page 4 How to Use This Guide ◆ Chapter 5 - Port Connections — Includes information on network interfaces, installing optional transceivers, and cabling specifications. ◆ Chapter 6 - Switch Management — Connecting to the switch for management, and information on the system status LEDs. ◆...
- Page 5 How to Use This Guide April 2016 Revision This is the second revision of this guide. This revision includes the following change: ◆ Updated ECS2100-10PE panel image. January 2016 Revision This is the first revision of this guide. – 5 –...
-
Page 6: Table Of Contents
Contents How to Use This Guide Contents Figures Tables 1 Switch Description Overview Power-over-Ethernet Key Hardware Components Key Technical Specifications 2 Installation Overview Package Contents Switch Installation Tasks 3 Switch Chassis General Installation Guidelines Switch Cooling Requirements Rack Cooling How to Install the Switch in a Rack Rack-Mounting Items Rack-Mount Procedure How to Install the Switch on a Shelf or Desktop... - Page 7 Contents 5 Port Connections Cable Labeling and Connection Records Understanding the Port Status LEDs How to Install an SFP/SFP+ Transceiver How to Connect to Twisted-Pair Copper Ports Copper Cabling Guidelines 10/100BASE-TX Pin Assignments 1000BASE-T Assignments Power-over-Ethernet Connection Procedure How to Connect to SFP/SFP+ Fiber Optic Ports Connection Procedure Making 10 Gbps DAC Connections 6 Switch Management...
-
Page 8: Figures
Figures Figure 1: Switch Front Panels Figure 2: Rear Panel Figure 3: Installing the Switch in a Rack Figure 4: Connecting AC Power Figure 5: Connecting DC Power Figure 6: System LEDs Figure 7: Console Port Figure 8: Making a Connection to an RJ-45 Port Figure 9: Switch Cooling (ECS2100-28P and ECS2100-28PP) Figure 10: Switch Cooling (ECS2100-52T) Figure 11: Switch Cooling (ECS2100-10T/10P/10PE, ECS2110-26T and ECS2100-28T) -
Page 9: Tables
Tables Table 1: Key Technical Specifications Table 2: AC Power Supply Specifications Table 3: Port Status LEDs Table 4: Maximum Twisted-Pair Copper Cable Lengths Table 5: 10/100BASE-TX MDI and MDI-X Port Pinouts Table 6: 1000BASE-T MDI and MDI-X Port Pinouts Table 7: ECS2100 Series PoE Power Budget Table 8: Maximum 10 Gigabit Ethernet Fiber Cable Lengths Table 9: Maximum Gigabit Ethernet Fiber Cable Lengths... -
Page 10: Switch Description
CLI-based configuration. Power-over-Ethernet All of the 10/100/1000 Mbps ports on the ECS2100-10P, ECS2100-10PE, ECS2100- 28P, and ECS2100-28PP support both the IEEE 802.3af-2003 and IEEE 802.3at-2009 PoE standards. These switches are excellent choices for supplying power to connected PoE devices such as web cameras, IP telephones, or access points. -
Page 11: Figure 1: Switch Front Panels
ECS2100-10PE ECS2100-10P ECS2100-28T ECS2100-28P ECS2100-28PP ECS2100-52T ECS2110-26T 10/100/1000BASE-T RJ-45 Ports 10/100/1000BASE-T RJ-45 Port LED Gigabit SFP Ports PoE button (ECS2100-10P/ECS2100-10PE/ ECS2100-28P/ECS2100-28PP) RJ-45 Console Port Reset / Factory Default button System LEDs (Power/PoE Max/Diag) 10 Gigabit SFP+ Port – 11 –... - Page 12 “How to Connect to SFP/SFP+ Fiber Optic Ports” on page PoE Button Pressing the PoE button on the ECS2100-10P, ECS2100-10PE, ECS2100-28P, and ECS2100-28PP front panel changes the port LEDs to display PoE status. For more information, see “Understanding the System Status LEDs” on page...
