Section 4 - Con guration
Tick this box to enable this feature and click More to con gure
Enabled:
VPN Dynamic IP on a separate page. Please see the next page
for more details.
Enter a name for your VPN.
Tunnel Name:
Enter the local (LAN) subnet. (ex. 192.168.0.0)
Local Subnet:
Enter the local (LAN) subnet mask. (ex. 255.255.255.0)
Local Netmask:
Enter the amount of time in seconds that the Phase 1 key should
Pase1 Key Life
last.
Time:
Enter the amount of time in seconds that the Phase 2 key should
Phase2 Key Life
last.
Time:
Choose either ESP, AH or ESP+AH from the drop-down menu.
Encapsulation
protocol:
Enable or Disable the PFS Group option using the drop-down
PFS Group:
menu. PFS is an additional security protocol.
Check this box to enable aggressive mode.
Aggressive Mode:
Enter an ASCII passphrase in the box.
Preshare Key:
Choose from Username, FQDN, User@FQDN, or Key ID using
Local ID:
the drop-down menu and then enter an ID in the box.
D-Link DWM-312 User Manual
Dynamic VPN Settings
