POSIFLEX SA Series Quick Setup Manual

MDI-3100/4100 2D Image Scanner
Quick Setup Guide
Scanner Maintenance
The scanner is designed for long-term trouble-free operation and rarely
requires any maintenance. Only an occasional cleaning of the scanner window
is necessary in order to remove dirt and fingerprints.
Wipe the scan window with a soft lint-free cloth and a non-abrasive cleaner to
avoid the scan window from being scratched and damaged. The scan window
can be cleaned while the scanner is running.
The standard interface cable is attached to the scanner with a 10-pin modular
connector. When the connector is properly seated, it is secured in the scanner
by a flexible retention tab. The cable is designed to be field replaceable.
Replacement cables can be obtained from your authorized distributor. To
replace the cable, take the following steps.
Make sure the power of both the host terminal and the scanner is powered
1.
off.
Disconnect the old scanner cable from the host terminal.
2.
Press down the retention tab, and gently pull out the cable.
3.
Insert the new interface cable into the bottom of the scanner until it clicks.
4.
Plug the new cable into the host.
Programming Codes
Below are some suggestion you need to bear in mind while scanning labels:
1. The barcode labels shown in bold and black are default factory
settings.
2. Please cover the unwanted codes for scanning the specific barcode
required for the programming to prevent confusion in code scanning.
3. Use the user manual downloaded from our global website or taken from
the Information DVD for advanced programming.
4. Two operational modes, Auto Trigger and Manual Trigger, are provided
to help you manage your daily activities more efficiently via 2D Image
Scanner. By default, the scanner is set to Auto Trigger.
5. While scanning the setup barcode labels provided in the quick guide, you
need to pull the trigger to initiate the decoding process.
6. Please scan barcode within a scan range of 130mm to ensure barcode data
can be detected successfully.
15650901050 Ver. D0