-
Page 13: Figure 2: Rear Panel
Chapter 1 | Switch Description Overview Figure 2: Rear Panel ECS2100-10T ECS2100-10PE ECS2100-10P ECS2110-26T/ECS2100-28T/ECS2100-28P/ECS2100-52T ECS2100-28PP Grounding Terminal AC Power Socket DC Power Socket External Power Supply Connector Cooling Fans and Vents The switch must be installed in a properly cooled and ventilated environment. For more information, see “Switch Cooling Requirements”... -
Page 14: Key Technical Specifications
8 K MAC address entries AC Input Power ECS2100-10T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-10P: AC 100-240 V, 50-60 Hz, 2.1 A ECS2100-28T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-28P: AC 100-240 V, 50-60 Hz, 3.2 A ECS2100-28PP: AC 100-240 V, 50-60 Hz, 5.8 A... - Page 15 (W x D x H): ECS2100-10T: 19.64 x 11.71 x 3.66 cm (7.73 x 4.61 x 1.44 in.) ECS2100-10P: 33.0 x 20.4 x 4.26 cm (12.99 x 8.03 x 1.67 in.) ECS2100-10PE: 24.0 x 15.5 x 2.65 cm (9.44 x 6.10 x 1.04 in.) ECS2100-28T/28P/28PP/52T, ECS2110-26T: 44 x 22 x 4.4cm (17.32 x...
-
Page 16: Installation Overview
Quick Start Guide ◆ Regulatory and Safety Information Optional Item ◆ Console cable—RJ-45 to DB-9 Note: For other documentations include Installation Guide, Web Management Guide, and CLI Reference Guide can be obtained from www.edge-core.com -> support -> download. – 16 –... -
Page 17: Switch Installation Tasks
Chapter 2 | Installation Overview Switch Installation Tasks Switch Installation Tasks Follow these tasks to install the switch in your network. For full details on each task, go to the relevant chapter or section by clicking on the link. Caution: Before installing your switch, first review all the safety statements and guidelines in the Regulatory and Safety Information document. -
Page 18: Figure 4: Connecting Ac Power
Chapter 2 | Installation Overview Switch Installation Tasks Task 3 Connect AC Power to Power On Prior to connecting to AC power, assure to connect the chassis ground connection to a known earth ground. Connect the power cord to the AC socket on the switch and to a grounded, 3-pin, AC power source. -
Page 19: Figure 6: System Leds
Chapter 2 | Installation Overview Switch Installation Tasks Task 4 Verify Switch Operation Verify basic switch operation by checking the system LEDs. When operating normally, the Power and Diag LED should both be on green. If either of these LEDs are on amber, see “Diagnosing LED Indicators”... -
Page 20: Figure 7: Console Port
Chapter 2 | Installation Overview Switch Installation Tasks Through the Console Port The serial port’s configuration requirements are as follows: 115200 bps, 8 characters, no parity, one stop bit, 8 data bits, and no flow control. You can log in to the command-line interface (CLI) using default settings: User “admin”... -
Page 21: Figure 8: Making A Connection To An Rj-45 Port
Chapter 2 | Installation Overview Switch Installation Tasks As connections are made, check the port status LEDs to be sure the links are valid. Go to the chapter “Port Connections” Figure 8: Making a Connection to an RJ-45 Port 10/100/1000BASE-T RJ-45 Port. Twisted-pair Cable with RJ-45 Plug. -
Page 22: Switch Chassis
The installation location should: ◆ be able to maintain its temperature within 0 to 50 ° C/32 to 122 ° F ( 0 to 40 ° C/ 32 to 104 ° F, ECS2100-10P/ECS2100-28PP only) and its humidity within 10% to 90%, non-condensing. ◆... -
Page 23: Switch Cooling Requirements
Figure 9: Switch Cooling (ECS2100-28P and ECS2100-28PP) Figure 10: Switch Cooling (ECS2100-52T) The ECS2100-10T, ECS2100-10P, ECS2100-10PE, ECS2110-26T and ECS2100-28T use a fanless cooling design. The following figure shows the convective airflow from the switch. -
Page 24: Rack Cooling
Chapter 3 | Switch Chassis How to Install the Switch in a Rack Rack Cooling When mounting the switch in an enclosed rack or cabinet, be sure to check the following guidelines to prevent overheating: ◆ Make sure that enough cool air can flow into the enclosure for the equipment it contains. -
Page 25: Rack-Mounting Items
Chapter 3 | Switch Chassis How to Install the Switch in a Rack Rack-Mounting Items Before you start to rack-mount the switch, be sure to have the following items available: ◆ Four mounting screws for each device you plan to install in a rack—these are not included. -
Page 26: Figure 13: Installing The Switch In A Rack
Chapter 3 | Switch Chassis How to Install the Switch in a Rack Figure 13: Installing the Switch in a Rack Rack Mount Screws If installing a single switch only, go to “Power and Grounding” on page If installing multiple switches, repeat steps 1 to 4 to mount the switches following your rack plan. -
Page 27: How To Install The Switch On A Shelf Or Desktop
Chapter 3 | Switch Chassis How to Install the Switch on a Shelf or Desktop How to Install the Switch on a Shelf or Desktop The switch can be installed on any flat surface such as a desktop or shelf. To mount the switch on a flat surface, follow these steps: Attach the four adhesive feet to the bottom of the first switch. - Page 28 Chapter 3 | Switch Chassis How to Install the External Power Supply — External Power Supply EPS460W Install the ECS2100-28PP in a standard 19-inch rack and power on. Install the PS3000 chassis in a standard 19-inch rack. Install one or more EPS460W PSUs in the chassis. The chassis can support up to three EPS460W PSUs.
