AlliedTelesyn™
Wiring Solutions:
For Optimized xDSL Performance
Release 8.0 (and up unless reissued)
Issue 1
© 2006 Allied Telesyn Networks. All rights reserved. Information subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSL8S and is the answer not in the manual?

Questions and answers

Related Manuals for Allied Telesis ADSL8S

Summary of Contents for Allied Telesis ADSL8S

  • Page 1 AlliedTelesyn™ Wiring Solutions: For Optimized xDSL Performance Release 8.0 (and up unless reissued) Issue 1 © 2006 Allied Telesyn Networks. All rights reserved. Information subject to change without notice.
  • Page 2 Introduction Congratulations on your purchase of Allied Telesyn™ products! Who Should Read This Guide? This document is intended for sales and network engineers, project managers, and service provider and telco staff who are involved in equipment recommendations, ordering, installation and maintenance of xDSL (ADSL and SHDSL) subscriber service and associated equipment both at the central office and subscriber premises.

  • Page 3: Table Of Contents

    2.2...
  • Page 4 5.4...

  • Page 5: Solutions For Optimized Adsl Performance

    The 71xx is a small unit that offers three ADSL16 cards of Annex-A service, three ADSL16B cards of Annex-B service, both a maximum of 48 ports, or three ADSL8S cards (8 ports with splitter) for 24 ports. Telesyn Wiring Solutions (Solutions for Optimized ADSL Performance)
  • Page 6 Figure 1-1 illustrates a complete wiring solution from the iMAP with the CO-based solutions through the office to the subscriber premises with Residential solutions. Telesyn iMAP POTS Device Splitter Network Isolation Device Splitter Outside Phone Attenuator Distribution Plant Frame Facilities Television Phone Set Top Box...

  • Page 7: Co-Based Solutions

    Each CO-based solution is comprised of the following components: • Telesyn system with ADSL cards • Cabling to the Splitter • Splitter (not required for ADSL8S) • Distribution frame blocks • Frame jumpers Note: Telesyn Compact Multiservice Access Platform (MAP) system ordering information and...

  • Page 8: At-Tn-101-A (Adsl8S)

    PULL FAULT I N SERV Equip. Subsc. Side Side Subscriber (Alternative option) ADSL8S FIGURE 2-1 The ADSL8S solution is comprised of the following components: • ADSL8S cards • Cabling to the distribution frame equipment side • Distribution frame blocks • CAT5 DF Jumper Wire Order one terminal block cable assembly per four ADSL cards.
  • Page 9 AT-TN-101-A (ADSL8S) AT-TN-K025-A- Terminal block with four Cable Assembly - 10 ft. AT-TN-K025-A- Terminal block with four Cable Assembly - 15 ft. AT-TN-K025-A- Terminal block with four Cable Assembly - 20 ft. AT-TN-K025-A- Terminal block with four Cable Assembly - 30 ft.

  • Page 10: Tn-121-A, Tn-124B - Standard Splitter (Adsl24A, Adsl24B)

    TN-121-A, TN-124B - Standard Splitter (ADSL24A, ADSL24B) Order CAT5 Jumper wire to connect components on the Distribution Frame. Refer to the Appendix for wir- ing practices 5.3. Part Number Description TN-K015-A Kit, Jumper Wire, 1 pair, CAT5, White/Blue, 1K ft. Roll 2.3 TN-121-A, TN-124B - Standard Splitter (ADSL24A, ADSL24B) Distribution Frame...
  • Page 11 TN-121-A, TN-124B - Standard Splitter (ADSL24A, ADSL24B) Order adapter cables that allow a transition from optimized connections to standard connections. (Optimized end is red.) Part Number Description AT-TN-C018-A- Optimized male to Conventional male telco assembly - 5 ft. AT-TN-C018-A- Optimized male to Conventional male telco assembly - 10 ft.
  • Page 12 TN-121-A, TN-124B - Standard Splitter (ADSL24A, ADSL24B) Order one terminal block cable assembly per four splitter cards. The DF block is included and should be mounted on the distribution frame and connected directly to the splitter. Part Number Description AT-TN-K019-A- Terminal block with four Cable Assembly - 5 ft.
  • Page 13 TN-121-A, TN-124B - Standard Splitter (ADSL24A, ADSL24B) Part Number Description TN-K015-A Kit, Jumper Wire, 1 pair, CAT5, White/Blue, 1K ft. Roll Allied Telesyn Wiring Solutions (CO-Based Solutions)

