- Page 1 ADVANCED REVERSE OSMOSIS SYSTEM DIRECT FLOW MANUAL EQUIPMENT REVERSE OSMOSIS...
- Page 3 ADVANCED REVERSE OSMOSIS SYSTEM DIRECT FLOW ÍNDICE User manual Technical manual Sanitization manual Data sheet...
- Page 4 USER MANUAL FOR REVERSE OSMOSIS EQUIPMENT 0. MAIN FEATURES CLICK ELECTRONIC ADAPTER QUICK CONNECTIONS GREATER SECURITY AND MAXIMUM SECURITY AND EFFICIENCY FILTER CONTROL DOUBLE FLOW AUTOMATIC WARNING HIGHER FLOW OF MAINTENANCE OF WATER DISPENSED SOLENOID DIRECT VALVE ACCESS IMMEDIATE CONTROL EASE OF ACCESS SECURITY MESH AND MAINTENANCE...
- Page 5 1. INTRODUCTION 3. ADVANCE WARNINGS Congratulations. You have purchased an excellent piece ATTENTION: Read carefully the warnings des- of equipment for domestic water treatment. cribed in the corresponding section of the Technical Manual. This unit will help you improve the features of your water.
- Page 6 • It is recommended not to use aluminum utensils to cook with osmosis water. 4. BASIC OPERATION The mains water to be treated enters the equipment passing through a sediment filter and a combined polypropylene and carbon block filter. In this filtration stage, suspended particles, chlorine, its derivatives and other organic substances are retained.
- Page 7 7. IDENTIFICATION AND RESOLUTION OF PROBLEMS ISSUE POSSIBLE CAUSE SOLUTION 1. Leaking from the Several possible Call technical service outside of the unit. 2. No Production. 1. There is no water supply. 1. Wait for the supply to return. 2. No power supply. 2.
- Page 8 TECHNICAL MANUAL FOR REVERSE OSMOSIS EQUIPMENT 1. MAIN FEATURES Water treatment Inverse osmosis Improvement of the characteristics of drinking water (that complies with the requirements of the European Di- rective on water of human consumption 98/83 or its national transpositions in the different member states of the European Community).
- Page 9 • It is recommended that the water to be treated be • This equipment must not be installed lying down or tilted (2), softened or with a maximum hardness of 15 ºHF in or- because the leak sensor would be disabled. der to obtain optimal performance of the equipment.
- Page 10 ATTENTION: Claims for damage during transport � 16 mm must be presented together with the delivery note or invoice to your distributor, attaching the name � S A 16mm drill bit is of the carrier within a maximum period of 24 hours af- recommended for ter receipt of the merchandise.
- Page 11 5.2. INSTALLATION OF THE FILTERS 6.3. SYSTEM SEALS, STOP AND START • Remove the protective plastic from the filters. • Closing the faucet of the equipment on the worktop and keep the equipment hydraulically or electrically · Install the number 1 prefilter (PP) in position. powered conducting an eye check of the system to en- sure that there are no leaks (for about 5 min.).
- Page 12 RECOMMENDED MAINTENANCE Prefilter 1 PP = 12 months or 1500Lts. * Prefilter 2 PPC = 12 months or 1500Lts. * RO membrane = 48 months or 6000 Lts. * Prefilter K33 = 12 months or 1500Lts. * * Lts. Litres of water produced. Maintenance must be carried out by trained person- nel, who must handle the equipment properly, as well as use original spare parts to maintain the characteris-...
- Page 13 Hydraulic scheme. 1/4” 1/4” 1/4” � 3/8” 3/8” 1/4” 1/4” IN/FEED DRAIN...
- Page 14 SANITIZATION PROCEDURE 1. SANITIZATION ATTENTION: Extreme hygienic measures during the handling of the filters, the membrane and equipment components in contact with water. Necessary material: Wear disposable gloves or wash your hands as many times as necessary to avoid risks of contamination of •...
