Installing The Bottom Cover - Danfoss 176F4057 Installation Manual

In-back/Out-back Cooling Kit for FA11-FA12
Installation Guide
1
2
3
4
5
6
Illustration 7: Installation of the Top Cover
1 M5x14 screw
2 Top cover
3 Top gasket

2.6 Installing the Bottom Cover

DRAIN OPENING
The bottom cover features a drain opening in the middle of the plate.
-
To drain moisture in wet or humid environments, attach nylon tubing with interior diameter of 8 mm (0.3 in).
-
To seal the drain in dry environments, fasten a screw in the drain hole.
To install the bottom cover at the lower end of the cooling back channel, use the following steps. See
Procedure
1. Remove the paper backing from the bottom gasket.
2. Adhere the gasket to the upper side of the bottom cover.
3. Position the bottom cover and gasket over the opening at the lower end of the cooling channel.
10 | Danfoss A/S © 2022.03
4 Top vent
5 M5x12 screws (loosened, not removed)
6 Top of frequency converter
N O T I C E
Installation
Illustration 8.
AN361428862578en-000101 / 136R0249