  • Page 14: Tn-121-A, Tn-124B - High Performance Splitter (Adsl24A, Adsl24B)

    TN-121-A, TN-124B - High Performance Splitter (ADSL24A, ADSL24B) 2.4 TN-121-A, TN-124B - High Performance Splitter (ADSL24A, ADSL24B) Distribution Frame ADSL24 Card Equip. Subsc. Side Side Subscriber Frame Jumpers To existing (Alternative option) frame blocks ADSL24 FIGURE 2-3 The ADSL24 solution is comprised of the following components: •...
  • Page 15 TN-121-A, TN-124B - High Performance Splitter (ADSL24A, Part Number Description AT-TN-C013-A- Optimized 25 pair Cable Assembly - 3 ft. AT-TN-C013-A- Optimized 25 pair Cable Assembly - 5 ft. AT-TN-C013-A- Optimized 25 pair Cable Assembly - 7 ft. AT-TN-C013-A- Optimized 25 pair Cable Assembly - 10 ft. AT-TN-C013-A- Optimized 25 pair Cable Assembly - 15 ft.
  • Page 16 TN-121-A, TN-124B - High Performance Splitter (ADSL24A, ADSL24B) Provides 3 rack units of up to 4 cards for up to 96 ADSL ports Order one terminal block cable assembly per four ADSL cards. The DF block is included and should be mounted on the distribution frame and connected directly to the splitter.
  • Page 17 TN-121-A, TN-124B - High Performance Splitter (ADSL24A, Order CAT5 Jumper wire to connect components on the Distribution Frame. Use CAT5 wiring practices 5.3. Part Number Description TN-K015-A Kit, Jumper Wire, 1 pair, CAT5, White/Blue, 1K ft. Roll 2-11 Allied Telesyn Wiring Solutions (CO-Based Solutions)

  • Page 18: At-Tn-113-A (Pots24)

    AT-TN-113-A (POTS24) 2.5 AT-TN-113-A (POTS24) Distribution Frame Subsc. Side Subscriber Frame Jumpers To existing frame blocks (Alternative option) POTS24 FIGURE 2-4 The POTS24 solution is comprised of the following components: • Telesyn system with POTS24 cards • Cabling to the splitter •...
  • Page 19 AT-TN-113-A (POTS24) TN-C008-A-020 CABLE, CONVENTIONAL RJ21 MALE TO CON- VENTIONAL RJ21 MALE, 20FT TN-C008-A-030 CABLE, CONVENTIONAL RJ21 MALE TO CON- VENTIONAL RJ21 MALE, 30FT TN-C008-A-040 CABLE, CONVENTIONAL RJ21 MALE TO CON- VENTIONAL RJ21 MALE, 40FT TN-C008-A-050 CABLE, CONVENTIONAL RJ21 MALE TO CON- VENTIONAL RJ21 MALE, 50FT TN-C008-A-060 CABLE, CONVENTIONAL RJ21 MALE TO CON-...

  • Page 20: At-Tn-123-A (Pac24)

    AT-TN-123-A (PAC24) 2.6 AT-TN-123-A (PAC24) The PAC24 card provides both the POTS24 and ADSL24A functionality on one card, with internal splitters. As a result, a separate splitter is not used. Distribution Frame PAC24 Card Equip. Subsc. Side Side Subscriber Frame Jumpers To existing (Alternative option)
  • Page 21 AT-TN-123-A (PAC24) AT-TN-K022-A- Terminal block with four Cable Assembly - 50 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 60 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 70 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 80 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 90 ft.

  • Page 22: At-Tn-129-A - Internal Splitter Annex-A (Adsl24Sa)

    AT-TN-129-A - Internal Splitter Annex-A (ADSL24SA) 2.7 AT-TN-129-A - Internal Splitter Annex-A (ADSL24SA) Distribution Frame ADSL24SA Card Equip. Subsc. Side Side Subscriber Frame Jumpers To existing (Alternative option) frame blocks ADSL24SA FIGURE 2-6 The ADSL24SA provides the ADSL24A functionality on one double-width card, with internal POTS splitters. The connection is comprised of the following components: •...
  • Page 23 AT-TN-129-A - Internal Splitter Annex-A (ADSL24SA) Order one cable per ADSL24SA card and connect one end directly to the (label and the other PSTN CAT 3) end to a POTS connection. Note: This uses standard RJ21 wiring, so exisitng cable could be used instead of this cable. Part Number Description TN-C008-A-005...
  • Page 24 AT-TN-129-A - Internal Splitter Annex-A (ADSL24SA) AT-TN-K022-A- Terminal block with four Cable Assembly - 30 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 40 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 50 ft. AT-TN-K022-A- Terminal block with four Cable Assembly - 60 ft.