-
Page 29: Power And Grounding
Power and Grounding This chapter focuses on how to connect AC power to the switch, grounding the chassis, and how to power-on the switch. This chapter includes this sections: ◆ “Switch Power Supply” on page 29 ◆ “Grounding the Chassis” on page 30 ◆... -
Page 30: Grounding The Chassis
Description AC Input ECS2100-10T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-10P: AC 100-240 V, 50-60 Hz, 2.1 A ECS2100-28T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-28P: AC 100-240 V, 50-60 Hz, 3.2 A ECS2100-28PP: AC 100-240 V, 50-60 Hz, 5.8 A... -
Page 31: How To Connect To Ac Power
ECS2100-10T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-10P: AC 100-240 V, 50-60 Hz, 2.1 A ECS2100-28T: AC 100-240 V, 50-60 Hz, 0.5 A ECS2100-28P: AC 100-240 V, 50-60 Hz, 3.2 A ECS2100-28PP: AC 100-240 V, 50-60 Hz, 5.8 A... -
Page 32: How To Connect To Dc Power
Chapter 4 | Power and Grounding How to Connect to DC Power To connect the switch to a power source: Plug the power cord into a grounded, 3-pin, AC power source. Figure 17: AC Power Cord and Power Socket AC Power Cord AC Power Socket Insert the plug on the other end of the power cord directly into the AC input socket on the back of the switch. -
Page 33: Figure 18: Dc Power Cord And Power Socket
Chapter 4 | Power and Grounding How to Connect to DC Power Figure 18: DC Power Cord and Power Socket DC power socket – 33 –... -
Page 34: Port Connections
Port Connections This chapter focuses on making connections to switch network interfaces, including how to install optional transceivers, and details on network cable specifications. This chapter includes these sections: ◆ “Cable Labeling and Connection Records” on page 35 ◆ “Understanding the Port Status LEDs” on page 36 ◆... -
Page 35: Cable Labeling And Connection Records
Chapter 5 | Port Connections Cable Labeling and Connection Records Cable Labeling and Connection Records When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. Doing so will enable you to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption. -
Page 36: Understanding The Port Status Leds
The link is down. 10G SFP+ Ports 25-26 (ECS2110-26T) On/Blinking Green Port has a valid 1000 Mbps/10Gbps link. Blinking indicates traffic on the port. The link is down. PoE Mode button is pressed (ECS2100-10P/ECS2100-10PE/ECS2100-28P/ECS2100-28PE) – 36 –... -
Page 37: How To Install An Sfp/Sfp+ Transceiver
Chapter 5 | Port Connections How to Install an SFP/SFP+ Transceiver How to Install an SFP/SFP+ Transceiver The switch provides slots for optional SFP/SFP+ transceivers. The supported transceiver types are listed below: ◆ 1000BASE-SX ◆ 1000BASE-LX ◆ 1000BASE-ZX ◆ 1000BASE-LHX ◆... -
Page 38: How To Connect To Twisted-Pair Copper Ports
Chapter 5 | Port Connections How to Connect to Twisted-Pair Copper Ports Figure 20: Inserting an SFP/SFP+ Transceiver into a Slot SFP Transceiver SFP Slot Note: To remove a transceiver: First disconnect the network cable, then pull the tab to remove the transceiver from the slot. How to Connect to Twisted-Pair Copper Ports The RJ-45 ports on the switch support automatic MDI/MDI-X pinout configuration, which enables you to use standard straight-through twisted-pair cables to connect... -
Page 39: Copper Cabling Guidelines
Chapter 5 | Port Connections How to Connect to Twisted-Pair Copper Ports Copper Cabling To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX, or 1000BASE-T Guidelines operation. Check the following criteria against the current installation of your network: ◆... -
Page 40: 1000Base-T Assignments
Chapter 5 | Port Connections How to Connect to Twisted-Pair Copper Ports Table 5: 10/100BASE-TX MDI and MDI-X Port Pinouts MDI-X Signal Name MDI Signal Name Receive Data minus (RD-) Transmit Data minus (TD-) GND (Positive V -52V power (Negative V port port GND (Positive V... -
Page 41: Power-Over-Ethernet
PoE standards. These switches are excellent choices for supplying power to connected PoE devices such as web cameras, IP telephones, or access points. Table 7: ECS2100 Series PoE Power Budget ECS2100-10PE ECS2100-10P ECS2100-28P ECS2100-28PP ECS2100- 28PP with one external power supply... -
Page 42: How To Connect To Sfp/Sfp+ Fiber Optic Ports