- Page 15 • Once the assembly is installed, close the new manual inlet valve and open the inlet valve connected to the wall adapter (7). The dosing housing must be empty. • Pour 0.25 liters of Hydrogen Peroxide into the dosing housing installed in the entrance of the equipment (8). Screw the body correctly to its head.
- Page 16 • Pay special attention to sanitizing the faucet spout. Use the sanitizing spray (or, failing that, hydrogen pe- roxide, dosing it in such a way that it penetrates the tap spout) and single-use blotting paper. Spray the spray on the tap nozzle (11), rub the spout and the tap nozzle with the disposable paper and do not touch it directly with your hands (12).
- Page 18 DATA SHEET FOR REVERSE OSMOSIS EQUIPMENT 1. TECHNICAL CHARACTERISTICS Water treatment Inverse osmosis Improvement of the characteristics of drinking water (that complies with the requirements of the European Di- rective on water of human consumption 98/83 or its national transpositions in the different member states of the European Community).
- Page 19 PP prefilter 1 x sediment 2,5” PPC prefilter 1 x combined sediment + carbon 2’5” RO membrane 800 GPD. Water flow: 1,7 lpm T33 postfilter 1 x granulated carbon 2” Power supply: 24 VDC 4 A. Power adapter: 100-240 Vac 50 / 60 Hz Type of tap: Special 1-way tap.
- Page 20 HYDRAULIC CONNECTION DIAGRAM * For salinities greater than 1500ppm consult your distributor. ** Higher hardness may reduce the life and workings of certain components. *** Maximum accumulation depending on the inlet pressure. **** Flow rates may vary by 20% depending on the temperature, pressure and specific composition of the water to be treated.
- Page 21 3. FEATURES FUNCTION ACTION 1. Flushing at machine Whenever it is electrically connected the system will flush the RO membrane for start-up. 20 seconds. 2. Flush after use When the machine accumulates more than 20 minutes of operation, a flushing of accumulated.
- Page 22 4. WARRANTY The distributor guarantees the equipment for a period of three years against any lack of conformity that is detected in them, as provided in RD 1/2007 of November 16 (consolidated text of the General Law for the defense of consumers and users). . ·...
- Page 23 5. INSTALLATION RECORD SHEET NOTES FOR THE TECHNICIAN/INSTALLER: read this carefullyHandbook. In case of any doubt, contact the Technical Assistance Service (SAT) of your distributor. The data marked with the symbol * must be filled in by the technician/ installer and transcribed by him/her on the WARRANTY sheet. This sheet must be kept by the installer and may be required by the distributor in order to improve after-sales service and customer service to the client.
- Page 24 6. MAINTENANCE SERVICE NAME, SIGNATURE AND STAMP OF THE AUTHORIZED DATE TYPE OF SERVICE TECHNICIAN START UP COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY HIGIENIZACIÓN EXTRAORDINARY OTROS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY...
- Page 25 6. MAINTENANCE SERVICE DATE TYPE OF SERVICE NAME, SIGNATURE AND STAMP OF THE AUTHORIZED TECHNICIAN START UP COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY...
- Page 26 6. MAINTENANCE SERVICE NAME, SIGNATURE AND STAMP OF THE AUTHORIZED DATE TYPE OF SERVICE TECHNICIAN START UP COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY HIGIENIZACIÓN EXTRAORDINARY OTROS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY...
- Page 27 6. MAINTENANCE SERVICE DATE TYPE OF SERVICE NAME, SIGNATURE AND STAMP OF THE AUTHORIZED TECHNICIAN START UP COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY SANITIZATION EXTRAORDINARY OTHERS WARRANTY COMPLETE MAINTENANCE TECHNICAL PREPARATION STAMP ORDINARY...
- Page 28 NOTES...
- Page 29 NOTES...
- Page 30 NOTES...
- Page 31 NOTES...