  • Page 25: At-Tn-71Xx-A

    AT-TN-71xx-A 2.8 AT-TN-71xx-A In release 6.1, the 7101, 7102, 7103, 7104, and 7105 are no longer available. Instead, the following product is available: • TN-07112-A - Provides ADSL Annex-A service for 48 ports. This product replaces the 7101, 7102, 7103, and 7104. Note: In a future release, the TN-9100-A can be configured to replace the TN-7105-A and provide Annex-B service.

  • Page 26: Cabinet Solutions

    Circuits 0 - 23 Surge Protector Adapter Assembly FIGURE 2-7 Order one 24 circuit surge protector adapter assembly for every 3 ADSL8S cards (one adapter assembly protects 3 ADSL8S cards). Connect the ground cable from the surge protector adapter assembly to GND.

  • Page 27: Installation Recommendations

    3. Installation recommendations 3.1 Overview This section illustrates recommended wiring installation procedures for the solutions detailed in the previous sec- tions. Telesyn Wiring Solutions (Installation recommendations)

  • Page 28: At-Tn-C013-A

    AT-TN-C013-A 3.2 AT-TN-C013-A The following diagram illustrates the wiring required at the distribution frame for the AT-TN-C013-A, ADSL24 card, and High Performance splitter. For each ADSL24 card, the user would: Connect one AT-TN-C013-A of correct length from the ADSL24 card to the High Performance splitter card ADSL connector.

  • Page 29: At-Tn-K019-A

    AT-TN-K019-A 3.3 AT-TN-K019-A The following diagram illustrates the wiring required at the distribution frame for the AT-TN-K019-A and ADSL16 card. For each ADSL16 card, the user would: Connect one AT-TN-C008-A of correct length from the ADSL16 card to the splitter card ADSL connector. Connect a customer-supplied CAT3 cable/wiring of correct length from the splitter card PHONE connector to the Class #5 switch for POTS service.

  • Page 30: At-Tn-K022-A

    AT-TN-K022-A 3.4 AT-TN-K022-A 3.4.0.1 ADSL16 High Performance - Optimized The following diagram illustrates the wiring required at the distribution frame for the AT-TN-K022-A and ADSL16 card. For each ADSL16 card, the user would: Connect one AT-TN-K019-A of correct length from the ADSL16 card to the distribution frame. Connect one AT-TN-K022-A of correct length from the splitter card ADSL connector to the distribution frame.
  • Page 31 AT-TN-K022-A AT-TN-K022-A from Telesyn splitter card (connects to 4 cards) Subscriber premises Splitter Card 1 44 46 48 50 15 17 19 21 23 25 27 29 33 35 37 40 Splitter Card 2 15 17 19 21 23 25 27 29 33 35 37 40...
  • Page 32 AT-TN-K022-A AT-TN-K022-A from Telesyn TN-S105-A splitter card (connects to 4 cards) Subscriber premises Splitter Card 1 44 46 48 50 15 17 19 21 23 25 27 29 33 35 37 40 Splitter Card 2 44 46 48 50 15 17 19 21 23 25 27 29...

  • Page 33: At-Tn-K025-A

    The following diagram illustrates the wiring required at the distribution frame for the AT-TN-K025-A and ADSL8S card. Connect one AT-TN-K025-A of correct length from the ADSL8S card to the distribution frame. The user should refer to the connector pinouts for the pin connection numbering. This is how a single subscriber line would be wired.
  • Page 34 AT-TN-K025-A Telesyn Wiring Solutions (Installation recommendations)

  • Page 35: Residential Premises

    4. Residential Premises 4.1 Customer Premises Equipment Set Top Box NID CPE ADSL Telco Attenuator Splitter Modem Network Phone Phone Video and Data solution FIGURE 4-1 The following components are described in this section: • CPE Splitter • Attenuator Telesyn Wiring Solutions (Residential Premises)
  • Page 36 Customer Premises Equipment Order one CPE Splitter per subscriber ADSL connection. Should be mounted at the entry to the house and a Home-Run taken directly from the splitter to the ADSL Modem Part Number Description Market Specific Market dependent requirements Order sufficient attenuators to apply one to each short loop of ADSL service that is deployed.

