In-back/Out-back Cooling Kit for FA11-FA12
Installation Guide
1 Cabinet
2 Bottom gasket
3 Bottom cover
4 M5x14 screw
5 Top cover
6 Top gasket
2.3 Creating Vent Openings in the Mounting Plate
To create upper and lower vent openings in the mounting plate, use the following steps. Use the dimensions in
mm (24 in) cabinets, and Illustration 4
Procedure
1. Drill 6 mounting holes in the back of the frequency converter using the dimensions in the template.
2.
Insert 6 M10 pem self-clinching nuts (not supplied) in the mounting holes.
3. Cut out the upper and lower vent openings in the mounting plate using the dimensions in the template.
The openings must match the frequency converter vent openings.
4. Drill 6 screw holes around each vent opening using the dimensions in the template.
The holes must match the holes in the frequency converter and the inner flange of the back ducts.
Danfoss A/S © 2022.03
for 800 mm (32 in) cabinets.
7 Clip-on nut
8 Back duct
9 M5x18 screw
10 6-hole gasket
11 8-hole gasket
12 M6x12 screw
AN361428862578en-000101 / 136R0249 | 5
Installation
Illustration 3 for 600