Chapter 5 | Port Connections How to Connect to SFP/SFP+ Fiber Optic Ports Figure 22: Making Twisted-Pair Connections 1000BASE-T RJ-45 Port Category 5, 5e, or 6 Cable Attach the other end to an available port on the switch. Make sure each twisted pair cable does not exceed 100 meters (328 ft) in length. -
Page 43: Connection Procedure
Chapter 5 | Port Connections How to Connect to SFP/SFP+ Fiber Optic Ports Table 9: Maximum Gigabit Ethernet Fiber Cable Lengths Cable Type Fiber Bandwidth Maximum Cable Length Connector 1000BASE-SX 62.5/125 micron multimode 160 MHz/km 2-220 m (7-722 ft) 200 MHz/km 2-275 m (7-902 ft) 50/125 micron multimode 400 MHz/km... -
Page 44: Figure 23: Making A Connection To An Sfp/Sfp+ Port
Chapter 5 | Port Connections How to Connect to SFP/SFP+ Fiber Optic Ports Remove and keep the fiber port’s rubber plug. When not connected to a fiber cable, the rubber plug should be replaced to protect the optics. Check that the fiber terminators are clean. You can clean the cable plugs by wiping them gently with a clean tissue or cotton ball moistened with a little ethanol. -
Page 45: Making 10 Gbps Dac Connections
Chapter 5 | Port Connections Making 10 Gbps DAC Connections Making 10 Gbps DAC Connections Direct Attach Cable (DAC) is a method of connecting two SFP+ interfaces without using optics and fiber cable. A fixed length of twinax copper cable is terminated at each end with physically-compliant SFP+ transceivers that do not include all their normal electronic and optical components. -
Page 46: Switch Management
Switch Management The switches include a management agent that allows you to configure or monitor the switch using its embedded management software. To manage the switch, you can make a direct connection to the console port (out-of-band), or you can manage it through a network connection (in-band) using Telnet, Secure Shell (SSH), a web browser, or SNMP-based network management software. -
Page 47: Understanding The System Status Leds
Chapter 6 | Switch Management Understanding the System Status LEDs Understanding the System Status LEDs The switch includes a display panel of key system LED indicators. The LEDs, which are located on the front panel, are shown below and described in the following table. -
Page 48: Figure 25: Console Port
Chapter 6 | Switch Management How to Connect to the Console Port Figure 25: Console Port Console port. The following table describes the pin assignments used in the console cable. Table 11: Console Cable Wiring Switch’s RJ-45 Null Modem PC’s 9-Pin Console Port DTE Port 6 RXD (receive data) -
Page 49: Figure 26: Console Port Connection
Chapter 6 | Switch Management How to Connect to the Console Port Figure 26: Console Port Connection Follow these steps to connect to the Console port: Connect one end of the included RJ-45 to DB-9 serial cable to a DB-9 COM port connector on a management PC. -
Page 50: How To Reset The Switch
Chapter 6 | Switch Management How to Reset the Switch Log in to the web interface using the default settings: ◆ Login Name — admin ◆ Password — admin Note that the guest default user login will only allow a user to view switch parameter data. -
Page 51: A Troubleshooting
Troubleshooting Diagnosing LED Indicators Table 12: Troubleshooting Chart Symptom Action ◆ Power LED is Off Check connections between the switch, the power cord, and the AC power outlet. ◆ Check the AC power outlet is supplying 110-240 VAC. ◆ Contact your dealer for assistance. ◆... -
Page 52: Power And Cooling Problems
Chapter A | Troubleshooting Power and Cooling Problems Power and Cooling Problems If a power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the switch shuts down after operating for a continuous period, check for loose power connections, power losses or surges at the power outlet. -
Page 53: Index
Index Numerics installation power requirements 10 Mbps collision domain site requirements 10 Mbps connectivity rules installation troubleshooting 10/100 PIN assignments introduction 1000BASE fiber cable lengths 1000BASE-T PIN assignments 10BASE-T cable lengths laser safety 10GBASE fiber cable lengths LED indicators port location requirements adhesive feet, attaching air flow requirements... - Page 54 Index web-based management – 54 –...
- Page 55 Declaration of Conformity (DoC) can be obtained from www.edge-core.com -> support -> download. ECS2100 Series E102017-AP-R03 149100000273A...