  • Page 37: Appendix

    5. Appendix 5.1 General Safety Guidelines Note: Only personnel familiar with local telco practices should install, replace, or service this equipment. Note: Before starting equipment installation procedures, the user should read the whole chapter for important information and safety warnings. Before cabling the equipment, the user should be aware of standard safety practices and the hazards involved in working with electricity to avoid accidents.
  • Page 38 General Safety Guidelines Setup Precautions and Antistatic Procedures Electrostatic discharge (ESD) can damage equipment when electronic equipment is handled improperly. ESD damage can produce total or partial failures in electronic equipment. Follow these ESD-prevention procedures when handling systems cards and modules: Verify that the frame is electrically connected to earth ground.

  • Page 39: Adsl Card Connector Cable Pinout

    ADSL Card Connector cable pinout 5.2 ADSL Card Connector cable pinout The ADSL card connector pin number locations are illustrated in the next figure. Pi n 50 Pi n 50 Card Cable Connector Connector Pi n 26 Pi n 26 ADSL card connector cable pinout FIGURE 5-1 5.3 CAT5 Best Practices...

  • Page 40: Tn-101-A (Adsl8S)

    TN-101-A (ADSL8S) 5.4 TN-101-A (ADSL8S) The table below illustrates the ADSL8S card RJ-21 connector and pin layouts. Wiring table for RJ-21 - ADSL8S TABLE 5-1 RING Pair ADSL Port # Pin # Wire Color Pin # Wire Color ADSL 0...

  • Page 41: At-Tn-C000

    AT-TN-C000-A 5.5 AT-TN-C000-A Used to connect a conventional splitter to the DF using 25 pairs (50 wires) of unterminated wires. Pinouts for RJ- 21 to unterminated 15m cable assembly. RJ-21 to Unterminated FIGURE 5-2 Telesyn Wiring Solutions (Appendix)

  • Page 42: At-Tn-C001

    AT-TN-C001-A 5.6 AT-TN-C001-A RJ-21 to unterminated 25m cable assembly. Note: See AT-TN-C000-A for wiring pinouts 5.7 AT-TN-C002-A RJ-21 to unterminated 35m cable assembly. Note: See AT-TN-C000-A for wiring pinouts Telesyn Wiring Solutions (Appendix)

  • Page 43: At-Tn-C005

    5.8 AT-TN-C005-A Used to connect the ADSL8S to two different positions on the DF, one for POTS and one for ADSL using 16 pairs (32 wires) of unterminated wires, 4 pair to a bundle. 4 (4-pair) 15m cable assembly (unterminated).

  • Page 44: At-Tn-C006

    AT-TN-C006-A 5.9 AT-TN-C006-A 4 (4-pair) 25m cable assembly. Note: See AT-TN-C005-A for wiring pinouts 5.10 AT-TN-C007-A 4 (4-pair) 35m cable assembly. Note: See AT-TN-C005-A for wiring pinouts Telesyn Wiring Solutions (Appendix)

  • Page 45: At-Tn-C008-A-Xxx

    AT-TN-C008-A-xxx 5.11 AT-TN-C008-A-xxx Used to connect the Telesyn system to a standard splitter Male RJ-21 Connector Male RJ-21 Connector Pair ADSL-Ring-1 ADSL-Ring-1 ADSL-Tip-1 ADSL-Tip-1 ADSL-Ring-2 ADSL-Ring-2 ADSL-Tip-2 ADSL-Tip-2 ADSL-Ring-3 ADSL-Ring-3 ADSL-Tip-3 ADSL-Tip-3 ADSL-Ring-4 ADSL-Ring-4 ADSL-Tip-4 ADSL-Tip-4 ADSL-Ring-5 ADSL-Ring-5 ADSL-Tip-5 ADSL-Tip-5 ADSL-Ring-6 ADSL-Ring-6 ADSL-Tip-6...

