Danfoss 176F4057 Installation Manual page 6

In-back/Out-back Cooling Kit for FA11-FA12
Installation Guide
6X S-M10-2Z1
7 (0.3)
3 (0.1)
Illustration 3: Vent Dimensions for Mounting Plate in 600 mm (24 in) Cabinet
6 | Danfoss A/S © 2022.03
499 (19.7)
0.0
100 (3.9)
137 (5.3)
158 (6.2)
169 (6.7)
314 (12.3)
326 (12.8)
347 (13.7)
1335 (52.6)
1357 (53.4)
1368 (53.9)
1513 (59.6)
1524 (60.0)
1545 (60.8)
1645 (64.7)
23 (0.9)
AN361428862578en-000101 / 136R0249
Installation
