2. CO-Based Solutions

2.1 Overview

Cabling, wiring, connection and splitter options for each of the ADSL solutions are described in this chapter.
Ordering information is provided. Detailed product specifications are provided in the Appendix.
Each CO-based solution is comprised of the following components:
• Telesyn system with ADSL cards
• Cabling to the Splitter
• Splitter (not required for ADSL8S)
•
Distribution frame blocks
• Frame jumpers
Note: Telesyn Compact Multiservice Access Platform (MAP) system ordering information and
specifications are contained in the Telesyn MAP Component Specification
Note: For SHDSL configurations, use a standard RJ-21 cable with a standard pinout; for pair usage,
refer to the Telesyn MAP Component Specification.
An explanation of part numbers for cable assemblies that are connectorized on both ends follows:
AT-TN-K025-A-xxx
• AT-TN - Telesyn
• K025 - Specific part number
• A - A series
• xxx - Cable length (see table below)
xxx value Cable Length
005 5 ft.
010 10 ft.
015 15 ft.
020 20 ft.
Allied Telesyn Wiring Solutions (CO-Based Solutions)
xxx value Cable Length
050 50 ft.
060 60 ft.
070 70 ft.
080 80 ft.
2-1