  • Page 46: At-Tn-C013-A-Xxx

    AT-TN-C013-A-xxx 5.12 AT-TN-C013-A-xxx Used to connect ADSL24 cards to a high performance splitter. Opt Male RJ-21 Connector Opt Male RJ-21 Connector Pair Pair ADSL-Ring-1 ADSL-Ring-1 ADSL-Tip-1 ADSL-Tip-1 ADSL-Ring-2 ADSL-Ring-2 ADSL-Tip-2 ADSL-Tip-2 ADSL-Ring-3 ADSL-Ring-3 ADSL-Tip-3 ADSL-Tip-3 ADSL-Ring-4 ADSL-Ring-4 ADSL-Tip-4 ADSL-Tip-4 ADSL-Ring-5 ADSL-Ring-5 ADSL-Tip-5 ADSL-Tip-5...

  • Page 47: At-Tn-C018-A-Xxx

    AT-TN-C018-A-xxx 5.13 AT-TN-C018-A-xxx Used to adapt or transition from high performance CAT5 cabling to standard telco cabling. Opt Male RJ-21 Connector Conv Male RJ-21 Connector Pair ADSL-Ring-1 ADSL-Ring-1 ADSL-Tip-1 ADSL-Tip-1 ADSL-Ring-2 ADSL-Ring-2 ADSL-Tip-2 ADSL-Tip-2 ADSL-Ring-3 ADSL-Ring-3 ADSL-Tip-3 ADSL-Tip-3 ADSL-Ring-4 ADSL-Ring-4 ADSL-Tip-4 ADSL-Tip-4 ADSL-Ring-5...

  • Page 48: At-Tn-C019-A-Xxx

    AT-TN-C019-A-xxx 5.14 AT-TN-C019-A-xxx Used to connect the high performance splitter to the DF. Pinouts for Optimized 5-wired RJ-21 to unterminated 15m, 25m, and 35m cable assembly. Wiring table for RJ-21 to unterminated cable assembly TABLE 5-2 Wire Color Wire Color BLUE/WHITE GREEN/BLACK WHITE/BLUE...

  • Page 49: At-Tn-K019-A-Xxx

    AT-TN-K019-A-xxx 5.15 AT-TN-K019-A-xxx Used to terminate ADSL24 or standard splitter at the distribution frame. This view illustrates the DF block with flap opened and turned upright 44 46 48 50 15 17 19 21 23 25 27 29 33 35 37 40 44 46 48 50...
  • Page 50 AT-TN-K019-A-xxx RJ-21 Male Connector Telect Pin connections Cable Pair Pin Field Column Tip/Ring 1 ADSL-Ring-1 Ring 26 ADSL-Tip-1 2 ADSL-Ring-2 Ring 27 ADSL-Tip-2 3 ADSL-Ring-3 Ring 28 ADSL-Tip-3 4 ADSL-Ring-4 Ring 29 ADSL-Tip-4 5 ADSL-Ring-5 Ring 30 ADSL-Tip-5 6 ADSL-Ring-6 Ring 31 ADSL-Tip-6 7 ADSL-Ring-7...

  • Page 51: At-Tn-K022-A-Xxx

    AT-TN-K022-A-xxx 5.16 AT-TN-K022-A-xxx Used to terminate high performance splitter cards at the distribution frame. This view illustrates the DF block with flap opened and turned upright. 44 46 48 50 15 17 19 21 23 25 27 29 33 35 37 40 44 46 48 50...
  • Page 52 AT-TN-K022-A-xxx RJ-21 Male Connector Telect Pin connections Cable Pair Pin Field Column Tip/Ring ADSL-Ring-1 Ring ADSL-Tip-1 ADSL-Ring-2 Ring ADSL-Tip-2 ADSL-Ring-3 Ring ADSL-Tip-3 ADSL-Ring-4 Ring ADSL-Tip-4 ADSL-Ring-5 Ring ADSL-Tip-5 ADSL-Ring-6 Ring ADSL-Tip-6 ADSL-Ring-7 Ring ADSL-Tip-7 ADSL-Ring-8 Ring ADSL-Tip-8 ADSL-Ring-9 Ring ADSL-Tip-9 ADSL-Ring-10 Ring ADSL-Tip-10...

