E7202S CONVECTION OVEN
CAUTION: Read the instructions before
using the appliance
INSTALLATION and
SERVICING INSTRUCTIONS
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these
instructions and National Regulations in force at the time of installation. Particular attention
MUST be paid to –
BS7671 IEE Wiring Regulations
Electricity at Work Regulations
Health And Safety At Work Act
Fire Precautions Act
This appliance has been UKCA/CE marked based on compliance with the relevant Electrical and
Electromagnetic Compatibility (EMC) Regulations/Directives for the voltages stated on the data
plate.
WARNING -THIS APPLIANCE MUST BE EARTHED
On completion of the installation these instructions should be left with the Engineer-in-Charge for
reference during servicing. Further to this, The Users Instructions should be handed over to the
User, having had a demonstration of the operation and cleaning of the appliance.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE
INSTALLING AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE
SPECIFIED PROCEDURES MAY RESULT IN DAMAGE OR THE NEED FOR A SERVICE
CALL.
PREVENTATIVE MAINTENANCE CONTRACT
To obtain maximum performance from this unit regular servicing of the appliance should be undertaken
to ensure correct operation, it is functioning as intended, and safe to use. We recommend servicing in
accordance with SFG20 Maintenance Schedules and as a minimum, after 2,500 hours of use, or annually,
whichever comes
first and
Visits may then be made at agreed intervals to carry out adjustments and repairs.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement parts in a safe
manner, via a licenced waste handler.
Units are designed to be dismantled easily and recycling of all material is
encouraged whenever practicable.
Falcon Foodservice Equipment
Wallace View, Hillfoots Road,
Stirling, FK9 5PY, Scotland
Phone: 01438 363 000
.
that a maintenance contract be arranged with an appointed service contact.
T100677 Ref. 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E7202S and is the answer not in the manual?

Questions and answers

Related Manuals for Falcon E7202S

Summary of Contents for Falcon E7202S

  • Page 1 E7202S CONVECTION OVEN CAUTION: Read the instructions before using the appliance INSTALLATION and SERVICING INSTRUCTIONS IMPORTANT The installer must ensure that the installation of the appliance is in conformity with these instructions and National Regulations in force at the time of installation. Particular attention MUST be paid to –...
  • Page 2 IMPORTANT INFORMATION ELECTRICAL SAFETY AND ADVICE REGARDING SUPPLEMENTARY ELECTRICAL PROTECTION Commercial kitchens and foodservice areas are environments where electrical appliances may be located close to liquids, or operate in and around damp conditions or where restricted movement for installation and service is evident. The installation and periodic inspection of the appliance should only be undertaken by a qualified, skilled and competent electrician;...

  • Page 3: Section 1 - Installation

    SECTION 1 – INSTALLATION UNLESS OTHERWISE STATED, PARTS WHICH HAVE BEEN PROTECTED BY THE MANUFACTURER ARE NOT TO BE ADJUSTED BY THE INSTALLER 1.1 MODEL NUMBER, NETT WEIGHTS and DIMENSIONS MODEL WIDTH mm DEPTH mm HEIGHT mm WEIGHT kg E7202 1.2 SITING The units are suitable for installation upon any flat, horizontal surface.

  • Page 4: Instruction To User

    Periodical testing, repair and fixing wiring connection should only be undertaken by a skilled and competent electrician. This appliance is also provided with a terminal for connection of an external equipotential conductor. This terminal is in effective electrical contact with all fixed exposed metal parts of the appliance, and shall allow the connection ofa conductor having a normal cross-sectional area of up to 10mm².

  • Page 5: Section 2 - Servicing And Maintenance

    1. Model number – found on data plate 2. Serial number – found on data plate 3. Brief description of the issue To contact Falcon for a warranty issue dial (UK only) 01786 455 200 and select Warranty Issues from the menu. Warning BEFORE ATTEMPTING TO UNDERTAKE ANY MAINTENANCE TASK.

  • Page 6: Oven Control Panel

    2.1 OVEN CONTROL PANEL 2.1.1 Control Panel Undo two fixings on underside of oven until location pins allow panel to drop forward. 2.1.2 To Remove Rear Panel a) Slacken fixings behind elongated slots at top of panel. b) Lift panel clear of these fixings. c) Replace in reverse order.
  • Page 7 2.1.8 To Remove Cook Thermostat/fan Switch a) Open main control panel. b) Remove control knob. c) Remove connections, noting their positions. d) Undo fixings which secure thermostat to control panel. e) Undo phial guard fixing to remove guard and retaining brackets. f) Feed phial back through oven side hole.
  • Page 8 2.1.14 To Replace Door Stud a) Undo locknut and remove stud. b) Replace stud and adjust as detailed in Figure 1 before tightening locknut. Figure 1 2.1.15 To Remove Oven Light a) Remove RH shelf hanger. b) Undo lamp cover fixing screws. c) Open control panel.
  • Page 9 Wiring Diagram...