  • Page 53: At-Tn-K025-A-Xxx

    AT-TN-K025-A-xxx 5.17 AT-TN-K025-A-xxx Used to terminate ADSL8S at the distribution frame. This view illustrates the DF block with flap opened and turned upright. 11 12 13 14 15 26 27 28 29 30 32 33 34 35 36 37 38 39...
  • Page 54 Ring ADSL-Tip-7 Line-Ring-7 Ring Line-Tip-7 ADSL-Ring-8 Ring ADSL-Tip-8 Line-Ring-8 Ring Line-Tip-8 (Connected, but unused) ADSL8S to DF block for the A row FIGURE 5-12 The same wiring pattern applies to rows B, C, and D. 5-18 Telesyn Wiring Solutions (Appendix)

  • Page 55: At-Tn-K026-A

    Wiring Installation AT-TN-K026-A 5.18 AT-TN-K026-A Used to connect 3 ADSL8S cards into a cabinet. 24 circuit surge protector adapter assembly. CONNECTOR AND HOOD UL RECOGNIZED CATEGORY 5E, 24 AWG, UL TYPE CMR, 25 PAIR, BLUE JACKET, PREMISE CABLE LENGTH: 8 FEET 6.100...
  • Page 56 AT-TN-K026-A Wiring Installation Connect the circuit from the surge protector adapter assembly into the cabinet surge protector. Install a protection module on the surge protector adapter assembly for the specified circuit. Wiring Table for Surge Protector Adapter Assembly TABLE 5-3 5 Pin Conn.
  • Page 57 Wiring Installation AT-TN-K026-A Wiring Table for Surge Protector Adapter Assembly (Continued) TABLE 5-3 5 Pin Conn. Champ AMP Cable Wire Pair 5 Pin Conn. Cable 24 Pair Port. Panel (1-8) Color Ring (EQ) Voice orange/white Splice brown/black Tip (OSP) Voice/DSL white/blue Tip (OSP) | Tip (EQ) black/green...

  • Page 58: Tn-S004-A (Splitter Chassis)

    TN-S004-A (Splitter Chassis) Wiring Installation 5.19 TN-S004-A (Splitter Chassis) Used to separate the incoming ADSL24 line into voice and data. This high performance, high isolation splitter is specially designed to implement the functionality of low pass filtering of POTS over an ADSL application. It supports 96 lines and contains 4 splitter cards with 24 lines per card.

  • Page 59: Splitter Conformance

    Splitter Conformance TN-S004-A (Splitter Chassis) High Performance Splitter Chassis - Fully Installed with Four Splitter Cards FIGURE 5-14 5.19.1 Splitter Conformance TO BE SUPPLIED Splitter Safety Warnings • Never work alone when potentially hazardous conditions exist, and never assume that power has been disconnected from a circuit- always check. •...

  • Page 60: Tn-S116-A (Splitter Card) - Annex B

    TN-S004-A (Splitter Chassis) TN-S116-A (Splitter Card) - Annex B 5.19.2 TN-S116-A (Splitter Card) - Annex B The TN-S116-A is used to split the customer loop which contains both ADSL Annex B data and POTS voice signals into two separate signal paths - an ADSL data path and a voice band/ISDN path. This high performance, high isolation splitter card is specially designed to implement the low pass filter that removes the ADSL data from the voice band/ISDN signals.
  • Page 61 Wiring Installation Overview TN-S004-A (Splitter Chassis) Telesyn 7700 Incoming pair from the subscriber premises Connection to the MAP PHONE PHONE PHONE PHONE PHONE PHONE PHONE CO Switch Connection to the CO switch TN-S004-A Chassis Connections FIGURE 5-15 Connector Pinout Numbering FIGURE 5-16 Note: Each card includes brackets and screws to facilitate the installation of tie wraps for the 90°...

  • Page 62: Connector Pinouts - Tn-S116-A

    TN-S004-A (Splitter Chassis) Connector Pinouts - TN-S116-A 5.19.5 Connector Pinouts - TN-S116-A Table 5-5, Table 5-6, and Table 5-7 to locate the connectors PHONE (J1), LINE (J2), and ADSL (J3) on the splitter. The following tables provide the pinouts. Note: Refer to 5.19.6 for connector pinouts for the TN-S101-A.
  • Page 63 Connector Pinouts - TN-S116-A TN-S004-A (Splitter Chassis) J2 - Combined ADSL + POTS Output (Non-traditional) TABLE 5-6 Function Function Ring 1 Ring 13 Tip1 Tip13 Ring 2 Ring 14 Tip 2 Tip 14 Ring 3 Ring 15 Tip 3 Tip 15 Ring 4 Ring 16 Tip 4...
  • Page 64 TN-S004-A (Splitter Chassis) Connector Pinouts - TN-S116-A J3 - ADSL input to splitter from SM (Non-traditional) TABLE 5-7 Function Function Ring 1 Ring 13 Tip1 Tip13 Ring 2 Ring 14 Tip 2 Tip 14 Ring 3 Ring 15 Tip 3 Tip 15 Ring 4 Ring 16...

  • Page 65: Connector Pinouts - Tn-S101-A

    Connector Pinouts - TN-S101-A TN-S004-A (Splitter Chassis) 5.19.6 Connector Pinouts - TN-S101-A Table 5-8, Table 5-9, and Table 5-10 to locate the connectors PHONE (J1), LINE (J2), and ADSL (J3) on the splitter. The following tables provide the pinouts. J1 - POTS input from PSTN Switch (Traditional Pinout) TABLE 5-8 Function Function...
  • Page 66 TN-S004-A (Splitter Chassis) Connector Pinouts - TN-S101-A J2 - Combined ADSL + POTS Output (Non-traditional) TABLE 5-9 Function Function Ring 1 Ring 13 Tip1 Tip13 Ring 2 Ring 14 Tip 2 Tip 14 Ring 3 Ring 15 Tip 3 Tip 15 Ring 4 Ring 16 Tip 4...
  • Page 67 Connector Pinouts - TN-S101-A TN-S004-A (Splitter Chassis) J3 - ADSL input to splitter from SM (Non-traditional) TABLE 5-10 Function Function Ring 1 Ring 13 Tip1 Tip13 Ring 2 Ring 14 Tip 2 Tip 14 Ring 3 Ring 15 Tip 3 Tip 15 Ring 4 Ring 16...

  • Page 68: Tn-S900-A (Attenuator)

    TN-S900-A (Attenuator) Overview 5.20 TN-S900-A (Attenuator) 5.20.1 Overview The TN-S900-A loop attenuator is used to artificially increase the distance between the DSLAM (ATU-C) and the Customer Premise Equipment (ATU-R). Each TN-S900-A adds approximately 2000 ft. of “cable” to the cus- tomer loop.

  • Page 69: Determining If Installation Of Tn-S900-A Is Needed

    Determining if Installation of TN-S900-A is Needed TN-S900-A (Attenuator) Attenuator Connections FIGURE 5-18 5.20.3 Determining if Installation of TN-S900-A is Needed This subsection provides steps to determine if you should install the TN-S900-A, and an example that illustrates what to look for when performing these steps. 5.20.3.1 Determining if Installation of TN-S900-A is Needed Use these guidelines to determine if installing an attenuator is appropriate.
  • Page 70 TN-S900-A (Attenuator) Determining if Installation of TN-S900-A is If the DSLAM power output is between 16.0 and 30.0 dBm (or greater), do NOT install an attenuator; other- wise proceed to Step Determine the existing ADSL line attenuation (shown in 5.20.3.2). If the perceived line attenuation of the CPE is between 25.0 and 50.0 dB (or greater), do NOT install an attenuator;...
  • Page 71 Determining if Installation of TN-S900-A is Needed TN-S900-A (Attenuator) Upstream Rate....(ATU-R) 1021.9 kbps Max Attainable Rate..(ATU-R) 1371.6 kbps Signal-to-Noise Ratio..(ATU-C) 12.5 dB Attenuation....(ATU-C) 4.0 dB Output Power...(ATU-R) 6.5 dBm 5-35 Telesyn Wiring Solutions (Appendix)

  • Page 72: Specifications

    TN-S900-A (Attenuator) Specifications 5.20.4 Specifications Attenuator Specifications TABLE 5-11 Parameter Criteria Unit Dimensions Width - 1.6 in (40 mm) Height - 1.0 in (25 mm) Length - 2 in (50 mm) Length of attached RJ45 cable - 4 in (100 mm) Environmental Designed to be used in indoor applications Long time operation temperature - 41°F - 104°...
  • Page 73 Conformance TN-S900-A (Attenuator) FCC - This Allied Telesyn product complies with FCC requirements for emissions radia- tion. Users of this Allied Telesyn product are cautioned that any changes or modifica- tions not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the product.
  • Page 74 TN-S900-A (Attenuator) Conformance 5-38 Telesyn Wiring Solutions (Appendix)
